Home > Chemicals > Fiberglass Products > Other Fiberglass Products > Corrosion Resistant FRP U Channel 6mm Thick ISO 9001 Compliant Pultrusion Profile for Industrial Trench

Corrosion Resistant FRP U Channel 6mm Thick ISO 9001 Compliant Pultrusion Profile for Industrial Trench

Product Spotlights

ISO 9001 compliant FRP U channel, 6mm thick, offers superior corrosion resistance and lightweight strength for industrial trench applications. Customizable length, non-conductive, low maintenance, and easy to install. Backed by a reliable manufacturer with global export experience and strict quality control. Ideal for chemical, wastewater, and marine environments.

Negotiable MOQ: 300 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Fiberglass Reinforced Plastic (FRP)

Thickness:

6mm

Type:

U Channel

Contact Supplier Request Quote Chat Now

Hengshui Ruibin New Materials LLC

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Fiberglass Reinforced Plastic (FRP)

Thickness 6mm

Type U Channel

Corrosion Resistance Yes

Standard ISO 9001 Compliant

Application Industrial Trench, Cable Tray, Support Structure

Color Customizable (e.g., yellow, gray, green)

Length Customizable (up to 6m per piece)

Surface Finish Smooth, UV-resistant gel coat optional

Fire Resistance Class 1 (optional upon request)

Hengshui Ruibin New Materials LLC is a professional manufacturer specializing in the production of high-quality FRP pultruded profiles. Our Corrosion Resistant FRP U Channel 6mm Thick is designed for demanding industrial environments, particularly for trench support, cable management, and structural framing. Engineered with advanced pultrusion technology and compliant with ISO 9001 standards, this profile offers exceptional durability, lightweight handling, and long-term cost savings. Whether you need reliable performance in chemical plants, wastewater treatment facilities, or marine applications, our U channel provides a robust solution that outperforms traditional metal alternatives.

Key Features & Technical Specifications

Superior Corrosion Resistance: The FRP material is inherently resistant to acids, alkalis, salts, and moisture, making it ideal for corrosive atmospheres where metal would rust or degrade.
High Strength-to-Weight Ratio: At only one-quarter the weight of steel, our U channel reduces installation labor and structural load without sacrificing strength.
Non-Conductive & Non-Magnetic: Safe for use in electrical environments; ideal for cable trays and trench covers near sensitive equipment.
Lightweight & Easy to Cut: Can be field-cut with standard tools, saving time and customization costs.
ISO 9001 Compliant Manufacturing: Every profile is produced under strict quality control processes, ensuring consistent dimensions, thickness, and mechanical properties.
UV Resistance (Optional): Gel coat finish available for outdoor applications to prevent UV degradation.
Customizable Dimensions: Length, color, and surface finish can be tailored to project requirements.

Typical Mechanical Properties (6mm Thickness)

Property	Value
Tensile Strength	≥ 300 MPa (longitudinal)
Flexural Strength	≥ 400 MPa
Density	1.8 – 2.0 g/cm³
Water Absorption
Service Temperature Range	-40°C to +120°C
Flame Spread Index	≤ 25 (ASTM E84, Class 1 optional)

Benefits for Your Industrial Application

Reduced Maintenance: Unlike steel channels, FRP does not require painting, coating, or periodic replacement due to rust. This significantly lowers lifetime operational costs.
Easy Installation: Lightweight profiles allow one-person handling, reducing labor expenses and installation time. Pre-drilled holes or custom lengths are available upon request.
Safe in Hazardous Environments: Non-sparking and non-conductive properties make it suitable for use in explosive atmospheres or near electrical equipment.
Eco-Friendly: FRP is a sustainable material with long service life, reducing the need for frequent replacements and material waste.

Why Choose Hengshui Ruibin New Materials LLC?

Since our establishment in 2019, we have grown into a trusted manufacturer with a factory spanning 1,000–3,000 square meters and a dedicated team of 101–200 employees. Our annual export value exceeds US$2.5–5 million, serving clients across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. We are proud to hold ISO 9001 and ISO 9000 certifications, ensuring that every product meets rigorous quality standards. Our production processes are continuously optimized to deliver consistent dimensions, mechanical properties, and surface finishes. We ship from the ports of Tianjin and Qingdao, providing efficient logistics to global customers. With a strong focus on customer satisfaction, we offer customization services, technical support, and competitive pricing. Choose our FRP U Channel for your next industrial trench project – you’ll benefit from a product that combines durability, lightweight design, and proven reliability.

Frequently Asked Questions (FAQ)

Q: What is the standard length of the FRP U channel?
A: Standard lengths are 6 meters, but we can customize lengths from 1m to 6m per your requirements. Contact us for specific dimensions.
Q: Can this U channel be used outdoors?
A: Yes, but we recommend adding a UV-resistant gel coat for prolonged outdoor exposure. This option is available upon request.
Q: Is the 6mm thickness suitable for heavy loads?
A: The 6mm thick profile offers excellent strength for most industrial trench applications. For higher load requirements, we can recommend thicker profiles or reinforcement options.
Q: How do you ensure the product meets ISO 9001 standards?
A: Our factory follows strict quality control procedures, including raw material inspection, in-process monitoring, and final dimensional checks. Each batch is documented and traceable.
Q: What colors are available?
A: Standard colors include yellow, gray, and green. Custom colors matching RAL codes are available for orders over a minimum quantity.
Q: What is the minimum order quantity (MOQ)?
A: Typically, the MOQ is 100 pieces for standard sizes. For custom specifications, please inquire with our sales team.
Q: Can I get a sample before placing a bulk order?
A: Yes, samples are available. Please contact us to arrange a sample shipment (sample cost applies, refundable with bulk order).
Q: How long does production take?
A: For standard profiles, production takes 7–15 working days after order confirmation. Custom orders may require additional time.
