China Yukun ISO/DOT 25Mpa 8pcs type gas tank trailer
gas tank trailer specification |
|
Tube Qty.: 8pcs Service: 20 years Chassis: Three axis Working pressure: 25Mpa
CNG loading volume: 4466Nm3 Total weidht (without chassis): 30772kg Container Dimension: 12192×2438×1400mm s gas tank trailer mainly consists of five parts: trailer, framework, large-cubage seamless steel cylinders, fore safety cabin and back operation cabin. Both ends of the large-cubage seamless steel cylinder have machined outside and inside screw threads. The outside screw threads of both ends connect with the setting flanges. The setting flange is fixed on the supporting plates of both ends of framework by bolts. Screw the end plugs into the inside threads of the cylinder mouth. Connect tube fittings with the end plugs. There set burst disks on the fore cabin, forming safety cabin. There set inlet and outlet tubes, blowdown tubes, thermometer, pressure gauge, quick-connect joint and burst disks fitting on back cabin, forming operation cabin. |
gas tank trailer advantage |
|
gas tank trailer is the gas source of CNG filling substation. It also can transport CNG for the civil gas system. It is an effective supplementary method to the pipe conveyance of gas. Its technology is simple and it occupies small ground. It has the following traits: 1. Import valves with high quality; 2. Advanced manufacture technology, fine manufacture equipment and feasible quality insurance system. 3. Scientific design and logical load bearing structure. This can realize the perfect combination of tractor and trailer. It can assure the safe and steady transportation. 4. It can release various combinations with CNG storage cylinders groups and can satisfy different requirements of customers. 5. Standard corner fittings and framework for container, easy transport. |
CE/DOT/ASME License |
Profession, progress and perfect We are a professional CNG&LNG equipment manufacturer since 2007.Annually around 800 sets CNG storage and transporting equipments including CNG semi trailer and CNG storage cascade, have been manufactured, and half of them have been exported to Asia, Africa, CIS, Europe, Latin America etc. Professional engineers devoted themselves into new products development. Feedbacks from our present and potential clients will be valued and improvements will be made to ensure the CNG storage equipments well fits clients' requirements, so the lighter weight series CNG trailers are born. |
gas tank trailer payment term |
Order's payment: T/T 30% deposit, T/T balance before delivery |
gas tank trailer packing |
|
|
gas tank trailer shipping |
|
Ordering Tips |
If you are interested in our products and want to know more information, please tell us your requirements as follows:
a. The working pressure b. Volume capacity c. Certificates requirements d. Others factors you want to know |
gas tank trailer photos |
|
|
