4wd Truck

Name: 4wd Truck
Brand: Howo
SKU: 100048867
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Capacity (Load):

11 - 20t

Drive Wheel:

4x4

Weifang Xiaer Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Capacity (Load) 11 - 20t

Drive Wheel 4x4

Horsepower Other, 196kw

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Place of Origin Shandong, China

Brand Name Howo

Model Number ZZ2167

Specifications

4wd truck
1. Strong power:196HP.
2. Bigger load capacity:15t
3. Rear single wheel.

4wd truck

MAIN SPECIFICATION FOR MODEL ZZ2167M4627
WEIGHT	CURB WEIGHT(kg)		7780
	RATED PAYLOAD(KG)		15000
	MIN.STEERING DIAMETER (m)		18
	MAX.SPEED (km/h)		76
	MAX.CLIMBING CAPACITY (%)		48
	PARKING GRADIENT(%)		20
	MIN.SPEED(km/h)		20
	SLIDING DISTANCE (At initial speed 50km/h) (m)		950
	BRAKE DISTANCE(COMMENCING 30km/h) (m)		9
	FUEL CONSUMPTION(l/100km)		34
	FUEL TANK CAPACITY (L)		400
FRAME	TYPE	LADER-SHAPED WITH SAME WIDTH
	SECTION OF MAIN LONGN		GROOVE PROFILE 300×80×8mm
	SECTION OF VICE LONGN		GROOVE PROFILE 280×70×5mm
GEARBOX	MODEL		HW15710C
	F GEARSHIFT		10.73;7.98;5.91;4.38;3.29;
			2.45;1.82;1.35;1.00;0.75
	R GEARSHIFT		10.49;2.39
F AXLE	MODEL		6.5T, SPEED RATIO 5.73
REAR AXLE	MODEL		16T, SPEED RATIO 5.73
	DIFFERENTIAL LOCK		YES
TRANSFER CASE	MODEL		ZQC1200
CARGO BOX	DIMENSION
DEMENSION	OVERALL SIZE	LENGTH (mm)	8068
		WIDTH (mm)	2496
		HEIGHT(mm)	3110
	WHEEL BASE (mm)		4600
	WHEEL TREAD(mm)	F	2022
		R	1830
	MIN.GROUND CLEARENCE (mm)		314
	APPROACH ANGLE (°)		32
	DEPARTURE ANGLE (°)		30
	F SUSPENSION (mm)		1578
	R SUSPENSION (mm)		1890
ENGINE	MODEL		WD615.92C
	DISPLACEMENT(L)		9.726
	RATED HP kW/(r/min)		196
	MAX.TORQUE Nm/(r/min)		1100/(1100-1600)
CLUTCH	MODEL/TYPE		AIR ASSIST, DIAMETER 420MM
BRAKE	RATED WORKING PRESSURE (kPa)		784
	SERVICE BRAKE		4-LOOP AIR BRAKE
	SERVICE BRAKE ASSIST		AIR BRAKE
	PARKING BRAKE		SNUFF OUT THE BRAKE
ELECTRICAL EQUIPMENT	VOLT		24V
	ALTERNATOR		1500W
	BATTERY (V/Ah)		24/165 Ah
WHEEL	RIM		8.50-20
	TYRE		12.00-20, 18PR 7 pieces
SUSPENSION	F	NUMBER OF LEAF SPRING	9
	R	NUMBER OF LEAF SPRING	9+6
