Product: 8 E1 to Optical Ethernet Protocol Converter
Our advantage:Warranty is 3 years with good quality/Low MOQ:1Piece/Low price/OEM or ODM accepted.
8 E1 to Optical Ethernet Protocol Converter use back multiplexing technology, transfer 10M/100M Ethernet data by using multi E1 channels. Realize convert between 1 to 8 E1 channels and Ethernet interface. It can transmit signal of E1 channel to RJ45 interface point to point, realize the connection of E1 channel and Ethernet. It different from normal bridge , supporting 1 to 8 E1 channels customized configuration, auto detecting the number of E1 channels and use the available E1, allow some limiting transfer delay between different E1 channels. Single line speed is 1968Kbits/s, 8 channels can up to 15744Kbits/s. it can connect with Ethernet switch or hub when in 10/100Mbps full/half duplex mode, make use of mass E1 resource in telecommunication networks to expend the transfer distance and application field of Ethernet, is a suitable solution for broadband switch in of Ethernet. It can used in fields such as connecting LANs, connecting end offices, VOD, remote monitor, E1 interface of switches, etc.
8 E1 to Optical Ethernet Protocol Converter
- Realizing the transparent transmission of Ethernet data via 1 to 8 E1 lines
- Providing 10/100Base-Tx&100Base-Fx interface in compliance with the protocol
- standard IEEE 802.3, providing 2 electronical Ethernet ports and one optical Ethernet port
- supporting the working mode of either full duplex or half-duplex.
- Able to transparently transmit the ultra-long frames (up to 1916 bytes) as defined in IEEE 802.1Q, supporting transparent transmission of VLAN frames.
- Providing an in-built dynamic Ethernet MAC address list (1024 addresses) with filtering function for local data frames.
- 128MBits large capacity cache memory and an in-built SDRAM controller, to adapt to various service requirements.
- E1 interface in compliance with ITU-T G.703, G.704 and G.823, not applicable for signaling time slot.
- E1 Support 75Ω/unbalance impedance or 120Ω/balance for order
- Allowing a clock drift up to 512UI in the transmission system, with significantly enhanced reliability.
- Providing availability detection and automatic troubleshooting for 1 to 8 E lines.
- Supporting E1 interface loop-back function and Ethernet loop-back function.
- Self-contained line alarm indication and output.
- Optional power supply, e.g. AC220V or DC-48V; optional mounting type, e.g. desktop or rack mounted.
- Power consumption: <10 W
E1 Interface
FAQ
1.How can i get a sample ?
You need place sample order to us.We will arrange the sample production for you.
2.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3.How can we place order?
After we made agreement on the product' parameters, we will make proforma invoice for your confirmation.when we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if you don't have ship forwarder, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
4.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. usually it takes about 7work days to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
5.What's your products' advantages ?
A. good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,assemble,packing and shipping.
D. Aftersale services, if there is quality problem, we will offer you replacement for defective quantity.
Packaging&Shipping
The devices will be well packaged by carton with Foam or other shock proof materials.
Certification
| BD-8E1-OETH/3ETH 8E1 to optical ethernet converter,3electrical ethernet port,E1 75ohm(BNC connector) or 120ohm(RJ45),power AC 220V or DC 48V |
| BD-8E1-OETH/OP/2ETH 8E1 to optical ethernet converter,2electrical ethernet+1optical ethernet,,E1 75ohm(BNC) or 120ohm(RJ45 connector),power AC 220V or DC 48V |
The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
Your any questions will be responsed within 12hours!
