CA-217A-K High-temperature Natural Gas Detector
- China Port
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Caatm | |
| Model Number | CA-217A-K | Usage | Other, Fixed Combustible Gas Detector |
Product Description
Specifications
1. Advanced imported catalytic combustion sensor2. Reliable, sensitive and long-life circle
3. Excellent anti-poisoning
CA-217A-K High-temperature Natural Gas Detector
Features:
1. Adopt imported catalytic combustion sensor
2. Able to detect combustible gases under high temperature condition
3. Reliable, sensitive and long performance life
4. Excellent anti-poison performance and powerful anti-interference capability.
5. Automatic zero calibration can avoid long-term zero drift caused by measurement error
6. Concentration signal output
7. Over-current protection, anti-polarity protection
8. 4-20mA standard AC or concentration digital output , able to work with our gas controller
CA-2100A or CA- 2100F
9. Power supply range: DC20V~DC30V
Specifications:
Detection Principle: | Catalytic Combustion | Detection Method: | Diffused |
Applicable Gas: | Combustible Gases | Working Method: | Continuous Working |
Detection Scope: | 0~100%LEL | Respond Time: | <=30S |
Detection Error: | <+-3%LEL | Environment Temperature: | -30°C~+220°C (Sensor) |
Relative Humidity: | 30%-95% | Output Signal: | Concentration Digital Signal / Electric Current Loop Signal |
Output Signal: | Concentration Digital Signal / Electric Current Loop Signal | Working Voltage: | DC20V~DC30V |
Sensor Life Span: | 2 Years (under normal circumstances)
| Transmission Distance: | <=1000m |
Operation Pressure: | (86-106) kPa | Detector Size: | 158*130*93mm |
Explosion-proof Level: | Exd II CT6 | Connection Thread: | 1/2G Inner Thread |
Weight: | 1.5 kg | Communication: | 4-20mA Standard Current |
Performance Standards: | GB3836.1-2000,GB3836.2-2000, GB15322.1-2003
|
|
|
OEM ODM are Welcomed
