High Quality 35HP 4WD Mini Tractor With Front Loader

High Quality 35HP 4WD Mini Tractor With Front Loader thumbnail-1
High Quality 35HP 4WD Mini Tractor With Front Loader thumbnail-2
High Quality 35HP 4WD Mini Tractor With Front Loader thumbnail-3
High Quality 35HP 4WD Mini Tractor With Front Loader photo-1
High Quality 35HP 4WD Mini Tractor With Front Loader photo-2
High Quality 35HP 4WD Mini Tractor With Front Loader photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Weifang Xiaer Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Brand Name Luzhong Tractor
Model Number LZ354
Place of Origin Shandong, China

Luzhong tractor

Luzhong 35hp Tractor Main Technical Parameters
Model  LZ350 LZ354
Drive type  4*2 4*4
Engine  JD3100
Type of the engine
Displacement (L) 2.59
Capacity of fuel tank(L/Gal) 38(8.36)
Engine power at rated speed(KW/rpm)
PTO power at rated speed (KW/rpm)
Clutch  Dry, Dual-stage clutch
PTO speed  540/1000 rpm
Gear shift  8+2/8+8/16+4
Way of gear shifting  Sleeve meshing
Hydraulic output flux (L/min) 21
Three point linkage
Category of 3-point link  Category 1, upper lifting point, joining
Lifting force (at point of 610mm) KN 6.4
Lifting force (orgin) KN 12
Overall size(L*W*H)mm 3880*1480*1540
Wheelbase(mm) 1900 1924
The smallest clearance  360 280
Front tires  6.00-16 6.50-16
Rear tires  11.2-24


Model

LZ354

Type

4WD    Wheeled Type

(mm)Dimensions of Tractor

Length (to front ballast)

3835

Width

1620

Height (to the exhaust vent)

2220

Tread

Front Wheel

1280

Rear Wheel

1300 Fixed or 1200~1500 Adjusted

Axle Base

2030

Min.Ground Clearance

325

Structure weight (kg)

1665

Ballast weight
(kg)

Front ballast

140

Rear ballast

200

Rated traction force (kg)

1100

Engine

Model

3105/490

Type

Vertical,4-Cylinder,Water Cooled and 4-stroke

Rated Power(kw)

29.4

Rated speed (r/min)

2400

Fuel

Diesel

Tyre

Front Wheel

8.3-20

Rear Wheel

12.4-28

Clutch

Dual-stage clutch

Steering

power steering

Transmission Type

8+4  or  8+8 with shuttle gearshift or (8+4)×2 with creeper shift

Suspension Type

3-point links

PTO

Type and Rev

Semi-independent Type 540/1000

Spline Size

F35 Rectangle Spline with 6 teeth....
