Hengshui Ruibin New Materials LLC proudly presents our premium Fiberglass Cable Ladder with 2mm Thick Profile, 20kg/m Load, 3m Span, Non-Conductive. As a manufacturer with ISO9001 certification and over 5 years of export experience, we deliver high-strength, corrosion-resistant cable management solutions for demanding environments. This non-conductive ladder tray eliminates electrical hazards, ensures long service life in harsh conditions, and supports heavy cable loads across 3-meter spans without sagging. Designed for global markets including North America, Europe, and Southeast Asia, our product is the trusted choice for industries requiring reliable, safe cable support.
Key Features & Technical Specifications
- Profile Thickness: 2mm – robust yet lightweight, providing excellent strength-to-weight ratio.
- Load Capacity: 20 kg/m (uniformly distributed load across 3m span) – ideal for heavy cable bundles.
- Non-Conductive: Made from fiberglass reinforced plastic (FRP), ensuring zero electrical conductivity, enhancing worker safety in electrical areas.
- Corrosion Resistance: Withstands acids, alkalis, salts, and UV radiation – perfect for chemical plants, offshore platforms, and outdoor installations.
- Fire Retardant (Optional): Self-extinguishing grade available upon request to meet specific fire safety codes.
- Easy Installation: Modular design with splice plates and hardware included; compatible with standard supports.
- Customizable Colors: Standard gray or yellow; other RAL colors available on request.
- Long Service Life: Expected lifespan >20 years under normal operating conditions.
| Parameter | Value |
|---|---|
| Material | Fiberglass Reinforced Polyester (FRP) |
| Profile Thickness | 2.0 mm ± 0.2 mm |
| Load Capacity (UDL) | 20 kg/m at 3m span |
| Span Length | 3.0 meters (standard) |
| Conductivity | Non-conductive (dielectric strength > 10 kV/mm) |
| Operating Temperature | -40°C to +80°C |
| Weight per Unit Length | Approx. 4.5 kg/m (varies by width) |
Advantages for Your Business
- Enhanced Safety: Non-conductive nature eliminates electrocution risk, reducing workplace accidents and insurance costs.
- Reduced Maintenance: Resistant to rust, rot, and chemical attack – no need for painting or protective coatings.
- Lightweight: Easier to handle and install than steel, lowering labor costs and installation time.
- High Load Capacity: Supports 20 kg/m over 3m spans, accommodating heavy power and data cables without deflection.
- Long-Term Value: With a lifespan exceeding 20 years, total cost of ownership is significantly lower than metal alternatives.
- Global Compliance: Manufactured under ISO9001 quality management system, ensuring consistent quality and reliable performance.
Why Choose Hengshui Ruibin New Materials LLC?
Since 2019, we have grown into a specialized manufacturer with a 1,000-3,000 m² factory and a skilled team of 101-200 employees. Our annual export value reaches US$2.5 Million – US$5 Million, serving customers across North America, South America, Europe, Asia, Africa, and Oceania. We ship from Port of Tianjin and Port of Qingdao, ensuring timely delivery worldwide. Every product is backed by ISO9001:2015 and ISO9000 certifications, guaranteeing strict quality control from raw material selection to final inspection. Our engineers offer customization services for width, color, and fire rating to match your exact project requirements. Join hundreds of satisfied clients who trust Ruibin for durable, non-conductive cable ladder solutions.
Frequently Asked Questions
-
Q: Can the ladder be used in outdoor environments?
A: Yes, our fiberglass cable ladder is UV-resistant and weatherproof, suitable for outdoor installations. Optional gel coat enhances UV protection. -
Q: Is the product truly non-conductive?
A: Absolutely. The fiberglass material has a dielectric strength of over 10 kV/mm, making it safe for electrical substations, data centers, and telecom rooms. -
Q: What is the maximum cable weight it can support?
A: At a 3m span, the maximum uniformly distributed load is 20 kg/m. For longer spans, please consult our technical team for custom engineering. -
Q: Do you offer fire-retardant versions?
A: Yes, we can produce self-extinguishing grades that meet V-0 or similar classifications. Please specify your requirement when ordering. -
Q: What standard widths are available?
A: Common widths include 200mm, 300mm, 400mm, and 600mm. Custom widths are also available upon request. -
Q: How is the ladder joined together?
A: We provide stainless steel splice plates and fasteners for easy field assembly. The connection is both strong and corrosion-resistant. -
Q: What is the lead time for a standard order?
A: Typically 15-25 working days after order confirmation, depending on quantity and customization. Express delivery can be arranged for urgent orders. -
Q: Do you provide samples for testing?
A: Yes, sample pieces are available. Please contact our sales team to discuss sample cost and shipping.
Get Your Reliable Cable Support Solution Today
With ISO9001 certification, a dedicated factory, and a proven track record of global exports, Hengshui Ruibin New Materials LLC is your trustworthy partner for non-conductive fiberglass cable ladders. Our 2mm thick profile and 20 kg/m load capacity ensure long-lasting performance in the most demanding applications. Contact us now for a quotation, technical drawing, or to discuss your specific requirements. Let us help you build a safer, more efficient cable management system.
