Help CenterNylon 66 Gear, Module 1, 20 Teeth, Low Noise, Wear Resistant, Lightweight for Light Machinery
Product Spotlights
Related Products
-
Industrial Gear Manufacturing: High Precision & Heavy Duty PerformanceNegotiableMOQ: 1 Piece -
Gear Drive System With 3-Year Warranty and Technical Support PackageNegotiableMOQ: 1 Piece
-
Custom Spline Shaft Gear for Agricultural Machinery OEM ReplacementNegotiableMOQ: 1 Piece
-
Hardened Steel Spur Gear 20CrMnTi Alloy With 58-62HRC Surface HardnessNegotiableMOQ: 1 Piece
-
Industrial Bevel Gear Set 1:3 Ratio for Heavy-Duty Power TransmissionNegotiableMOQ: 1 Piece
Welcome to Henan San Kuang Machinery Technology Co., Ltd. As a trusted manufacturer since 2014, we are proud to introduce our Nylon 66 Gear, Module 1, 20 Teeth – a precision component engineered for light machinery applications. Combining advanced polymer technology with rigorous quality control, this gear delivers exceptional low-noise operation, outstanding wear resistance, and a lightweight design that reduces overall system inertia. Whether you need a reliable replacement part or a core component for new equipment, our gear offers the perfect balance of durability and performance.
Our factory, spanning 10,000–30,000 square meters, houses a dedicated team of 51–100 skilled professionals. We have achieved multiple certifications including ISO9001, ISO14000, and OHSAS18001, ensuring that every gear we produce meets international standards. The Nylon 66 gear is crafted from high-quality engineering plastic, known for its excellent mechanical strength and self-lubricating properties. Below you will find detailed specifications and benefits that make this gear an ideal choice for your light machinery needs.
Key Features & Technical Specifications
- Material: Nylon 66 (Polyamide 66) – offers high tensile strength, excellent fatigue resistance, and low moisture absorption compared to standard nylon.
- Module: M1 (Module 1) – ensures standardized tooth profile for easy integration with other module 1 gears and racks.
- Teeth Count: 20 teeth – provides a balanced combination of smooth engagement and torque transmission.
- Low Noise Operation: The inherent damping properties of Nylon 66 significantly reduce vibration and noise, making it suitable for office equipment, printers, and small automation systems.
- Wear Resistant: Reinforced with internal lubricants and optimized molecular structure, this gear withstands continuous friction without excessive wear.
- Lightweight: Weighing only a fraction of metal gears, it reduces the load on bearings and motors, improving energy efficiency.
- Customizable Options: Available in various colors, bore sizes, and keyway configurations upon request.
| Parameter | Value |
| Material | Nylon 66 (PA66) |
| Module | M1 |
| Number of Teeth | 20 |
| Pressure Angle | 20° (standard) |
| Outer Diameter | Approx. 22 mm (based on M1, 20T) |
| Bore Size | Customizable (default 6 mm) |
| Operating Temperature | -40°C to +120°C |
| Color | Natural (black, white, or custom) |
Detailed Advantages for Your Application
The Nylon 66 gear excels in environments where metal gears would cause excessive noise or require lubrication. Its self-lubricating nature reduces maintenance intervals and prevents contamination in sensitive equipment like food packaging machines or medical devices (subject to compliance). The lightweight design directly contributes to lower energy consumption and faster acceleration in automated systems.
Compared to standard nylon gears, our Nylon 66 variant offers 20% higher wear resistance and 15% lower coefficient of friction, based on internal testing. This translates to longer service life even under continuous loads. The module 1 tooth profile ensures compatibility with widely available racks and pinions, simplifying replacement and scaling.
Every gear is precision-molded using advanced injection molding machines, achieving tight tolerances of ±0.05 mm on tooth profile. This eliminates the need for post-machining in most applications, saving you time and cost. Our quality control team inspects each batch for dimensional accuracy, hardness, and noise level.
Trust & Certification
Henan San Kuang Machinery Technology Co., Ltd. has been serving global markets since 2014, with an annual export value of US$2.5 Million – US$5 Million. Our products are shipped to over 20 countries including North America, Europe, Southeast Asia, and South America via major ports such as Shanghai, Qingdao, and Tianjin.
We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, and SA8000, reflecting our commitment to quality, environmental responsibility, and social compliance. Our factory is equipped with modern testing facilities, and we welcome third-party audits.
When you choose our Nylon 66 gear, you benefit from a reliable supply chain, consistent quality, and responsive after-sales support. We offer free samples for evaluation (subject to shipping cost), and our engineering team provides technical guidance for integration.
Don’t compromise on performance – upgrade to our lightweight, low-noise nylon gear today. Contact us for pricing, customization, or bulk orders.
Frequently Asked Questions
-
Q: What is the maximum torque this gear can handle?
A: The torque capacity depends on the gear width, bore size, and operating conditions. For a standard 10mm width gear, the maximum allowable torque is approximately 1.5 Nm at 100 RPM. Contact us for a detailed calculation based on your application. -
Q: Can I use this gear in high-temperature environments?
A: Yes, Nylon 66 can operate continuously up to 120°C. For short-term peaks, it can withstand up to 150°C. However, prolonged exposure above 120°C may reduce mechanical properties. -
Q: Is the gear self-lubricating? Do I need to add grease?
A: Nylon 66 has inherent lubricity, but for optimal performance and extended life, a light grease coating is recommended, especially under high-speed or high-load conditions. -
Q: What bore sizes are available?
A: We offer standard bore sizes of 6 mm, 8 mm, and 10 mm. Custom bore sizes and keyways are available upon request with a minimum order quantity. -
Q: How does this gear compare to metal gears in terms of precision?
A: Our injection-molded nylon gears achieve a precision grade of ISO 9 (Q9), which is suitable for most light machinery. For applications requiring higher precision (e.g., ISO 6), we can supply machined nylon gears. -
Q: Is the gear suitable for food processing equipment?
A: Nylon 66 is generally considered food-safe, but we recommend using our FDA-compliant grade (available upon request). Our standard material is not certified for direct food contact unless specified. -
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 100 pieces. For custom specifications, MOQ is 500 pieces. Small trial orders are welcome. -
Q: Do you provide samples? How long does delivery take?
A: Yes, we offer free samples (buyer pays shipping). Production lead time is 7–15 working days for standard orders, and 15–25 working days for custom orders.
