Help CenterZDa-L15 Series 60l/min,excavator Hydraulic Control Valve/control Valve Manufacturer
Related Products
-
ZT-L20 Series (80l/min),hydraulic Monoblock Valves/Chinese Control Valve ManufacturerNegotiableMOQ: 100 Pieces -
ZT-L20 Series(80l/min),manual Control Valves/Chinese Control Valve ManufacturerNegotiableMOQ: 100 Pieces
-
ZT-L20 Series(80l/min),hydraulic Control Valve for Tractor/Chinese Control Valve ManufacturerNegotiableMOQ: 100 Pieces
-
ZT-L20 Series(80l/min),hydraulic Lift Valve/Chinese Control Valve ManufacturerNegotiableMOQ: 100 Pieces
-
ZT-L20 Series(80l/min),hydraulic Hand Control Valve/Chinese Control Valve ManufacturerNegotiableMOQ: 100 Pieces
Product Application
Hydraulic monoblock valve is controlling component of the hydraulic system,which is used for adjusting the direction,pressure and flow.The valve is widely used in the hydraulic system of forklift,sanitation vehicle and light loading machines.Comparing the sectional control valve,monoblock valve's biggest advantage is excellent sealing
performance.Also it has a smaller volume，which is suitable for the appilication scene where requires high flow.
Main Features
ZDa: product series;
L: thread connection, the size is G1/2;
15: the diameter, corresponding flow is 60L/min;
F: working pressure, 20mpa;（H: working pressure 31mpa）
2: means 2 working spool;（1~7 spools）
O: Spool funtion(when the valve is in neutral position, the oil is circulated back into the tank)
T: spring return;(W:Ball locking)
Machine material
part: valve body
Material: casting iron（HT300）
Feature：It belongs to a kind of gray iron which has corrosion resistance that is improved over steel in certain environments,it also has good wear-resistance.
Machine material
part: valve spool
Material: compound metal（20CrMnti）
Feature：small machining deformation；
good anti - fatigue performance
Surface processing
Name: electrophoresis
Part: valve body (take ZT-L12 for example)
Feature:Electrophoresis paint is a very environmentally friendly products, it will not have any negative effects on the machinery.Also the paint has good corrosion resistance, protecting the valve body against outside influences which increases the service life of the machine.
Surface processing
Surface processing
Name: blue-white zinc plating treatment.
(72 hours of salt spray test)
Part: bolts and nuts
Feature:excellent anti-corrosion properties，No-Rust
Guarantee.
Surface processing
Name:1. polishing treatment
2. blue-white zinc plating treatment
part: end cover，supporter cover
Feature:excellent anti-corrosion properties
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* One year warranty
* Our experienced engineers would give you the best technical support as they can
Business License
(Original)
Certification & Photos 2
Business License(Duplicate) with Records of Annual Inspection
Certification & Photos 3
Certification & Photos 4
Permit for Opening Bank Account
Certification & Photos 5
Organization Code Certificate
Certification & Photos 6
Custom Clearance Registration Form
Quality is priority. Sheng Jie Hydraulic always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001, ISO40000 certification.
Hydraulic Directional Control Valve Test Table 1
Hydraulic Directional Control Valve Test Table 2
Constant Flow Pump Performance Test Table
Hydraulic Power Unit Test Table
