450/750V KVVP,ZR-KVVP2 copper wire braided shield wire
Operating Characteristics
1,Long-term allowable operating temperature of cable conductor ≤70°C
2,The laying temperature should over 0℃, Permissible bending radius of cable:for unarmored cable and screened flexible cable, should be no less than 6 times of cable diameter ; for armored cable and copper tape shielded cable, should be no less than 12 times of cable diameter
3,The product is applicable for controlling, monitoring circuit and transmission lines.
Standards
GB/T9330.2-2008
Technical parameters
(1)We can produce
a.All type of flame retardant cable Flame
Retardant power cable is marked by “ZA”,“ZB”or “ZC”
Added before the above types.
b.We also can produce low-halogen low-smoke and LSOH flame retardant cable.
LHLS is marked by DDZA,DDZB or DDZC added before original type
Zero-halogen low-smoke is marked by WDZA,WDZB or WDZC added before original type
c.Waterproof, gopher protection, anti-termite, low toxicity cable.
d.Prefabricated branched cable.
(2) To armor the single-core cable,we adopt non-magnetic material or construction for reducing magnetic loss.Only D.C. Voltage is suitable for single-core armored cable(steel tape or steel wire armored cable)
1. 22 years production experience .
2high-end Machinery and equipment for high quality cable .
3.manufacture various of cable :power cable,control cable,abc cable,submersible oil pump cable,rubber cable,elevator cable,electric cable...
4. products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV:
system ceryification:ISO9001,ISO14001,OHSAS18001
5.our product sells all over the world and has the good reputation.
fessional teamwork service for you actively.
7.quick solution and long time online time waiting for your inquiry.
8.rapid delivery and feedback.
9.we can do that you except
Testing Machine
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's reques
Delivery Detail: 10 days after receiving 30% T/T or L/C
