CE Mini Excavator
SPECIFCATIONS
Japan made engine YANMAR 4TNV94
Ppower 38.1KW/2200RPM, a guarantee of super power
In conformity with the EU III emission control regulations
Imported hydraulic system with dual pump and dual circuit, stable work performance
Guarantee for 3 yrs under normal use and maintenance
Imported hydraulic components, South Korea made main pump, multi-circuit valve, swing motor, walking motor, Japan made or South Korea made gasoline tank
On-line digital monitoring and control system
GPS satellite position and remote diagnose system(optional)
Cold&warm air conditioner supply under different kinds of weather conditions
Light and handy pilot operating system
Steel pedrail
SPECIFCATIONS
Operating weight |
5.900 KG |
Travel speed |
4.0/2.5km/h |
Bucket Capacity |
0.20m3(SAE) |
Tracking force |
49.3kn |
Engine power |
45KW |
gradeability |
30°(58%) |
Swing speed |
10RPM |
Bucket digging force |
36.7 kn |
Ground Pressure |
34KPa |
Arm digging force |
26.1 kn |
Dimensions
Boom Length |
2.650 mm |
Arm Length |
1.600 mm |
Upperstructure width |
1.500 mm |
Undercarriage width |
1.630 mm |
Overall Height with cabinet |
2.455 mm |
Rear swing radius |
1.600 mm |
Clearance under counter weight |
585 mm |
Tumbler Distance |
1.710 mm |
Ground clearance |
350 mm |
Overall length for transportation |
5.560 mm |
working range
MAX digging radius |
6.245 mm |
MAX digging radius at ground lever |
6.100 mm |
MAX digging depth |
3.875 mm |
MAX vertical wall digging depth |
2.900 mm |
MAX digging height |
5.785 mm |
MAX dumping height |
4.095 mm |
MAX dozer cutting depth |
595 mm |
MAX dozer lifting height |
300 mm |
