Product: 4Ports Optical Fiber Media Converter
Our advantage
1.Warranty is 3 years with good quality
2. Min MOQ,only one is ok
3.more 16 years factory
4.OEM/ODM accept,CE passed
5.new design and fast delivery
The 4Ports Optical Fiber Media Converter transmits 10/100Base-T Ethernet electrical signal through fiber, realize TX/FX converter.
4Ports Optical Fiber Media Converter Picture:
4 UTP port,1fiber port;
Conforms to IEEE802.3,IEEE802.3u (10Base-T,100Base-TX,100BaseT-FX) international standard;
support single fiber or dual fiber optical port;
brings 1M buffer, supports 2KMAC address;
isolates network conflict and broadcasting package effectively, has the function of preventing broadcasting storm;
supports 802.1Q and 16 groups of VLAN;
single-mode connection:transmitting range can reach 120 kilometers.
support both 10/100M full/half duplex adapt and compulsive set 10M,100M,full duplex, half duplex, then convenient to connect CPE and protect previous invest when network upgrade
| Fiber connector | FC,ST,SC connector |
| Single-mode 8.3/125, 8.7/125, 9/125, 10/125µm,transmission distance(20km~120km) | |
| Multi-mode 50/125, 62.5/125, 100/140µm, transmission distance (0~2km) | |
| Ethernet interface | RJ-45 (coaxial twisted pair) 10/100Base-TX: UTP RJ45 connector |
| Operating standard: IEEE802.3 10 Base-T, IEEE802.3u 100Base-TX and 100Base-FX | |
| UTP cable:non-shielded 5 class cable Cat.5UTP(MUX transmission distance is up to 100 meters) | |
| Environment condition | Operating temperature: 0°c~+50 °c |
| Storage temperature: -20 °c~+70 °c | |
| Relative humidity:95% (uncondensed) | |
| Dimension | 210(W) × 140 (L) x 30(H) mm |
| Power supply | DC power: DC-48V, AC power: AC220V |
FAQ
1.How can i get a sample ?
You need place sample order to us.We will arrange the sample production for you.
2.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3.How can we place order?
After we made agreement on the product' parameters, we will make proforma invoice for your confirmation.when we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if you don't have ship forwarder, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
4.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. usually it takes about 7work days to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
5.What's your products' advantages ?
A. good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,assemble,packing and shipping.
D. Aftersale services, if there is quality problem, we will offer you replacement for defective quantity.
Packaging&Shipping
Certification
Item NO |
Description |
Fiber mode |
Distance |
BD-100M-4RJ-2 |
media converter |
Multi-mode |
2KM |
BD-100M-4RJ-20 |
media converter |
Single-mode |
20 KM |
BD-100M-4RJ-60 |
media converter |
Single-mode |
60 KM |
BD-100M-4RJ-80 |
media converter |
Single-mode |
80KM |
The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
Your any questions will be responsed within 12hours!
pls feel free contact us anytime, it's our honor to service for you. we are together.
