Help CenterProgressive Stamping Tool/mould/die for Motor Silicon Steel Lamination Core , Motor Stator Rotor Stamping Tool
Related Products
-
Motor Core Stamping Die /progressive Stamping Tool for Motor LaminationUS$ 1 - 2MOQ: 1 Piece -
Stamping Hardware for FurnitureUS$ 1 - 2MOQ: 1 Set
-
Sheet Metal Deep Drawing Mould/tool/die , Die for Deep RdrawingUS$ 1 - 2MOQ: 1 Set
-
Servo Motor Stator Rotor Core Progressive Stamping Tool/mould/die , Silicon Steel LaminationUS$ 1 - 2MOQ: 1 Set
-
Metal Stamping Vacuum Cleaner Spare PartsUS$ 1 - 2MOQ: 1 Set
Specifications
die and tool maker for metal stampingISO9001;2008
14 years experience
Japan high-tech
die and tool maker for metal stamping
Progressive die stamping metal working is suit to high volume mass producion, and because most small stamping parts with high volume, so most progressive stamping parts is small parts.It's widely use in electronic metal parts production, such as sheet contact terminal,connection-peg & all samall stamping parts
The characteristics of the progressive die stamping:
1. Progressive die is a multi-task sequence die, a mold, including punching, bending and stretching process, with high productivity;
2. Progressive die operations with full security;
3. Automation;
4. Can use high-speed punch press for production;
5. Can reduce the numbers of punchs, the plant area, reducing transport and storage of semi-finished products occupy;
Basic requirements of progressive die parts:
1. Smaller parts;
2. High volume;
3. Material thickness is thinner (0.08 to 2.5mm);
4. Material relatively soft;
5. Shape is more complex;
6. Can not too much high precision (utmost is IT10 level).
- The technics & capabilities: progressive die punching, coining, bending swaging
- Materials: strips of Aluminum,copper/ brass,stainless steel, carbon steel, Mild steel,cold roll steel, etc.
- Finish treating: hard anodizing,electroplating of gold/silver/chrome/zinc/nickel plated, tinning, blackening etc.
Advantage of Progressive stamping: rapid production & cheap unit price
disadvantage of Progressive stamping: high cost for progressive die, small volume is unavailable.
Lead time for progressive stamping die & samples in 45days.
COC, Test Report, Rohs, plating report, coating reports, is available !
| product name | stator and rotor lamination |
| material | stainless steel and other metal |
| type | stamping cnc |
| tolerance | accoding to custmer's drawing |
| quality guarantee | 2D and 3D test equipment |
planeness |
around 0.25mm |
| surface | surface treatment |
| brand | JR |
| certificate | iso9001;2008 |
| After-sales Service Provided | Engineers available to service machinery overseas |
specifications and advantage
1)specializing in stamping parts for the shield for more than 14 years
2)the professional engineer and practised workers
3)certificata of ISO 9001;2008
4)our market main in china japan southeast Asia
5)All punch chip use tungsten steel to stamping , The comprehensive service life span of the tool is not less than ten million stamping times. Tungsten steel edge should be grinded within 2 million stampings per time. but any details according to customer reuquires.
6)all price will precision count by my engineer and provide a competitive price for my customer. let all product have good value for money.
7).Consider to convenience,it's simple assembly to our mould.and lower cost for maintenance , special after-sales service and regular maintenance and grind punch chip.
8) we have a experienced design and manufacture team. and it's important to each details for us. we very care the finally and key requires. the good quality and warm service always promise and practice to my customers. meanwhile, we won the affirmation and trust of them.
9)we can provide design drawings 2D and 3D files to my customers. and technology support.
10)we have complete test system and instrument. and Issued quality inspection sheet by Jiarun Quality inspection department .
11)As to the problem in the tooling manufacture process. main department will organize discussion and solution.
12)Competitive quality will be checked anytime.and on-time delivery will be guarantee.
13) Safe packing and some parts of extra free .
Progressive stamping die for motor stator rotor lamination technology
QUALITY:tolerance of spare part is within 0.002mm , tolerance of feeding length is within 0.003-0.005mm , and groundness is within R0.05-0.5,
STATOR ROTOR Technology : stator rotor tolerance is within 0.05mm , concentricity is within 0.05mm ,
SPEED: stamping speed reach 350-400 strokes per minute .
Life: regarding life reaches 1 million to 5 million strokes , while total life from 100million to 200 million ,
Product size : we make stamping die for motor stator rotor from od 3mm to 1000mm ,
Technology: 1.auto interlocking
2. skewing
3.shoulder hole for stator rotor lamination
4.rotation for lamination within 180 degree .
Mould material: tungsten steel ,SKD11 , SAP-60, ASP-9 etc .
product name |
motor core stamping tool |
product material |
Carbon steel, hot-dipped galvanized steel, SECC, stainless steel, aluminum, |
process method |
stamping ,punching ,forming ,bending ,deep drawing |
mould steel |
AISI D2/JIS SKD11/ Din1.2379, ASP-23, SKH-9,etc |
mould type |
progressive stamping die ,transfer die , high speed die ,deep drawing die,punching die,forming die, bending die ,etc |
equipment |
20-220T press maqchine , CNC machine , wire EDM machine ,laser machine ,conputer CNC machine , grinding machine etc |
stamping capacity |
0.1mm to 5mm , longth 3000mm ,width 2000mm 20t-220t |
surface finish |
electroplating, Powder coating, Conversion, Passivation , Anodize, Alodine, |
product |
auto stamping part ,machinerty stamping part ,office appliance stamping part ,computer stamping part ,terminal,connector ,contact ,flat spring ,flat washer, HDMI stamping part , IC chip Lead Frame ,micro SD stamping part, PC terminal,I/O ,USB stamping part,motor stator ,motor rotor ,motor bracket, motor cover ,motor case , electornic stamping part , usb connector , wire EDM part , stamping mould deep drawing die ,etc |
output |
500 sets die , 25sets press machine ,5 sets CNC machine ,20 sets grinder machine ,12 sets SODIC wire EDM ,5sets laser machine , |
market |
Europe ,America,Japan,India ,southeast Asia ,Africa, |
main customer |
Midea, Casic, Canon, Tong-chang electric machinery, Chigo Air conditioning, Mitsubishi Electric, Mitsui High-Tec. |
after-sales service |
guarantee replace , engineers are access for oversea, |
brand |
JR ,OEM ,and other |
certificate |
ISO9001;2008 |
Shenzhen Jiarun Precision Industry Co., Ltd | |
Founded time |
1997 |
Registered Place |
Shenzhen |
Management Mode |
Production and serving model |
Whether offer OEM |
Yes |
Factory Area |
3000m2 |
Main Market |
Every city of China, Southeast Asia, South America, Brazil, India |
Main customer |
Foreign, institutions in China ,Foreign enterprises , |
Company’s licence |
Business License for Legal Person, ISO9001:2008 by SGS |
Company’s address |
Building No.2,North, Yanchuan north Industry district, Songgang Town, |
|
Phone
|
86-0755-23491191 86-0755-23490155 |
Fax |
86-0755-23490062 |
Company Introduction |
We are professional with progressive die, stamping die. Tooling material is good quality. We could provide service all about precision sheet metal stamping dies including stamping die design, stamping die manufacturing, machining and trouble shooting of stamping dies.
|
Main Products |
motor rotor and stator , motor bracket, shredder blade,Computer, mobile phone connector terminals, motor core stamping mould.
|
Main Service |
According to the customer's drawings for mould design ,development and manufacture.
|
Other Features |
1.In-time response on letters, telephone calls or fax
|
Send Inquiry to This Supplier
