Agricultural Spray Machine Sprayer

Name: Agricultural Spray Machine Sprayer
Brand: QINGQUAN
Availability: InStock

FOB Price

US$ 800 - 1,800 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	QINGQUAN	Model Number	3W series
Sprayer Type	Other, Tractor mounted boom sprayer	Feature	Boom sprayer
Condition	New

Packaging Details

Iron case packaging, with spraying booms packaged outside

Product Description

Specifications

Agricultural spray machine sprayer:
1. Fitted power: 12~100hp
2. Case volume: 200~1000L
3. Spraying width: 6~12m

Agricultural spray machine sprayer

----3W series of agricultural boom sprayer

1. Attached with farm tractor

2. Boom style sprayer, with nozzles fitted on the booms

3. Has the mechanism of lifting the booms to a high spraying height.

Parameters:

Spraying with of 6m

Model	Unit	3W-200-6	3W-300-6	3W-400-6
Fitted power	hp	12~15	15~20	18~40
Case volume	L	200	300	400
Spraying width	m	6	6	6
Total weight	kg	80	90	123

Spraying with of 10m

Model	Unit	3W-500-10	3W-700-10	3W-900-10	3W-1000-10
Fitted power	hp	30~45	45~70	55~80	70~100
Case volume	L	500	700	900	1000
Spraying width	m	10	10	10	10
Total weight	kg	240	310	350	380

Spraying with of 12m

Model	Unit	3W-500-12	3W-700-12	3W-900-12	3W-1000-12
Fitted power	hp	30~45	45~70	55~80	70~100
Case volume	L	500	700	900	1000
Spraying width	m	12	12	12	12
Total weight	kg	270	340	380	400

Product photos:

Iron case packaging, spraying booms packaged outside:

Thank you for your attention on us and our products, we sincerely welcome your any question about product details and expecting cooperation with you, pls feel free to contact me:

William Liu

Skype: sdts8798

Tel: 0086-18205348798

E-mail: as showed in the product pictures, or directly chat with me on TM(Trade Manager), or send one message(inquiry) at below, thank you!

About our company:

Shandong Tiansheng Machinery Co., Ltd, a private enterprise specializing in developing, producing and selling the agricultural machinery since establishment year of 2005, with mature R&D, producing and exporting experience. acquiring fine reputation about products and service from clients of worldwide. Main products include: Qingquan brand disc harrow, disc plow, disc blade, mouldboard(share, furrow) plow, rotary tiller(rotavator), planter(seeder), harvester, thresher, cultivator, subsoiler, leveller, ridger, hole digger(earth auger), fertilizer distributor(spreader), farm trailer, mower, hay raker , and other farm machineries(farm tractors etc.)

We are assessed supplier of Alibaba, and has passed BV(Bureau Veritas) certification(Assessment report is avaible to be downloaded and viewed in our Company Profile):

Company Profile

Shandong Tiansheng Machinery Co., Ltd.

Shandong Tiansheng Agricultural Machinery Co., Ltd , a private enterprise specializing in developing, selling and producing the agricultural machinery, is the drafter of the industry standard of the disc harrow and share plough in China,which is China's outstanding agricultural expert, we have self-supported import and export right, In July 2006, Our company has passed ISO9001:2000 quality management system certification. Our company is located in High and New Technology Development Zone Yucheng City, Shandong Province, Covers an area of 32000 square meters including more than 15000 square meters standard workshops.There are 120 sets of various machinery equipments,158 employees and 66 engineers and technicians. We mainly produce with the brand of qingquan:disc harrow,disc plough,share plow, rotary tiller,potato planter,potato harvester,cultivator,subsoiler,seeder,box blade,ridger,ditcher,stubble cleaner,hole digger, fertilizer spreader, farming trailers and so on. We can yearly produce 20,000 sets of complete machines for each specification and 300,000 pcs of plough discs and harrow discs. They are exported to more than 66 countries and regions, such as USA, France, Germany, Russia, Switzerland, Zimbabwe, Ukraine, Nigeria, South America . We will convey the value of Chinese agricultural machinery for the mission, to be world-renowned manufacturer of vision, cooperate sincerely with the partners at home and abroad making bright future.
