Help CenterTouch Dimmable Led Driver
US$ 2 - 3
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Fontislight
Model Number:
Touch led Driver
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
Fontislight
Model Number
Touch led Driver
Type
Other, Remote Control, Wireless Dimmer
Max. Load Power
96W, 96W
Voltage
Other, 5V/12V/24V
Touch Dimmable led Driver Features:
1 . Mini size: L18.5mm x W11mm x H5mm
2. INPUT VOLTAGE:DC 5-24V
3. MAX OUTPUT VOLTAGE : DC 5-24V
4. MAX Output CURRENT: 4A
5. Low Standby Current Consumption:
a. In 12V: 6mA b. In 24V: 12mA
6. Touch signal can penetrate different medium (such as glass, acrylic, plastic, ceramic), safety to use
7. Wide range Stepless dimming
8. With memory of dimming
9. low EMI
10. Used Power MOSFET 24 AMPERES, 60 VOLTS, RDS(on) = =0.036 (Typ)
Applications:
Applied to Desk lamps , LED lights or crafts
Control Mode:
Initial supply, the light is Off.
1) Click touch (time<550ms)= ON/OFF Switch
First Click touch, Light On
Second Click touch, Light Off
Initial brightness is Maximum brightness.
2) Press touch (time>550ms) = adjustable of brightness (increasing/decreasing brightness)
First press, brightness is increasing; Release, brightness remains same level (if pressing time>3S, brightness would reach to its Max value and keep this intensity)
Second press, brightness is decreasing; release, brightness remains same level (if pressing time>3S, brightness would reach to its Min value and keep this intensity)
3) Click and Press could be used in any time, their functions won’t be interference or restrictions
