wrap on pipe heating cable
- 1000 Piece / Pieces per Month
- shanghai
- T/T
- Ev charging cable 25mm2 --- 70mm2 Orange 1000/1500V Double insulated HV cable electric vehicle shielded cable
- HDMI CABLE
- PTC temperature sensing wire, pvc double insulation.
- UL1285 PVC or silicone rubber spiral heating wire
- PE outer layer black 2.5mm aluminum core or Galvanized steel wire electric fence underground cable
- High quality Copper Conductor Flexible PVC RVVP Control Cable
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | GLL | Model Number: | P40 |
Conductor Material: | Other | Insulation Material: | Other | Jacket: | Other |
Number of Conductors: | Twin Conductor | Application: | freeze free |
Product Description
wrap on pipe heating cable
pipe heating cable
freeze free heating cable
UL,CE,TUV,20w/meter
self temperature 0-10c degree
with plug,convenient
1)Products
Water pipe heating cable
Electric pipe heating cable
Wrap on pipe heating cable
2)Application and Advantages
Water pipe heating cable is designed to prevent frozen condensate pipes in the most extreme conditions,
pipe heating cable is a simple to fit solution which stops frozen, cracked and damaged pipes and ensures
water keeps flowing down to .25C. Once installed Pipe Guard automatically ensures heat is applied to the
pipe when the temperature drops close to freezing, and switches off again to save energy once the pipe has
reached a safe temperature.
PVC insulation pipe heating cable use temperature is -20c degree
Silicon rubber freeze free heating cable use temperature is -60c degree
3)Features
·flexible heating cable,double insulation
·self-temperature control from 0-10c degree
·Ready made unit, simply connect to power supply
·Simple to install, can be quickly zip-tied in place
·Integrated thermostat to ensure energy efficiency
·Monitors pipe temperature, rather than air temperature, to minimise running costs
·Once covered with insulation the entire product is hidden from view, reducing potential damage or vandalism
·Maintenance free and supplied with a 10 year warranty
·Fully earthed for electrical safety
·certificate:TUV,CE,UL,CSA
4)Specification
wrap on pipe heating cable use 16-21w/meter
Number | Length of plug | Length of heating cable | Power | Voltage |
P11 | 1.8meter | 0.9meter | 21w | 120v/230v |
P12 | 1.8meter | 1.8meter | 42w | 120v/230v |
P13 | 1.8meter | 2.7meter | 63w | 120v/230v |
P14 | 1.8meter | 3.6meter | 84w | 120v/230v |
P15 | 1.8meter | 4.5meter | 105w | 120v/230v |
P16 | 1.8meter | 5.2meter | 126w | 120v/230v |
P17 | 1.8meter | 7.2meter | 168w | 120v/230v |
P18 | 1.8meter | 9meter | 210w | 120v/230v |
P19 | 1.8meter | 12meter | 280w | 120v/230v |
P20 | 1.8meter | 18meter | 420w | 120v/230v |
P21 | 1.8meter | 24meter | 560w | 120v/230v |
