Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000–3,000 m² factory and 101–200 employees, proudly presents our Chemical Plant Flooring FRP Pultruded Grating designed for exceptional acid resistance and oil proof performance. As a reliable supplier exporting US$2.5–5 million annually to markets across North America, South America, Europe, Africa, and Asia, we combine advanced pultrusion technology with rigorous quality control to deliver gratings that withstand harsh chemical environments. Our product is the ideal choice for platforms, walkways, and trench covers in chemical plants, refineries, and offshore oil facilities where safety and durability are paramount.
This grating is manufactured using high-quality fiberglass and polyester or vinyl ester resin, offering outstanding corrosion resistance against acids, alkalis, and oil. The pultruded profile ensures consistent strength and stiffness, while the anti-slip surface provides secure footing even in wet or oily conditions. Below are key technical specifications and features:
| Parameter | Specification |
| Material | E-glass / C-glass with vinyl ester or polyester resin |
| Standard Panel Size | 1220mm × 3660mm (customizable) |
| Thickness Options | 25mm, 30mm, 38mm, 50mm |
| Grid Spacing | 38×38mm / 50×50mm / 25×100mm |
| Load Capacity | Up to 2000 kg/m² (depending on span) |
| Surface Treatment | Anti-slip grit coating (silica sand or aluminum oxide) |
| Color | Yellow, green, gray, red, or custom |
| Operating Temperature | -40°C to +80°C (standard resin) |
Key Features & Benefits:
- Superior Acid & Oil Resistance: The vinyl ester resin matrix provides excellent protection against 30% sulfuric acid, 20% hydrochloric acid, and many hydrocarbons, extending service life significantly compared to steel.
- Lightweight yet Strong: Only 1/4 the weight of steel grating, making installation and handling easier and safer, while the pultruded fibers deliver high tensile strength.
- Non-Conductive & Non-Magnetic: Ideal for electrical safety in chemical plants and refineries where sparks or static discharge must be avoided.
- Low Maintenance: No painting, no rust, no corrosion—just simple cleaning with water or mild detergent.
- Anti-Slip Safety: Grit top surface exceeds standard slip resistance requirements, reducing accident risk in wet or oily environments.
- Customizable Dimensions: Panels can be cut to exact size, and additional features like raised edges, rounded corners, or clip-on attachments are available upon request.
- Long Service Life: With proper resin selection, the grating can last 20+ years in moderate chemical environments, offering excellent return on investment.
Our FRP pultruded grating is widely used in chemical plant flooring, oil platform walkways, battery rooms, waste treatment facilities, and food processing areas. The product is manufactured under strict quality control procedures, and each batch is tested for dimensional accuracy and load performance. We have shipped over 10,000 square meters of grating to clients in 20+ countries, with a 98% on-time delivery rate.
As a manufacturer with more than 5 years of specialized experience, Hengshui Ruibin New Materials LLC ensures consistent quality and competitive pricing. Our factory is equipped with multiple pultrusion lines, and we maintain a dedicated quality control team. With an annual export value of US$2.5–5 million, we have built long-term partnerships with distributors and end-users worldwide. We can provide third-party testing reports upon request, and our lead time for standard orders is 15–20 working days.
FAQ
Q: What is the maximum load capacity of your FRP grating?
A: The load capacity depends on the span, thickness, and grid pattern. For example, a 38mm thick grating with 38×38mm grid can support over 2000 kg/m² on a 600mm span. We provide load tables for each configuration.
Q: Can you customize the color and size?
A: Yes, we offer a variety of standard colors (yellow, green, gray, etc.) and can match custom RAL colors. Panel sizes can be cut to your exact dimensions. Minimum order quantity for custom colors may apply.
Q: Is your grating suitable for outdoor use?
A: Absolutely. The UV-resistant coating (optional) and corrosion-resistant resin make it ideal for outdoor platforms exposed to sunlight and rain. We recommend vinyl ester resin for maximum UV and chemical resistance.
Q: How do I install the grating?
A: Installation typically uses clip-on fasteners or hold-down brackets. We can provide mounting hardware and installation instructions. The lightweight nature allows easy handling without heavy equipment.
Q: What certificates do you have?
A: Our products are manufactured in compliance with international standards such as ASTM D3841 and ISO 9001 (certification available upon request). We also provide material test reports and load test certificates as needed.
Q: How long is the delivery time?
A: For standard sizes and colors, delivery takes 15–20 working days. Custom orders require 20–30 working days. We ship from Port of Tianjin or Port of Qingdao.
Q: Can I get a sample before ordering?
A: Yes, we offer free samples of 200×200mm or 300×300mm. You just need to cover the shipping cost. Samples are usually sent within 3 days.
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ is 50 square meters for standard products. For less quantity, please contact us to discuss availability.
