Heat exchanger price list
- Work Condition:
1)Refrigerant side(In the tube): R22,R134a,R407c,R410a etc.
2)Water side (Between the tube and PP shell):Nature water,pure water or other solution.
Material:
1)Heat transfer Tube: SUS304/316L .
2)Shell: PVC/PP/SS.
- Features:
1)Very good quality , Can be used more than 15 years.
2)SS tube has super strong corrosion proof ability and high intensity.
3) The tube was tested by 4.5MPa pressure to make sure the tube is strong and not leakage .
4)The stainless steel shell was tested by 0.4Mpa water pressure to make sure the water system not leakage .
5)It suitable for water chiller.
- Application:
Heat exchanger is widely used for widely used for freezing industries,such as plating, oxidation, chemical industry, metallurgy,light industry,shipbuilding,heating, pharmaceutical,foodstuff ect, also for leather chiller, injection molding machine chiller, print chiller,PV shoe machine chiller and so on.
- Notice:
1) The data list is our suggested data, We can produce any capacity heat exchangers according customer requirement and design.
2) To guarantee constant inprovement of technology , the parameters shall be changed without further notice.
- Design:
- Specification:
| Model | specification | Type | Inlet/Outlet | External Dimension | |||||
| Outlet(inch) | Inlet(inch) | A | B | C | D | E | |||
| WHB-2.0DC | 2.0HP 4.6KW | Single Cooling | 1.5 | 1.5 | 520 | 250 | 400 | 80 | 320 |
| WHB-3.0DC | 3.0HP 6.9KW |
1.5 | 1.5 | 570 | 250 | 450 | 80 | 370 | |
| WHB-4.0DC | 4.0HP 9.2KW |
1.5 | 1.5 | 620 | 250 | 500 | 80 | 420 | |
| WHB-5.0DC | 5.0HP 11.5KW |
1.5 | 1.5 | 720 | 250 | 600 | 80 | 520 | |
| WHB-6.0DC | 6.0HP 13.8KW |
1.5 | 1.5 | 820 | 250 | 700 | 80 | 620 | |
| WHB-8.0EC | 8.0HP 18.4KW |
Double Cooling | 1.5 | 1.5 | 1010 | 250 | 900 | 80 | 820 |
| WHB-10.0EC | 10.0HP 23.0KW |
2.0 | 2.0 | 1220 | 250 | 1100 | 90 | 1010 | |
| WHB-12.0SC | 12.0HP 27.6KW |
Triple Cooling | 2.0 | 2.0 | 920 | 315 | 800 | 90 | 710 |
| WHB-15.0SC | 15.0HP 34.5KW |
2.0 | 2.0 | 1120 | 315 | 1000 | 90 | 910 | |
|
Power (HP) Cooling Capacity (KW) Unit:mm | |||||||||
WH Factory is one of the largest Shell And Tube Heat Exchanger manufacturer in China ,who offer high quality heat exchanger with TA1 Titanium ,TA2 Titanium ,304 SS ,316 L ,copper and other materials, all products can be customized by request .
1). Professional manufacturer, ISO9001-2008
2). More than 6 years’ experiences of manufacturing.
3).Customized solutions and products
4).OEM/Small order accepted
5).Lead time 30 days
6).Tooling in house
7).High quality control
8).Competitive price
Our organisation is contributing huge patrons from the markets of China and other abroad countries such as Singapore, Middle-East, Africa, Malaysia, Europe, Denmark, America, Australia, UK, etc. Apart from these countries, we are also looking forward to entertain our more clients, by offering them our reliable products.
1:Before Service: All the process of Technical Production deportment and Strict Quality Control System. We also can provide the sample for your test quality.
2:Middle Service: Any question, pls feel free to tell us we will solve any doubt.
3:After Service: All the products problems, pls call us and E- mail us at any time, we will reply to you at the shortest time.
Payment Terms
Type of Payment: T/T100% payment in advanced, Paypal, Escrow, Western Union, L/C,etc.
Remark: If you have any question in payment, pls show us so that we will discuss.
Package:Standard export packing .
Shipping Terms:
1.For the sample order: we also use International Express freight: Such as: DHL, TNT, EMS, UPS and so on.
2.If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss in the Contract.
Q1.Are you factory?
A.Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
Q2.May i get your product catalogue?
A.Sure, you are welcome to download the latest catalogue at our web /en,E-book , or contact us directly.
Q3.Are there any discount for the heat exchangers?
A.Yes. Bigger quantity will enjoy lower discount!
Q4.What is the MOQ?
A.We accept loose quantity order,mixed order,any trial orders.
Q5.What information needed if I want a quotation?
A .Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
Q6.Can we visit your company/factory before place the order?
A.Sure.Welcome anytime.
Q7.What's your contact way ?
A.
|
Att:Ms Joanna Zhang QQ:1747660290 Wechat:qq1592268859 Email:wh(at) Cell:86-15356255661 Tel:86-577-86198864 Skype:wzwuhuan |
