Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019, specializes in high-performance bridge components. Our Rubber Bearing for Bridge Expansion Joints Accommodating 50mm Movement is engineered to provide reliable support and accommodate thermal expansion, contraction, and structural movements in bridges. With a factory spanning 1,000–3,000 square meters and a skilled team of 101–200 employees, we deliver products that meet global standards. This bearing is a cost-effective solution for bridges requiring precise 50mm displacement control, ensuring long service life and minimal maintenance.
Our rubber bearings are produced using premium natural rubber or neoprene compounds, reinforced with internal steel plates for enhanced load-bearing capacity. They are designed to absorb vibrations, reduce noise, and protect bridge structures from seismic forces. Whether used in highway bridges, railway overpasses, or pedestrian walkways, this bearing offers exceptional durability and performance.
Key Features & Technical Specifications
- Precise 50mm Movement Capacity: Accommodates thermal expansion and contraction up to 50mm without compromising structural integrity.
- High Load Bearing: Customizable load capacity up to 5000 kN, suitable for heavy traffic bridges.
- Excellent Elasticity: Returns to original shape after compression, ensuring consistent performance.
- Weather & Ozone Resistance: Neoprene option offers superior resistance to UV, ozone, and extreme temperatures.
- Easy Installation: Designed for simple placement between girder and abutment; no special tools required.
- Low Maintenance: No moving parts, eliminating lubrication and regular inspection needs.
- Seismic Damping: Absorbs and dissipates energy from earthquakes, reducing stress on bridge structures.
| Parameter | Value |
|---|---|
| Movement Capacity | 50 mm |
| Material Options | Natural Rubber, Neoprene, or custom blends |
| Hardness (Shore A) | 60 ± 5 |
| Operating Temperature | -40°C to +70°C |
| Max Load (customizable) | up to 5000 kN |
| Dimensions | Customized per project requirements |
| Reinforcement | Internal steel plates (optional) |
Our bearings are manufactured under strict quality control processes. Each unit is tested for compression set, shear modulus, and bond strength. The design follows internationally accepted principles for elastomeric bearings, ensuring reliable performance over decades of service.
Why Choose Hengshui Ruibin?
As a manufacturer with annual export value of US$2.5–5 million, we serve clients across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our products are shipped from Port of Tianjin and Port of Qingdao with reliable logistics. We offer customized solutions, including special dimensions, different rubber compounds, and additional reinforcement. Our team of 101–200 employees ensures consistent quality and timely delivery. With a factory size of 1,000–3,000 square meters, we maintain competitive pricing without compromising on quality.
Trusted by bridge engineers worldwide, our rubber bearings have been used in numerous infrastructure projects. We provide technical support, installation guidance, and after-sales service. Contact us today to discuss your specific bridge expansion joint requirements and get a tailored quotation.
Frequently Asked Questions (FAQ)
1. What is the lifespan of this rubber bearing?
Typically, our bearings last 20–30 years under normal service conditions, depending on environmental factors and load cycles. The neoprene variant offers enhanced longevity in harsh climates.
2. Can the bearing accommodate more than 50mm movement?
This model is specifically designed for 50mm movement. For larger displacements, we can customize bearings with different dimensions and reinforcement. Contact us for special requirements.
3. Is installation difficult?
No, installation is straightforward. The bearing is placed between the bridge girder and abutment. No special equipment is needed. We provide installation guidelines with each order.
4. What certifications do you have?
Our products undergo internal quality testing and meet relevant industry standards. Specific certifications are available upon request. We can also provide third-party test reports if needed.
5. What is the minimum order quantity?
We accept both small and large orders. For standard sizes, MOQ is 10 pieces. Custom orders may have different MOQ – please inquire.
6. How do you ensure quality?
Each batch is tested for hardness, compression set, and adhesion. We follow strict quality control procedures from raw material selection to final inspection. Samples can be sent for evaluation.
7. Can you provide custom rubber compounds?
Yes, we can formulate rubber compounds to meet specific requirements such as oil resistance, low temperature flexibility, or higher hardness. Contact our technical team.
8. What is the typical lead time?
For standard sizes, lead time is 15–20 working days. Custom orders may take 25–30 working days. Expedited shipping is available.
