Solar Garden Light 12V 120AH AGM Battery
Detail Specifications:
* Model: NP120-12 12V lead acid battery
* Nominal Voltage: 12V lead acid battery
* Rated Capacity: 120Ah(20Hr)
* Dimension: 407*173*236mm
* Approx Weight: 33Kg/pcs 12V lead acid battery
* Packing Detail: 1PCS/CTN 12v lead acid battery
* Loading Quantities: 20'FT=550PCS
Main Features:
1.Low selfdischarge: lower than 3% of rated capacity per month under normal operating temperature
2.ABS case (can be made with flame retardant V0)
3.No memory effect after repetitious usage or discharges
4.Maintenance-free operation
5.Sealed construction and leak proof
6.Safety valve regulated system
7.Operating in any position
8.Deep discharge recovery
9.Wide operating temperature range
Applications:
1.Telephone switchboards, electric equipments, medical equipments, medical instruments and meters
2.Computers and uninterrupted power source (UPS)
3.Power transmission and transformer station, switch control and accident lighting
4.Fire fighting, safety device and alarm monitoring
5.Aviation, spaceflight and power storage
6.Automatic office system
7.Radio communication system
8.Emergency lighting and car and ship starting system
Type :12V series Battery:
1.Standard:German Standard car battery
2.Material : high quality lead-stibonium alloy , AGM separator , pure sulphuric acid add special Additive.
3. Super starting power and long life.
4.Warranty : 12 -15 months
5.Applications:starting battery for cars,buses,and other vehivles.
6.Delivery:within 25 days after receiving deposit.
7.Packing:1pcs/cartons, with or without pallet.
8.OEM: customer's brands & packaging design/dimension for free.
Our advantages :
1.Competitive prices with reliable quality.
2.Adopting high quality PP plastic for battery case, stronger and heatproof.
3.Plates made of high purity lead 99.994-99.996% dry charged battery
4.High quality AGM separator, pure acid
Warnings:
- Matrix series batteries have acid in the case and are fully charged before leaving factory. Do not attempt to dismantle the battery, if accidental skin/eye contact is made with electrolyte, seek medical advice immediately.
- Do not use a new battery with an old one.
- Do not use the battery in sealed container.
- Each battery should have detailed record including the ex-factory date, installing date and using record.
- Check the connection of wire in a fixed interval (once a year). If there is any looseness should tighten the wire.
- Wipe the surface of the battery with soft cloth in a fixed interval (once three months) and always keep the battery clean.
- Avoid using any kind of organic solvents for cleaning the surface of the battery.
Specification:
| Nominal Voltage | 12V | |
| Rated capacity(20 hour rate) | 120AH | |
| Dimensions | Length | 407±1mm(16.02 inches) |
| Width | 173±1mm(6.81inches) | |
| Height | 236±1mm(9.3inches) | |
| Total Height | 240±1mm(9.45 inches) | |
| Weight Approx | 33Kg(72.6lbs) | |
Characteristics
| Capacity 25°C | 10 hour rate(12.00A, 10.80V) | 120.00AH | |
| 5 hour rate(20.00A, 10.50V) | 100.00AH | ||
| 1 hour rate(80.00A, 9.60V) | 80.00AH | ||
| Internal Resistance | Full charged Battery at 25 °C (77°F) |
4.5mΩ | |
| Capacity affected by temperature (20 hour rate) |
40°C(104°F) | 102% | |
| 25°C(77°F) | 100% | ||
| 0°C(32°F) | 85% | ||
| -15°C(5°F) | 65% | ||
| Self-Discharge at 25°C(77°F) |
Capacity after 3 month storage | 91% | |
| Capacity after 6 month storage | 82% | ||
| Capacity after 12 month storage | 64% | ||
| Charge (constant voltage) |
Cycle | Initial Charging Currentless than 36.00A Voltage14.40-15.00 V | |
| Float | Voltage 13.50-13.80V | ||
| Terminal | T10 | ||
Why Choose Us
1.door to door service.
2.low cost raw material with high quality.
3.Independent designer with more than 10 years design experience.
duct with the international market step.
5.our products are exported to Middle East,Europe,Asia,America,south Africa and else.
6.we would like stand with you in same line to open market with long term business.
