Home > Industrial Equipment & Components > Fastener & Fitting > Gasket & Washer > Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant thumbnail-3

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant thumbnail-4

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant thumbnail-5

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant photo-1

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant photo-2

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant photo-3

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant photo-4

Snap Ring With 1.5mm Wire Diameter, External Retaining Ring, Standard Compliant photo-5

Product Spotlights

Precision 1.5mm external retaining ring, compliant with DIN/ANSI/JIS standards. Manufactured by experienced factory since 1998, offering carbon steel or stainless steel with multiple finishes. Easy snap-fit installation, high axial retention, and cost-effective. Custom sizes and finishes available. Annual export US$5-10M, worldwide shipping from Tianjin/Qingdao/Shanghai.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Type:

Other, External Retaining Ring

Material:

Other, Spring Steel (Carbon Steel, Stainless Steel optional)

Wire Diameter:

1.5mm

Contact Supplier Request Quote Chat Now

Anping County Boli Hardware Wiremesh Products Factory

2Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Other, External Retaining Ring

Material Other, Spring Steel (Carbon Steel, Stainless Steel optional)

Wire Diameter 1.5mm

Standard DIN 471, DIN 472, ANSI, JIS (specify upon request)

Finish Phosphate coated, Zinc plated, Black oxide (customizable)

Size Range Available in various inner/outer diameters (custom sizes upon request)

Application Automotive, Machinery, Industrial equipment, Electronics

Color As per finish (silver, black, blue, etc.)

Anping County Boli Hardware Wiremesh Products Factory, established in 1998, is a professional manufacturer specializing in standard-compliant retaining rings. Our Snap Ring with 1.5mm Wire Diameter, External Retaining Ring is engineered for reliable axial retention in shafts and housings. With over two decades of experience and annual export values reaching US$5–10 million, we deliver precision components trusted by industries across North America, Europe, Asia, and Oceania. This product is manufactured to strict dimensional tolerances, ensuring snap-fit installation and secure locking under dynamic loads.

Product Overview:

Wire Diameter: 1.5mm (exact to ±0.05mm)
Type: External retaining ring (for shaft grooves)
Material Options: Carbon spring steel (SAE 1070, 1080), stainless steel (AISI 301, 304), or custom alloy upon request
Surface Finish: Phosphate (manganese or zinc), zinc plating (clear or yellow), black oxide, or as per customer specification
Standards: Compliant with DIN 471, DIN 472, ANSI B27.7, and JIS B 2804 (customer can specify)
Available Sizes: From 10mm to 100mm shaft diameter (custom sizes up to 200mm available)
Packaging: Bulk, polybags, or custom labeling

Parameter	Specification
Wire Diameter	1.5 mm
Material Tensile Strength	≥ 1400 N/mm² (carbon steel)
Hardness	HRC 44-52 (with spring temper)
Groove Diameter Tolerance	H11 (for shaft) / D11 (for housing)
Operating Temperature	-40°C to +150°C (standard); up to 300°C for stainless steel

Key Features & Benefits:

Precision Manufacturing: Our snap rings are cold-formed using advanced CNC coiling machines, ensuring consistent wire diameter and concentricity. Each ring is heat-treated to achieve optimal spring properties.
Standard Compliance: All dimensions meet international standards (DIN, ANSI, JIS) or can be customized. We provide a Certificate of Conformance upon request.
Easy Installation: The external retaining ring design features lugs for pliers, allowing quick and secure snap into shaft grooves. No special tools required.
Reliable Axial Retention: With 1.5mm wire thickness, these rings offer high clamping force, preventing components from shifting under vibration or axial loads.
Corrosion Resistance: Choose from various surface finishes to suit your environment: zinc plating for general protection, phosphate for oil retention, or stainless steel for harsh conditions.
Cost-Effective: As a manufacturer with 25+ years of experience, we offer competitive pricing without compromising quality. Our production capacity exceeds 10 million pieces per month.
Customization: Need a non-standard size, special material, or unique finish? We can produce according to your drawing or sample. Minimum order quantity is flexible.

Why Choose Anping County Boli Hardware Wiremesh Products Factory?

Since 1998, we have been a trusted supplier to global markets including North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our company exports US$5–10 million annually, reflecting our commitment to quality and customer satisfaction. We ship from Tianjin, Qingdao, or Shanghai ports, ensuring timely delivery. All our products undergo rigorous QC inspections: dimensional checks, hardness testing, and surface finish evaluation. We are not a trading company—we are the manufacturer, which means you get factory-direct pricing and direct communication with our engineering team.

Frequently Asked Questions (FAQ):

Q: What materials are available for the snap ring?
A: We offer carbon spring steel (SAE 1070, 1080) and stainless steel (AISI 301, 304). Other materials like beryllium copper or Inconel are available on request.
Q: Can you provide samples before bulk order?
A: Yes, we can supply samples (usually 3–5 pieces) for evaluation. The sample cost is nominal and can be deducted from the first order.
Q: Do you offer custom sizes or non-standard wire diameters?
A: Absolutely. We can produce snap rings with wire diameters from 0.5mm to 4mm, and any inner/outer diameter within our tooling range. Please provide a drawing or specification.
Q: What is the typical lead time for a standard order?
A: For standard sizes and finishes, lead time is 10–15 working days. Custom orders may take 20–25 days depending on complexity.
Q: How do you ensure the rings are resistant to deformation?
A: Our heat treatment process (quenching and tempering) ensures the rings achieve the required hardness and elasticity. We also perform 100% dimensional inspection on critical parameters.
Q: Do you have any quality certifications?
A: We follow internal quality control standards and can provide a Certificate of Conformance. Specific certifications such as ISO 9001 are not currently held, but we are open to third-party audits.
Q: What is the minimum order quantity (MOQ)?
A: For standard sizes, MOQ is 5,000 pieces. For custom sizes, MOQ may be higher depending on tooling requirements. Small quantities are available for sample or trial.
Q: Can you provide a retaining ring assortment kit?
A: Yes, we can customize kits with various sizes in a box. Please contact us with your requirements.
