Gas water heater heat exchanger
Advantage:
1.Used for chiller
2.PVC case
3.Pure seamless titanium coil
4.Copper tube joint
5.Piston water inlet outlet
Feature :
[1]The internal heat exchanger is made of seamless pure titanium(TA1) which have many advantages,such as corrosion resistance effect , heat exchanging efficiency,non-magnetic, non-toxic and no-scale.
[2]The outer barrel can be made of high strength PVC-U Services Pipes or PP Chemical Pipes. It has the character of chemical stability ,strong corrosion resistance, low efficiency of thermal conductivity ,heat insulation ,energy-saving effect and would not be influenced by environmental factors and medium composition of the pipeline.
[3] Gas water heater heat exchanger has good airtightness without refrigerant leakage after through a professional welding .
[4] Gas water heater heat exchanger has a light weight ,compact atructure and high power with small size .
Application :
Gas water heater heat exchanger are widely used formariculture ,Industrial chiller,laser chiller,plating industries, tank aluminum oxidation, Industrial refrigerator,industry, food & beverage manufacturing , salt manufacturing,metallurgy,pharmacy, ultrasonic and acid tank etc
Technical Data:
| Model | specification | Type | Inlet/Outle | External Dimension | |||||
| Out(inch) | Inlet(inch) | A | B | C | D | E | |||
| WHC-2.0DC | 2.0HP 4.6KW | Single Cooling | 1.5 | 1.5 | 520 | 250 | 400 | 80 | 320 |
| WHC-3.0DC |
3.0HP 6.9KW |
1.5 | 1.5 | 570 | 250 | 450 | 80 | 370 | |
| WHC-4.0DC |
4.0HP 9.3KW |
1.5 | 1.5 | 620 | 250 | 500 | 80 | 420 | |
| WHC-5.0DC |
5.0HP 11.63 |
1.5 | 1.5 | 720 | 250 | 600 | 80 | 520 | |
| WHC-6.0DC |
6.0HP 13.9KW |
1.5 | 1.5 | 820 | 250 | 700 | 80 | 620 | |
| WHC-8.0EC |
8.0HP 18.6KW |
Double Cooling | 1.5 | 1.5 | 1010 | 250 | 900 | 80 | 820 |
| WHC-10.0EC |
10.0HP 23.2KW |
2.0 | 2.0 | 1220 | 250 | 1100 | 90 | 1010 | |
| WHC-12.0SC |
12.0HP 27.9KW |
Triple Cooling | 2.0 | 2.0 | 920 | 315 | 800 | 90 | 710 |
| WHC-15.0SC |
15.0HP 34.8KW |
2.0 | 2.0 | 1120 | 315 | 1000 | 90 | 910 | |
|
Power (HP) Cooling Capacity (KW) Unit:mm | |||||||||
| Refrigerant side (in tube) | Water (in the shell) | |
| Design working pressure | 4.2Mpa | 0.3 Mpa |
| TEMP . range | -50~150°C | -35~45 °C |
| Medium | R22/R407C/R134a/R410a/R600a ... | swimming pool water ,ground water , seawater ,etc . |
| Remarks |
1.Please drain off the water so as to avoid ice freezing to burst shells . 2.Please purge air thoroughly from water system , and cannot exceed the maximum pressure . 3.Keep water quality clean ,suggest to add fliters, and regular cleaning |
|
1.To guarantee constant inprovement of technology , the above parameters shall be changed without further notice .
2.The package will base on the actual situation,if without specific requests .
3.All product can be customziable according to customers' requirements , you just need to send design by MSN,Email ,Fax and other way for us reference .
WH Factory is one of the largest Shell And Tube Heat Exchanger manufacturer in China ,who offer high quality heat exchanger with TA1 Titanium ,TA2 Titanium ,304 SS ,316 L ,copper and other materials, all products can be customized by request .
1). Professional manufacturer, ISO9001-2008
2). More than 6 years’ experiences of manufacturing.
3).Customized solutions and products
4).OEM/Small order accepted
5).Lead time 30 days
6).Tooling in house
7).High quality control
8).Competitive price
Our organisation is contributing huge patrons from the markets of China and other abroad countries such as Singapore, Middle-East, Africa, Malaysia, Europe, Denmark, America, Australia, UK, etc. Apart from these countries, we are also looking forward to entertain our more clients, by offering them our reliable products.
1:Before Service: All the process of Technical Production deportment and Strict Quality Control System. We also can provide the sample for your test quality.
2:Middle Service: Any question, pls feel free to tell us we will solve any doubt.
3:After Service: All the products problems, pls call us and E- mail us at any time, we will reply to you at the shortest time.
Payment Terms
Type of Payment: T/T100% payment in advanced, Paypal, Escrow, Western Union, L/C,etc.
Remark: If you have any question in payment, pls show us so that we will discuss.
Package:Standard export packing .
Shipping Terms:
1.For the sample order: we also use International Express freight: Such as: DHL, TNT, EMS, UPS and so on.
2.If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss in the Contract.
Q1.Are you factory?
A.Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
Q2.May i get your product catalogue?
A.Sure, you are welcome to download the latest catalogue at our web /en,E-book , or contact us directly.
Q3.Are there any discount for the heat exchangers?
A.Yes. Bigger quantity will enjoy lower discount!
Q4.What is the MOQ?
A.We accept loose quantity order,mixed order,any trial orders.
Q5.What information needed if I want a quotation?
A .Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
Q6.Can we visit your company/factory before place the order?
A.Sure.Welcome anytime.
Q7.What's your contact way ?
A.
Att:Ms Joanna Zhang
QQ:1747660290
Wechat:qq1592268859
Email:wh(at)
Cell:86-15356255661
Tel:86-577-86198864
Skype:wzwuhuan
