Help CenterUHMWPE PE Board 1000x2000mm, 10mm Thickness, High Impact Resistance for Industrial Application
Product Spotlights
Related Products
-
Black PE Board 3mm Thick, 1500x3000mm, High Density Polyethylene Sheet for Chemical ResistanceNegotiableMOQ: 1 Square Meter -
Customized PE Board, CNC Cutting Service, 3-Year Warranty for Industrial UseNegotiableMOQ: 1 Square Meter
-
2mm Thick HDPE PE Board With UV Stabilizer for Outdoor Use, 1200x2400mm SheetNegotiableMOQ: 1 Square Meter
-
White PE Board 2mm, 2000x1000mm, UV Resistant and Weatherproof for Outdoor SignsNegotiableMOQ: 1 Square Meter
-
PE Board 5mm Thickness, 1220x2440mm, Anti-Static Property for Electronics WorkshopNegotiableMOQ: 1 Square Meter
As a leading manufacturer based in Hengshui, Hebei, China, Anping County Boli Hardware Wiremesh Products Factory has been dedicated to industrial material solutions since 1998. Our UHMWPE PE Board 1000x2000mm, 10mm Thickness is engineered to deliver exceptional impact resistance for demanding industrial applications. With an annual export value exceeding US$5 million, we supply reliable plastic boards to markets across North America, South America, Europe, Asia, and beyond. This product combines advanced polymer technology with rigorous quality control, ensuring consistent performance in harsh environments.
This board is crafted from Ultra-High Molecular Weight Polyethylene (UHMWPE), a material known for its outstanding toughness, wear resistance, and self-lubricating properties. The 10mm thick sheet offers a perfect balance of strength and flexibility, making it ideal for lining chutes, hoppers, and conveyor systems exposed to heavy abrasion and impact. Our factory processes each board with precision, maintaining a tight tolerance of ±0.5mm on thickness and ±5mm on dimensions to ensure easy installation and compatibility.
Key Features & Technical Specifications
- High Impact Resistance: Absorbs shock without cracking or breaking, protecting equipment from damage.
- Excellent Wear Resistance: Outlasts steel and other plastics in abrasive applications, reducing replacement frequency.
- Self-Lubricating Surface: Low coefficient of friction minimizes material buildup and improves flow in bulk handling.
- Chemical Resistance: Resists most acids, alkalis, and organic solvents, suitable for corrosive environments.
- Non-Toxic & FDA Compliant (on request): Safe for contact with food and pharmaceuticals when specified.
- Lightweight: Easy to handle, cut, and install compared to metal alternatives.
| Property | Value |
| Dimensions | 1000 x 2000 mm (3.3 x 6.6 ft) |
| Thickness | 10 mm ± 0.5 mm |
| Density | 0.93 g/cm³ |
| Tensile Strength | ≥20 MPa |
| Elongation at Break | ≥300% |
| Working Temperature | -150°C to +80°C |
| Surface Hardness (Shore D) | 60-65 |
The 10mm thickness provides a robust barrier against repeated impacts, making it a preferred choice for industrial applications such as:
- Chute & hopper liners in mining and aggregate processing
- Conveyor belt skirting and scrapers
- Dump truck bed liners
- Material handling equipment wear strips
- Protective panels for machinery
Compared to conventional steel or rubber liners, UHMWPE boards offer longer service life in abrasive environments, reduce noise levels, and prevent material sticking. The lightweight nature (approx. 18.6 kg per sheet) simplifies transportation and onsite modifications. Each board is cut with clean edges, ready for immediate use or custom machining.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
With over 25 years of manufacturing experience, we have established a reliable supply chain and strict quality management system. Our factory exports US$5 million to US$10 million worth of products annually to major markets including North America, Europe, Africa, and Oceania. We offer flexible shipping options from Tianjin, Qingdao, and Shanghai ports, ensuring timely delivery worldwide. Custom sizes, colors, and additional processing (e.g., drilling, routing) are available upon request to meet your specific project requirements.
Trust in our expertise: We have served thousands of industrial clients who rely on our UHMWPE boards for critical applications. Our commitment to quality and customer satisfaction has built long-term partnerships across continents. Contact us today for a quote or technical consultation – we are ready to support your next project with durable, high-performance plastic solutions.
Frequently Asked Questions
-
Q: What is the maximum operating temperature for this UHMWPE board?
A: The board can be used continuously from -150°C to +80°C. For short-term exposure, it can withstand up to 100°C, but prolonged exposure above 80°C may cause softening. -
Q: Can this material be used for food contact applications?
A: Yes, our UHMWPE is non-toxic and can be made FDA-compliant upon request. Please specify your requirement when ordering. -
Q: How do I cut or machine the board?
A: The board can be cut with standard woodworking tools, such as a circular saw or jigsaw with fine-tooth blades. For drilling, use standard HSS bits. No special equipment is needed. -
Q: Is the board UV resistant for outdoor use?
A: Standard UHMWPE is not UV stabilized. If outdoor exposure is expected, we recommend adding a UV stabilizer additive (available upon request). -
Q: What is the weight of one sheet?
A: Approximately 18.6 kg per sheet (based on density 0.93 g/cm³). This makes it easy to handle by one person. -
Q: Do you offer custom sizes or thicknesses?
A: Absolutely. We can produce sheets in various dimensions and thicknesses (e.g., 5mm, 15mm, 20mm) with a minimum order quantity. Contact us for a quote. -
Q: Can this board be used as a drop-in liner for truck beds?
A: Yes, its impact resistance and low friction make it ideal for truck bed liners. You can cut to shape and fasten with bolts or adhesive. -
Q: How long does shipping take?
A: Typically 15-25 days for sea freight from Chinese ports. Express shipping (DHL, FedEx) is available for small quantities. Please check with our sales team for exact lead time.
