Help Center1.5mm Thick FRP Cable Tray With UL94 V-0 Flame Retardant, 300kg/M Load Capacity
Product Spotlights
Related Products
-
Lightweight FRP Cable Tray, 3mm Thickness, 800kg/m³ Density, 1200mm SpanNegotiableMOQ: 300 Meters -
Pultruded FRP Cable Tray, Fire Retardant Class B1, Anti-Static for Industrial Cable ManagementNegotiableMOQ: 300 Meters
-
FRP Cable Tray With 2.5mm Wall Thickness, 600mm Width, 500N/M Load Capacity for Heavy DutyNegotiableMOQ: 300 Meters
-
FRP Cable Tray With 304 Stainless Steel Bolts and Connectors, 4m Length, 1.2m WidthNegotiableMOQ: 300 Meters
-
FRP Cable Tray Used in Offshore Platform, Salt Spray Resistant, 20-Year Service LifeNegotiableMOQ: 300 Meters
As a leading manufacturer of composite cable management solutions, Hengshui Ruibin New Materials LLC proudly presents our 1.5mm Thick FRP Cable Tray with UL94 V-0 flame retardant rating and a robust 300kg/m load capacity. Established in 2019 and operating from a 1,000-3,000 square meter factory in Hengshui, Hebei, China, we have consistently delivered high-quality FRP products to global markets, including North America, Europe, Southeast Asia, and the Middle East. Our cable tray is engineered to provide superior strength, corrosion resistance, and fire safety, making it an ideal choice for demanding industrial environments. With ISO9001 certification and an annual export value of US$2.5 million to US$5 million, we are committed to excellence and customer satisfaction.
Our FRP cable tray is manufactured using high-quality fiberglass and thermosetting resins, ensuring exceptional durability and lightweight properties. The 1.5mm thickness delivers a perfect balance of structural rigidity and ease of installation, while the UL94 V-0 flame retardant classification guarantees that the material will self-extinguish within 10 seconds after ignition, preventing fire spread. The 300kg/m load capacity supports heavy cable loads without deformation, making it suitable for power plants, chemical plants, offshore platforms, and data centers. Additionally, the tray's corrosion-resistant properties eliminate the need for frequent maintenance, even in harsh environments with high humidity, salt spray, or chemical exposure.
Key Technical Specifications
| Parameter | Value |
| Material | Fiberglass Reinforced Plastic (FRP) |
| Thickness | 1.5mm ± 0.1mm |
| Flame Retardant Rating | UL94 V-0 |
| Load Capacity | 300 kg/m (uniformly distributed load) |
| Operating Temperature | -40°C to +80°C |
| Color | Gray (standard), Green, Yellow, or Custom |
| Width Range | 100mm to 800mm (customizable) |
| Length | 3m, 6m, or custom lengths |
Product Advantages & Benefits
- Superior Fire Safety: The UL94 V-0 rating ensures that the tray meets stringent fire safety standards, protecting critical cables and reducing fire risk in industrial facilities.
- High Load Capacity: With a 300kg/m load capacity, this tray can support heavy cable bundles without sagging, ensuring long-term reliability.
- Lightweight & Easy Installation: FRP is 70% lighter than steel, reducing labor costs and installation time. No heavy lifting equipment required.
- Excellent Corrosion Resistance: Resistant to acids, alkalis, salt spray, and UV radiation, making it ideal for coastal, chemical, and wastewater treatment environments.
- Low Maintenance: Non-conductive, non-magnetic, and rust-proof, eliminating the need for painting or galvanizing.
- Customizable Design: Available in various widths, lengths, and colors. Perforated, solid, or ventilated options can be provided upon request.
- Eco-Friendly: FRP is a non-toxic, recyclable material that contributes to sustainable construction.
At Hengshui Ruibin New Materials LLC, we combine advanced manufacturing techniques with rigorous quality control. Our factory employs 101-200 skilled workers, and our products are exported to major markets including North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and Asia. We ship through the Port of Tianjin and Port of Qingdao, ensuring timely delivery worldwide. With ISO9001 and ISO9000 certifications, we guarantee consistent quality and traceability. Our team is dedicated to providing technical support and after-sales service, making us a trusted partner for cable management solutions.
Choose our 1.5mm Thick FRP Cable Tray with UL94 V-0 flame retardant for your next project. Benefit from a product that combines safety, strength, and longevity. Contact us today for a quote or to discuss your specific requirements. We offer free samples, OEM/ODM services, and competitive pricing. Let us help you achieve a reliable and efficient cable management system.
Frequently Asked Questions (FAQ)
-
Q: What does UL94 V-0 flame retardant rating mean?
A: UL94 V-0 is a flammability standard for plastics. A V-0 rating means that the material self-extinguishes within 10 seconds after a flame is removed, and no burning drips are allowed. This ensures high fire safety for cable trays in critical applications. -
Q: Can the cable tray be used outdoors?
A: Yes, our FRP cable tray is UV-resistant and can withstand outdoor exposure. However, for direct sunlight, we recommend using a UV-stabilized resin or optional protective coating to extend service life. -
Q: Is the 300kg/m load capacity tested under real conditions?
A: Yes, we perform load testing per international standards. The 300kg/m capacity is based on a uniformly distributed load (UDL) at a span of 1.5m. For longer spans, the load capacity may reduce; please consult our engineers for specific span calculations. -
Q: Can I get custom colors or sizes?
A: Absolutely. We offer customization in width (100-800mm), length, color, and hole patterns. Just provide your requirements, and we will produce accordingly. -
Q: What is the typical lead time for an order?
A: For standard sizes, lead time is 15-20 working days after order confirmation. Custom orders may take 25-30 working days. Urgent orders are possible upon negotiation. -
Q: Do you provide installation accessories?
A: Yes, we offer compatible brackets, clamps, splices, and covers. All accessories are made from FRP or stainless steel for corrosion resistance. -
Q: How do you ensure product quality?
A: We follow ISO9001 quality management system. Each batch undergoes dimensional checks, flame retardant testing, and load capacity verification. We also provide a test report upon request. -
Q: What is the minimum order quantity (MOQ)?
A: The MOQ is 50 meters for standard sizes. For custom specifications, MOQ may vary. Contact us for details.
