Home > Tools & Hardware > Hardware Accessories > Spring > Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies thumbnail-3

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies thumbnail-4

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies thumbnail-5

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies photo-1

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies photo-2

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies photo-3

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies photo-4

Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies photo-5

Product Spotlights

Precision 316L stainless steel flat wire wave spring (5mm ID, 12mm OD, 0.2mm wire) designed for valve assemblies. Offers consistent axial force, corrosion resistance, and space-saving design. Customizable dimensions, wave count, and packaging. Backed by 25+ years of manufacturing expertise and global export experience.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, 316L Stainless Steel

Inner Diameter:

5mm

Outer Diameter:

12mm

Contact Supplier Request Quote Chat Now

Anping County Boli Hardware Wiremesh Products Factory

2Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, 316L Stainless Steel

Inner Diameter 5mm

Outer Diameter 12mm

Wire Thickness 0.2mm

Type Flat Wire Wave Spring

Application Valve Assemblies

Surface Finish As per standard (customizable)

Packaging Customizable

Tolerance Precision class (customizable upon request)

Coil Direction Standard (optional customization)

Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer since 1998 with annual export value between US$5 Million and US$10 Million. Our Flat Wire Wave Spring 316L Stainless Steel 5mm ID 12mm OD 0.2mm Wire for Valve Assemblies is engineered to deliver consistent axial force, reliable sealing, and precise load distribution in demanding valve applications. Crafted from premium 316L stainless steel, this wave spring offers excellent corrosion resistance and durability, making it a superior choice for industries ranging from oil & gas to chemical processing. We combine decades of manufacturing expertise with rigorous quality control to ensure every spring meets your exact specifications.

Product Features & Technical Specifications

High Precision Dimensions: Inner diameter 5mm, outer diameter 12mm, wire thickness 0.2mm – designed for tight tolerance valve assemblies.
Material Excellence: 316L stainless steel provides superior resistance to pitting, crevice corrosion, and stress corrosion cracking in harsh environments.
Consistent Wave Form: Flat wire wave spring design offers multiple contact points, reducing stress concentration and extending service life.
Versatile Application: Ideal for valve assemblies, pumps, actuators, and other mechanical systems requiring axial preload.
Customizable Options: Available in various sizes, finishes, and packaging upon request – we support OEM/ODM orders.

Parameter	Value
Material	316L Stainless Steel (UNS S31603)
Inner Diameter (ID)	5 mm
Outer Diameter (OD)	12 mm
Wire Thickness	0.2 mm
Number of Waves	Standard 3–5 (customizable)
Load Capacity	Varies with wave count; specify upon order
Operating Temperature	-196°C to 600°C (316L typical)

Key Advantages for Your Business

Enhanced Performance: The wave spring design reduces assembly height compared to conventional coil springs, saving space in compact valve assemblies.
Material Reliability: 316L stainless steel offers excellent weldability and formability, ensuring consistent quality across batches.
Cost Efficiency: Lightweight design and long service life reduce replacement frequency and maintenance costs.
Global Compliance: Our springs are manufactured to meet international standards; specific certifications are available upon request.
Rapid Prototyping: We offer fast turnaround for custom samples, enabling you to test before bulk production.

Why Choose Anping County Boli Hardware Wiremesh Products Factory?

With over 25 years of manufacturing experience (since 1998), we have built a reputation for delivering high-quality precision components to clients worldwide. Our annual export value of US$5–10 million reflects our strong presence in North America, South America, Europe, Asia, Africa, Oceania, and the Middle East. We ship from major ports including Tianjin, Qingdao, and Shanghai, ensuring timely delivery. Our dedicated quality team inspects every batch, and we offer flexible packaging and customization to meet your unique requirements. Contact us today to discuss your valve assembly needs – we are ready to support your next project with reliable, cost-effective wave spring solutions.

Frequently Asked Questions (FAQ)

Q: What is the typical tolerance for ID and OD? A: Our standard tolerance is ±0.1 mm for ID and OD. Tighter tolerances are available upon request for high-precision applications.
Q: Can this wave spring be used in high-temperature environments? A: Yes, 316L stainless steel retains good mechanical properties up to 600°C, making it suitable for many industrial valve applications.
Q: Do you offer custom wave counts or load ratings? A: Absolutely. We can adjust the number of waves, wire thickness, and free height to achieve desired load characteristics. Please provide your specifications.
Q: What surface finish is standard? A: Springs are supplied in a clean, passivated condition as per standard practice. Other finishes like electropolishing are available upon request.
Q: What is the minimum order quantity (MOQ)? A: MOQ varies by size and complexity. Typically, 500 pieces for standard sizes. Contact us for small-quantity samples.
Q: How do you package the springs to prevent damage? A: We use anti-corrosion wrapping, bubble bags, and sturdy cartons. Custom packaging (e.g., tape-and-reel, bulk boxes) is available.
Q: Do you have any quality certifications? A: Our products are manufactured under strict quality control. While we do not hold ISO/CE certificates listed, we can provide material test reports and dimensional inspection reports as needed.
Q: What is the lead time for mass production? A: Typically 15–25 days after sample approval, depending on order quantity and complexity. Express shipping options are available.
