Excavator

Name: Excavator
Brand: Chnaglin
SKU: 100043889
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Chnaglin

Model Number:

sc70

Weifang Xiaer Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Chnaglin

Model Number sc70

Condition New

Excavator

Detailed Product Description
MODEL	SC70
ENGINE
Model	CUMMINS B3.3
Type	Water-cooled,4-cycle, direct injection
Flywheel power(kw/rpm)	45/2200
UNDERCARRIAGE
No.of carrier rollers	1 each side
No. of track rollers	5 each side
No. of shoes	38 each side
HYDRAULIC SYSTEM
Hydraulic Pump (Toshiba)
Type	Variable displacement piston pump
Maximum flow(L/min)	1×154
Setting pressure(Mpa)(kg/cm2)	30(300)
Valve(Toshiba)
Type	IB18
Control Method	Full hydraulic Joystick
Travel Motor(KYB)	Axial Piston Motor (Brake valve)x2
Swing motor(Kavasaki)	Axial Piston Motor(Safe valve)x1
HYDRAULIC CYLINDERS(KYB)
No. of cylinder - Bore x Rod Diameter
Boom(mm)	115x65
Arm(mm)	100x60
Bucket(mm)	90x55
Blade(mm)	120x70
ATTACHMENT
Standard Machine
0.28m3 Standard Bucket 0.20m3 Small Buck
WORKING RANGE
Operating weight(kg)	6800
O max. Digging height	7165mm
P max. Dumping height	5068mm
Q max. Digging depth	4038mm
R max. Vertical wall digging depth	3505mm
T max. Digging reach	6333mm
U max. Digging reach at ground level	6182mm
Max. bucket digging force	52.7KN
Swing speed(rpm)	11.2
Travel speed(km/h)	L:2.7 H:5.1
Average Group Press(Kpa)	30
DIMENSION
A Overall length	6103mm
B Overall width	2198mm
C Overall height(to top of boom)	2515mm
D Overall height(to top of cab)	2630mm
F Min ground clearance	3815mm
G Tail swing radius	1755mm
H Length of track on ground	2130mm
J Track length	2757mm
K Track gauge	1700mm
L Width of crawler	2150mm
M Width of track	450mm
