Specifications
dual band 300M wifi repeater 220VMore range for every WLAN network
2.4GHz & 5GHz Concurrent
up to 300Mbps transmi
dual band 300M wifi repeater 220V with power plug
Certification CE FCC RoHS
• 2.4GHz & 5GHz Concurrent Dual Band technology
• Improves wireless coverage in all WLAN networks
• Provides up to 300Mbps transmission rates
• Complies with IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
• Maximum WLAN security with WPA2, WPA and WEP(128/64)
• Provides one 10/100Mbps Auto-Negotiation Ethernet LAN ports
• Software wizard for simple setup
• Antennas integrated
The wifi repeater 220V is mainly used for providing free WIFI service in big area such as factory , community , street or etc. For example, the normal enhancer can expend distance up to 300 meters away. If there are more repeaters or more bigger power repeater, the range will extended further; the Repeater simultaneously supports 2.4G and 5G wireless network connection, and it can supports 2.4G or 5G transmission speeds of up to 300M. It has 3dBi Antennas providing even better wireless performance, transmission rates, stability technology automatically avoids channel conflicts using its channel selection feature.
300M dual band wifi repeater 220V with power plug
| Ports | 1 x RJ45 | ||||||||||||
| Button | Reset WPS switch | ||||||||||||
| LED | 1 x LAN, 1 x WPSPower 1 x WiFi, 1 x 2.4G 1 x 5G | ||||||||||||
| Chipset | RTL8196C+RTL8192DR | ||||||||||||
| Flash | 32Mbps | ||||||||||||
| SDRAM | 256Mbps | ||||||||||||
| Power Supply | Internal DC5V / 1A | ||||||||||||
| Power Plug | UK/EU/US/China/Australia (option) | ||||||||||||
| Power Consumption | 3.3W | ||||||||||||
| Rated Voltage/ requency /current | 100-240 Va.c. 50/60Hz, 0.1A Max , CLASSⅡ | ||||||||||||
| Standard | IEEE802.11a,IEEE802.11b,IEEE 802.11g, IEEE 802.11n | ||||||||||||
| Modulation | 802.11b: DSSS / BPSK / QPSK / CCK 802.11g: OFDM / DSSS / BPSK / QPSK / CCK 802.11n: OFDM / DSSS / BPSK / QPSK / CCK |
||||||||||||
| Speed | 802.11b : 11 Mbps; 802.11g/a : 54, Mbps 802.11n : 300Mbps |
||||||||||||
| Frequency band | 2.412~2.484 GHz 4915 ~ 5850 MHz | ||||||||||||
| Power | 802.11b: 17dBm ± 2 dBm 802.11g: 14dBm ± 2dBm 802.11n: 14dBm ± 2 dBm |
||||||||||||
| Sensitivity | 802.11b: -83dBm /802.11g: -70dBm / 802.11n: -68dBm | ||||||||||||
| Antenna | 2 x 2dBi Integrated Antennas | ||||||||||||
| Distance | Outdoors 300m, Indoor 100m(According to the actual environment change) | ||||||||||||
| Safely | 64/128-bit WEP, AES,TKIP,WPA,WPA2,802.1x,WPA-PSK,WPA2-PSK,MAC , WDS | ||||||||||||
| Mode | AP Mode / Repeater Mode | ||||||||||||
| Wireless Safely | Wireless MAC address Screening Wireless security function switch 64/128/152-bit WEP WPA-PSK/WPA2-PSK,WPA/WPA2 |
||||||||||||
| DHCP settings | Server, disabled, |
||||||||||||
| System Tools | Traffic statistics System Journal |
||||||||||||
System requirement:
• 110 ~ 230-volt socket
• The WLAN client must support at least the WPA encryption standard.
• WLAN access point and the WLAN client with automatic IP address assignment (DHCP)
• Forwarding of IPv4-based protocols/Address Resolution Protocol
• The network name (SSID) of the WLAN access point must be set to "visible".
• WLAN access point/client according to IEEE 802.11a,n, g, b.
DIMENSIONS
Unit Dimensions 95 x 65 x 50mm (L x W x H)
Weight About 109g
Pack Dimensions 12*12*9.5 CM
Weight About 220g
1 x Dual Band wifi repeater 220v
1 x RJ-45 Networking Cable
1 x Quick Installation
Warranty time for wifi repeater 220v is 12 months.
Items can be replaced during the first month or maintained for the 1st year.
Buyers are only responsible for the return shipping fees for warranty items.
