Product Details
Condition: | New | Type: | Other, Piston, VW type | Configuration: | Stationary |
Power Source: | AC Power | Lubrication Style: | Oil-free | Mute: | No |
Place of Origin: | Henan, China | Brand Name: | YUKUN | Model Number: | VW-2.5/4-150 |
Voltage: | 380V | Dimension(L*W*H): | 2200x1600x1800mm | Weight: | 3200KG |
Certification: | ISO9001 2000 | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High pressure oil-free nitorgen compressor
Oil-free nitorgen compressor
- oil-free nitorgen compressor is a device designed specially to compress nitrogen gas for storage;
- oil-free nitorgen compressor is generally reciprocating types with the most common being guided piston/metal diaphragm;
- oil-free nitorgen compressor is used to compressor the gas to enormous pressures,often in excess of 40,000PSI, so that it maybe stored in usable amounts;
- The structure of oil-free nitorgen compressor includes1 stage,2 stage,3 stage,4 stage to meet the client's different demands.
Technical Parameters oil-free nitorgen compressor
Nitrogen compressor Technical Parameter | |||||||
Model | Medium | Capacity (m³/min) | Inlet Pressure (Mpa) | Outlet Pressure (Mpa) | Power (kw) | Overall Dimension (mm) | Weight (kg) |
VW-10/8 | Nitrogen | 10 | Atmospheric | 0.8 | 75 | 2200x1600x1550 | 2200 |
VW-1.5/8-50 | Nitrogen | 1.5 | 0.8 | 5 | 75 | 2300x1600x1750 | 3200 |
VW-2.5/4-150 | Nitrogen | 2.5 | 0.4 | 15 | 110 | 2200x1600x1800 | 3200 |
VW-1.7/6-21 | Nitrogen | 1.7 | 0.6 | 2.1 | 37 | 1780x1450x1550 | 2250 |
VW-2/5-30 | Nitrogen | 2 | 0.5 | 3 | 55 | 2000x1500x1850 | 2150 |
VW-1.3/13-25 | Nitrogen | 1.3 | 1.3 | 2.5 | 30 | 2000x1550x1550 | 2200 |
VW-1.67/8-140 | Nitrogen | 1.67 | 0.8 | 14 | 110 | 2400x1550x1750 | 3100 |
2VW-16.7/0.5-20 | Nitrogen | 16.7 | 0.05 | 2 | 185 | 4200x1600x1600 | 6500 |
2VW-28.5/0.4-20 | Nitrogen | 28.5 | 0.04 | 2 | 280 | 4500x1650x1750 | 7500 |
2VW-6.5/5-40 | Nitrogen | 6.5 | 0.5 | 4 | 220 | 4200x1650x1550 | 6000 |
2VW-2/6-80 | Nitrogen | 2 | 0.6 | 8 | 280 | 4200x1650x1550 | 6000 |
Photos oil-free nitorgen compressor
Why choose our oil-free nitorgen compressor?
Our company is committed to gas equipment development and production within 20 years, specially in oil-free nitorgen compressor, have a world class design team, advanced manufacturing center and focus manufacturing quality.
Customer visit oil-free nitorgen compressor
