Jiaxing Weiying Industry And Trade Co., Ltd., established in 2004, is a professional manufacturer dedicated to producing high-quality hydraulic equipment. Our WY 6490J 28kg Dual Pitches Low Profile Hydraulic Jack is engineered to meet the demands of modern automotive repair and industrial applications. With a 2-ton load capacity, an ultra-low minimum height of 140mm, and a maximum lifting height of 400mm, this jack offers exceptional versatility for low-clearance vehicles and heavy-duty tasks. Its dual-pitch design provides both rapid lifting and precise control, enhancing efficiency and safety in your workshop.
Key Features & Technical Specifications
- Dual Pitches Design: Two different lifting speeds – a fast stroke for initial lift and a slow stroke for precise positioning, reducing operator effort and improving accuracy.
- Ultra-Low Profile: Minimum height of 140mm allows easy access under sports cars, low-slung sedans, and other vehicles with limited ground clearance.
- Robust Construction: Made from high-strength alloy steel, ensuring durability and long service life even under frequent heavy use.
- Lightweight Yet Powerful: Weighing only 28kg, it is portable and easy to move around the workshop without sacrificing lifting capacity.
- Safety Features: Equipped with a built-in overload safety valve and a sturdy base for stable operation, protecting both the operator and the equipment.
- Ergonomic Handle: Designed for comfortable grip and efficient pumping, reducing fatigue during repetitive use.
| Parameter | Value |
| Model | WY 6490J |
| Load Capacity | 2T (4400 lbs) |
| Minimum Height | 140 mm |
| Maximum Height | 400 mm |
| Net Weight | 28 kg |
| Lifting Range | 260 mm |
| Material | High-strength alloy steel |
| Color | Red/Black (customizable) |
The dual-pitch mechanism is a standout feature. In the first stage, the jack lifts quickly to contact the vehicle, saving time. The second stage offers a slower, more controlled lift, allowing the operator to precisely position the load. This design minimizes the risk of over-lifting and provides a smoother experience compared to conventional single-speed jacks.
The low minimum height of 140mm is ideal for today's low-profile vehicles, such as sports cars and modified sedans. It easily slides under most chassis without the need for additional ramps or adapters. Combined with a maximum height of 400mm, it covers a wide range of lifting tasks, from tire changes to undercarriage inspections.
Durability is ensured by the high-strength alloy steel construction and a robust hydraulic system. The jack undergoes rigorous quality testing to meet industrial standards. Its lightweight design (28kg) makes it a practical choice for mechanics who need a mobile yet powerful tool.
Benefits for Your Workshop
- Enhanced Productivity: The dual-pitch system reduces lifting time while maintaining precision, allowing faster turnaround on jobs.
- Versatile Use: Suitable for both passenger cars and light trucks within the 2-ton range, as well as industrial equipment requiring low clearance.
- Reduced Physical Strain: Ergonomic handle and efficient hydraulics minimize operator fatigue.
- Long-Term Reliability: Quality materials and safety features ensure a low total cost of ownership.
Company Commitment & Trustworthiness
As a manufacturer with over 20 years of experience, Jiaxing Weiying Industry And Trade Co., Ltd. operates a 10,000-30,000 square meter factory with 51-100 skilled employees. Our annual export value of US$1-1.5 million reflects the trust from clients across North America, South America, Europe, Asia, and the Middle East. We adhere to strict quality management systems, including ISO9001 certification, ensuring every jack meets rigorous performance criteria. Our products are shipped from major ports like Shanghai, Ningbo, Guangzhou, and Qingdao, offering flexible logistics options.
We stand behind the WY 6490J with comprehensive after-sales support and customization services. Contact us today to request a quote or discuss your specific requirements. Choose a jack that combines innovation, reliability, and value – choose Weiying.
Frequently Asked Questions
1. What vehicles is this jack suitable for?
The WY 6490J is designed for low-profile vehicles such as sports cars, sedans, and coupes with a minimum ground clearance of 140mm. It can also handle most standard passenger cars and light trucks within the 2-ton load capacity.
2. How does the dual-pitch feature work?
The jack has two pumping stages: a fast stroke (high volume) for quickly raising the saddle to contact the vehicle, and a slow stroke (low volume) for precise, controlled lifting. This allows both speed and accuracy.
3. Is the jack portable?
Yes, it weighs only 28kg, making it easy to move around the workshop or transport between job sites. The handle folds for compact storage.
4. What safety features are included?
An overload safety valve prevents lifting beyond the 2T capacity. The stable base and large saddle provide good load distribution. Additionally, the dual-pitch design reduces the risk of sudden movement.
5. Does it come with a warranty?
Warranty terms are available upon request. We offer standard coverage for manufacturing defects and can customize warranty periods according to order volume.
6. Can I customize the color or logo?
Yes, we offer customization services for bulk orders. Contact us for details on color options, logo printing, and packaging requirements.
7. What certifications does your factory hold?
Our factory is ISO9001 certified, and we comply with international quality standards. Additional certifications such as CE are available upon request depending on your market.
8. How should I maintain the hydraulic jack?
Regularly check hydraulic oil level, keep the ram clean, and lubricate moving parts. Do not exceed the rated capacity. Store in a dry environment. Please refer to the user manual for detailed maintenance instructions.
