Factory Directly Sale Self-Propelled Boom Sprayer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
XIAER
Model Number:
3WZ-700
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2016 Hot Sale Self Propelled High Clearance SprayerNegotiableMOQ: 1 Set -
2016 Hot Sale Self Propelled High Clearance SprayerNegotiableMOQ: 1 Set
-
New Self-Propelled Boom SprayerNegotiableMOQ: 1 Set
-
Tractor Boom SprayerNegotiableMOQ: 1 Set
-
2015 Hot Sale Self Propelled High Clearance SprayerNegotiableMOQ: 1
Place of Origin
Shandong, China
Brand Name
XIAER
Model Number
3WZ-700
Sprayer Type
Pump
Material
Metal
Metal Type
Steel
Usage
Agriculture
| Model | 3WZ-700A |
| overall dimension mm | 3750×1722×2750 |
| Axle distance (mm) | 1566 |
| ground distance (mm) | 810 |
| wheel base (mm) | 1200 |
| Whole machine weight (KG) | 950 |
| Engine Model | changchai diesel engine 3M78 |
| Engine Type | In-line three water-cooling four-stroke diesel engine |
| Discharge capacity (L) | 1.123 |
| Rate power (kW/r/min) | 15.2 KW /2400 |
| Fule tank capacity (L) | 20 |
| Start type | Electric |
| Drive system Type | All-wheel-drive/round synchronous turning |
| Drive system Drive type | Hydraulic power steering |
| Drive system Spindle speed series | HST vice transmission (CVT) + two level (high speed gap) |
| Drive system Speed (km/h) | High speed: 10 or less work on 4 or less |
| Brake (brake and the parking sharing) | Wet multi-disc brake |
| Drive system Tire | 120/90-26(air pressure 250kpa) |
| Battery | 60 |
| Tank capacity (KG) | 700 |
| stirring type | Backflow mixing |
| Sprayer pump model | 50 plunger pump |
| Sprayer pump type | In-line three plunger |
| Sprayer pump Speed r/min | 1200 |
| Sprayer pump water regain (L/min) | 60 |
| Sprayer pump maximum limit pressure (Mpa) | 2.5 |
| working pressure (Mpa) | 1.0~2.2 |
| Boom type | Wings of three full electronic control lance |
| spraye type | Drip-proof fan nozzle |
| sprayer quantity | 16/18 |
| 4(2×2) | |
| work width (m) | 10 |
| Nozzle height from the ground (mm) | 450~1800 |
