Help Center25mm Thickness FRP Molded Grating With Anti-Slip Surface and 1500kg/m² Load Capacity
Product Spotlights
Related Products
-
Fire Retardant FRP Molded Grating, Class A Flame Spread Rating, UV Resistant for Outdoor UseNegotiableMOQ: 300 Blades -
Heavy Duty FRP Molded Grating 3000kg/m² Load Capacity, 30mm Thickness, Grit Top SurfaceNegotiableMOQ: 300 Blades
-
Customizable FRP Molded Grating Panel 1.2m x 3.6m With 38mm Mesh Size and 25mm ThicknessNegotiableMOQ: 300 Blades
-
Oil and Gas Platform FRP Molded Grating, Lightweight, Fire Retardant, and Chemical ResistantNegotiableMOQ: 300 Blades
-
Grit Top Surface FRP Molded Grating for Slip Resistance, 25mm Thick, 1000mm x 3000mm SizeNegotiableMOQ: 300 Blades
Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000-3,000 m² factory and ISO9001 certified, presents our 25mm Thickness FRP Molded Grating with Anti-Slip Surface and 1500kg/m² Load Capacity. This grating is engineered to provide superior strength, slip resistance, and long-term durability for demanding industrial environments. Whether you need safe walkways, heavy-duty platforms, or corrosion-resistant flooring, our product delivers reliable performance with minimal maintenance.
Our FRP molded grating is manufactured using a precise compression molding process, combining high-quality fiberglass reinforcement with premium resin systems. The result is a lightweight yet exceptionally strong panel that can support up to 1500 kg/m² evenly distributed load. The integrated anti-slip surface ensures worker safety even in wet or oily conditions, making it ideal for chemical plants, offshore platforms, food processing facilities, and public infrastructure.
Key Features & Benefits
- High Load Capacity: Rated at 1500 kg/m², suitable for heavy machinery and pedestrian traffic.
- Anti-Slip Surface: Factory-applied grit or concave texture provides excellent traction (slip resistance coefficient >0.6).
- Corrosion Resistant: Impervious to most chemicals, saltwater, and UV radiation – ideal for harsh environments.
- Lightweight: Only 30% the weight of steel gratings, reducing installation costs and structural load.
- Non-Conductive: Electrically and thermally non-conductive, enhancing safety near electrical equipment.
- Low Maintenance: Does not rust, rot, or require painting; easy to clean with water or mild detergents.
- Customizable Colors & Sizes: Available in standard panels or cut-to-size per project requirements.
- Fire Retardant Options: Can be produced with fire-resistant resin (Class B or C per ASTM E84).
Technical Specifications
| Thickness | 25 mm ± 0.5 mm |
| Load Capacity | 1500 kg/m² (uniformly distributed load) |
| Mesh Size | 38×38 mm (standard), others available upon request |
| Weight per m² | Approx. 18 kg (depends on resin and filling) |
| Material | Fiberglass reinforced polyester/vinyl ester resin |
| Anti-Slip Type | Silica sand grit or concave pattern (optional) |
| Color Options | Yellow, green, gray, red, blue, or custom (RAL) |
| Standard Panel Size | 1220×3660 mm (4 ft × 12 ft) |
| Operating Temperature | -40°C to +80°C (standard resin); up to +120°C with special resin |
Why Choose Hengshui Ruibin New Materials LLC?
As a specialized manufacturer with ISO9001 & ISO9000 certification, we ensure every batch of FRP grating meets stringent quality standards. Our factory spans 1,000-3,000 m² and employs 101-200 skilled workers, enabling us to deliver consistent products with short lead times. With an annual export value of USD 2.5-5 million, we have successfully shipped to markets across North America, South America, Europe, Asia, Africa, and Oceania. Our main ports of shipment are Tianjin and Qingdao, offering convenient logistics worldwide.
We understand that safety and reliability are non-negotiable in industrial applications. Our 25mm thick anti-slip grating is tested for load capacity and slip resistance, giving you peace of mind. We also offer customization services – from color matching to special cutouts – to fit your project perfectly. Contact us today for a quote or sample, and experience the difference of working with a trusted manufacturer.
Frequently Asked Questions
-
Q: What is the maximum span for this grating under 1500 kg/m² load?
A: For a uniformly distributed load of 1500 kg/m², the recommended maximum span is 600 mm. For specific spans, please consult our technical team. -
Q: Can this grating be used in seawater or chemical environments?
A: Yes, it is made of corrosion-resistant FRP. For harsh chemical exposure, we recommend vinyl ester resin which offers superior resistance. -
Q: Is the anti-slip surface permanent?
A: Yes, the anti-slip grit or concave texture is integrally molded during production and will not wear off easily. -
Q: Do you provide custom sizes or cutouts?
A: Absolutely. We can cut panels to your specific dimensions and add holes, notches, or other modifications. -
Q: What colors are available?
A: Standard colors include yellow, green, gray, and red. Custom RAL colors are available with minimum order quantity. -
Q: How do I install this grating?
A: FRP grating can be cut with standard tools and fastened using clips, bolts, or adhesive. We provide installation guidelines upon request. -
Q: What is the lead time for a typical order?
A: For standard sizes, lead time is 10-15 days after deposit. Custom orders may take 15-25 days depending on complexity. -
Q: Do you offer samples?
A: Yes, we can send small samples (e.g., 200×200 mm) for evaluation. Please contact us for details.
