Outlet Pressure of 30 Bars Nitrogen Compressor

Outlet Pressure of 30 Bars Nitrogen Compressor photo-1
US$ 10,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Piston
Configuration:
Stationary
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Piston
Configuration Stationary
Power Source AC Power
Lubrication Style Oil-free
Mute No
Place of Origin Henan, China
Brand Name YUKUN
Model Number VW-9.5/30
Voltage 380V
Dimension(L*W*H) 2300X600X1750mm
Weight 2300KG
Certification ISO9001 2000
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

30 bars nitrogen compressor
1.PLC control system.
2.Ethylene,propylene,vinyl chloride, etc.
3.V, sign, symmetry, bad type

   Outlet pressure of 30 bars nitrogen compressor







1. A nitrogen compressor is a device designed specially to compress hydrogen gas for storage.

2. Commercial nitrogen compressor are generally reciprocating types with the most common being guided piston/metal diaphragm

3. Nitrogen compressors are used to compressor the gas to enormous pressures, often in excess of 40,000PSI, so that it maybe stored in usable amounts.

4. The structure of the nitrogen compressor include 1 stage,2 stage,3 stage,4 stage to meet the client’s different demands.



A complete nitrogen compressor system solution consists of the following:
- The Pure nitrogen compressor
- The power conditioning Unit
- The cooling system
- The control and monitoring Unit and the safety system



Accessories:

Crank-shaft, crank-case, cylinder, piston assembly, cross head, connecting bar cross head,, piston ….





Compressor Model VW-9.5/30
Medium Nitrogen
Displacement (m³/min) 9.5
Inlet Pressure (Mpa) Atmospheric
Outlet Pressure (Mpa) 3
Overall Dimension (mm) 2300x600x1750
Power (KW) 90
Weight (KG) 2300



Our nitrogen compressors are particularly suitable for all type of applications and depending on your requirements, we can provide the most suitable nitrogen compressor fitting your needs.



Outlet pressure of 30 bars nitrogen compressor



Outlet pressure of 30 bars nitrogen compressor
