High Speed Aluminum CNC Milling Drilling Machine 3 Axis Processing Center
- Qingdao
- T/T Credit Card
You May Like
-
Aluminum Industry CNC Milling Drilling Machine
-
Parker Machine Aluminum Alloy CNC Milling Machine With High Precision
-
Four Axis Machining Center, CNC Drilling And Milling Machining Center (DMCC6)
-
DMCC3H Aluminium Profile CNC Drilling and Milling Machine for Window Door Curtain Wall Processing
-
4-Axis CNC Horizontal Aluminium Machining Center for Drilling Milling Boring
-
4-Axis CNC Aluminium Drilling Milling Boring Machining Center for Window Door Curtain Wall
Product Details
| Brand Name | PARKER | Place of Origin | Shandong, China | |
| Model Number | DMCC3H | Type | Vertical | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 1 Year | Weight | 3000kg | |
| Dimension(L*W*H) | 4525x1630x1900 | Voltage | 380V/50Hz | |
| Condition | New | Power(W) | 6kw |
Product Description
Aluminum CNC milling drilling machine
Feature
1. The machine is suitable for processing varieties of holes and slots for diversified aluminum profile.
2. It adopts high-precision linear guide pair, ball screw, pinion and rack and imported servo motor to ensure the machine runs steadily with high precision.
3. It adopts Italian HSD Brand high-speed motorized spindle to ensure the machine runs steadily with lower noise and better cutting ability.
4.It adopts vegetable oil microcrystalline cooling system to improve the tool life without poison and pollution.
5.The rotary workbench can change the position among -90°、0° and +90° arbitrarily, one time clamping can finish milling for three sides.
6.It adopts PA control system from Germany, intelligent CNC control system and straightforward human-computer interface make the operation much more convenient and efficient.
Parameter
X axis Stroke: 3200mm
Y axis Stroke: 300mm
Z axis Stroke: 200mm
X axis Speed: 0～140m/min
Y axis Speed: 0～75m/min
Z axis Speed: 0～75m/min
Spindle speed and Power: 18000rpm/3kw
Work table position: -90°、0°、+90°
Cutter size: ER25-Ф8
Air Pressure: 0.5～0.8MPa
Voltage: 380V/50Hz
Power: 6kw
Cutter cooling: Auto spraying and cooling
Processing dimension: （W×H×L）：160×160×3200mm
Processing character: Can process three sides of profile per time loading profile
Dimension（L×W×H): 4525×1630×1900mm
Aluminum profile CNC Machining center video link
Parker Machinery Co.,ltd
/watch?v=hYwmgxfRge4
DMCC3H Axis Aluminum Profile CNC machining center
/watch?v=d5NHjVsZ-C4
4 axis machining center DMCC6
/watch?v=gjHc4hsMFQA
DMCC82 4 AXIS milling and drilling machine
/watch?v=tHN0X175AHQ
CPA3 Three Axis CNC Machining Center
/watch?v=kzr9v6RhlpI
DMCC3 3 Axis CNC Machining center
/watch?v=lEbIDLdHnok&index=20
DMCC3S 3 Axis milling and drilling machine for Aluminum
/watch?v=EOR14SR7NVk&index=21
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
Products Name with link
91.8% Response Rate
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
