Video Conference Camera YC549 YARMEE
YARMEE HD Conference Camera will bring you into an extremely sharp and clear video world, satisfying all kinds of conference deployment with its 3.27 Mega pixels image and up to 1080p/60f quality video output. Camera has broadcasting industry interface of HD-SDI, HDMI, which gives an extremely sharp, clear and superior natural image quality. It provides 20 times optical zoom with powerful PTZ speedy motor.
Features
- Superior High Definition Image
- With a 1/2.8inch HD CMOS sensor and 3.3 millions of effective pixels
- 1920×1080 resolution image
- 20 Times Optical Focusing
- up to 20 times optical and 12 times digital disposition
- Innovative image stabilizing technology integrated
- HD and SD Video Outputs
- Support HD output with 1080p/1080i/720p and SD formats under PAL/NTSC
- HD-SDI interface, provides full digital transmission of reliable high quality video image directly to a distant codec
- With HDMI or YUV/CVBS interface, it gives a full digital high quality resolution.
- RS-232C/RS485 Command Ports
- Pan/Tilt/Zoom functions can be controlled through these serial ports from remote via VISCA port and protocol, for up to
- 7 cameras can be controlled in a daisy chain
- Supports camera preset function
Specifications
| Analog Output | Y/C (4 pin Mini DIN), VBS (Lotus head) |
| Angle of View (H) | 2.9 degrees (tele end ) to 55.4 degrees |
| Backlight | On/Off |
| Built-In Video Output | HDMI |
| CCD Effective Pixels | Approx. 3.27 mega pixels |
| Approx. 3.27 mega pixels | RS-232C (VISCA ) /RS-422 (VISCA ) |
| Dimensions (W x H x D) | 131.5 x 154 x 143mm |
| Effective Pixels | Approx. 3.27 |
| Focal Length | f=4.7 to 94mm (F1.6 to F3.5) |
| Focus System | Auto/Manual |
| Gain | Auto/Manual |
| Image Device | 1/2.8 type CMOS x1 |
| Image Flip | On/Off |
| Imager | CMOS |
| Lens | 20x optical zoom |
| Minimum Illumination | 0.5 lx |
| Minimum Object Distance | 10mm |
| Operating Temperature | -10 degrees to 50°C |
| Pan Angle | -175 to + 175 degrees |
| Pan Speed | 0.25 to 60 degrees/sec |
| Power Consumption | Max. 12W |
| Power Requirements | DC 12 V |
| Preset Positions | 255 positions |
| S/N Ratio | 50 dB |
| Shutter Speed | 1/1 to 1/10000 |
| Signal System | 1080/60P,50P |
| Storage Temperature | -20 degrees to 60°C |
| Synchronization | Internal/External |
| Weight | 2.3 kg |
| White Balance | Auto1 |
Tail-board Interface
Accessories
