Help CenterHigh Quality YUKUN Trailer for Sale
US$ 10,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Semi-Trailer
Material:
Steel
Certification:
Other, ISO
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydrogen Production PlantUS$ 100,000 - 800,000MOQ: 1 Set -
High Purity Hydrogen Generating Plant by Water ElectrolysisUS$ 6,000 - 100,000MOQ: 1 Set
-
High Purity Hydrogen Plant by Water ElectrolysisUS$ 6,000 - 100,000MOQ: 1 Set
-
Customized Water Electrolysis Hydrogen PlantUS$ 6,000 - 100,000MOQ: 1 Set
-
Customized Hydrogen Plant With Water ElectrolyzerUS$ 6,000 - 100,000MOQ: 1 Set
Type
Semi-Trailer
Material
Steel
Certification
Other, ISO
Size
12192x2438x1400mm
Max Payload
34320kg
Place of Origin
Henan, China
Brand Name
YUKUN
Model Number
LPA20-32-70
High quality YUKUN trailer for sale
trailer
- CNG long-tube trailer mainly consists of five parts: trailer, framework, large-cubage seamless steel cylinders, fore safety cabin and back operation cabin.
- CNG long-tube trailer is the gas source of CNG filling sub station. It also can transport CNG for the civil gas system. It is an effective supplementary method to the pipe conveyance of gas. Its technology is simple and it occupies small ground. It has the following traits:
1. Import valves with high quality;
2. Advanced manufacture technology, fine manufacture equipment and feasible quality insurance system.
3. Scientific design and logical load bearing structure. This can realize the perfect combination of tractor and trailer. It can assure the safe and steady transportation.
4. It can realize various combinations with CNG storage cylinders groups and can satisfy different requirements of customers.
Main Technical Characteristic List of trailer:
| Main Technical Characteristic List | |||||||
| Item | Data | Item | Data | ||||
| Whole Container |
Whole Equipment Weight | 26620kg | Gas Cylinders |
Working Pressure | 20 MPa | ||
| Filling Weight | 3190kg | Working Temperature | -40°C~60°C | ||||
| Total Weight | 29810kg | Main Body Material | 4130 X | ||||
| Working Pressure | 20 MPa | Water Volume | 2.25 m3 | ||||
| Working Temperature | -40°C~60°C | Cylinder Qty | 8 | ||||
| Filled Medium | CNG | Total Volume of Gas Cylinders | 18 m3 | ||||
| Airtight Test Pressure | 20 MPa | Hydraulic Test Pressure | 33.33 MPa | ||||
| Filling Gas Qty | 4540Nm3 | Outline Sizes (outsidediameter×wall thickness×length) |
Φ 559×16.5(min)×10975 | ||||
| Outline Sizes (length×width×height) |
12192×2438 × 1400mm |
||||||
| Vessel Class | Third | ||||||
| Burst Disk |
Burst Pressure | 30-33 MPa | Whole Trailer Outline sizes (length×width×height) |
12391×2490×2965mm | |||
| Type | LPA20-32-70 | Trailer Type | THT9352TJZ | ||||
| Specification | DN20 mm | Outline Sizes (length×width×height) |
12391×2480×156mm | ||||
| Trailer Weight | 4510kg | Wheelbase | 8450mm | ||||
| Total Weight of Containerand Trailer | 31130kg | Wheelbase of Back Shaft | 1300+1300mm | ||||
| Full-Load Max. Grand Weight | 34320kg | Tyre | 11.00-20 | ||||
