AC DC Adapter 12V 5A Power Adapter 60W Power Supply 12v 5a Energy Efficiency Level VI
Oupt power range |
12V 3A 24V2.5A 12V5A 12V4A (also have those models for selection) |
The adapter size |
123*55*35mm |
The adapter weight |
360g/pcs |
Input Rated Voltage |
100Vac~240Vac |
Input Frequency Range |
50Hz~60Hz |
Input Current |
less than 0.5A |
Input Inrush Current |
less than 50A |
Efficiency |
80%(MIN)at Rated Voltage |
DC Output Voltage |
12V± 5% (option) |
DC Output Current |
5A (option) |
DC Output Power |
60W (optional) |
Leakage Current |
less than 5mA |
Standbpower |
less than 0.5 |
Ripple and Noise |
less than 120Mv at full road with 20MHz bandwidth |
Turn On Delay Time |
less than 3S (AC:110V and full load) |
Certificates |
CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310 |
Dielectric Voltage |
A IEC320 three pin input---output(FG)3000Vac one minute |
Safety protection |
output voltage protection (150%-180% rated output current) |
output current protection (150%-180% rated output current) | |
short current protection | |
Operating Temperature |
-10°C - +45°C |
Storage Temperature |
-20°C - +40°C |
Safety Standard |
EN60950-1 UL60950-1 ESD (EN61000 3-3) |
CAS (60950 ITE/TE) FCC Part 15 subpart B Class B | |
ISO 9001: 2008 |
1. Used TDK, ST, ON, Rubycon, IR, Toshiba imported materials.
2. 100% of full load burn-in test through the long period of time, effectively guarantee the stability of product quality.
3. Product has overvoltage, overcurrent, overload, under voltage, over temperature protection function.
4. Strong R&D team.
5. The stability of the international quality.
6. The one and only design.
7. All products have passed the UL, cUL, TUV/GS, PSE, SAA, C-Tick, CE, FCC, CB, KC, RoHS certification; the factory passed ISO9001 quality system certification, and has dozens of patents.
1. Any inquiries will be replied within 24 hours;
2. Professional manufacturer , welcome to visit our website;
3. OEM/ODM available:
a) Print logo on our products
b) Customized specification
c) Customized color package box
d) Any your idea on our products,we can help you to design and put it into production;
4. High qulity,fashion design,reasonable&competitive price,fast lead time;
5. After-sale service:
a) All products will have been strictly quality checked in test house before packing;
b) All products will be well packed before shipping;
c) All products have 1 year warranty, and we sure the products will be free from maintenance within warranty period;
6. Faster delivery:
Sample order in stock, and 7-10 days for bulk production;
7. Payment term:
T/T & paypal.
Q1. What are the main products in your company?
A1: Our main products include switching power supply, power adapters, battery chargers.
Q2. Can you supply OEM or ODM service?
A2: We can supply OEM/ODM service of any charger or power adapter absolutely!
Q3. Which shipment available?
A3: Normally, we ship goods by sea,air and express. Special requirement also acceptable.
Q4. Do you inspect the finished products?
A4: Yes. Each product is 200% tested and inspected before package.
Q5: Can we get support if we have our own market position?
A5: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you, to find the best solution for you.
