Henan San Kuang Machinery Technology Co., Ltd., established in 2014 with a factory spanning 10,000-30,000 square meters and a team of 51-100 skilled employees, presents our PU Roller 220V Motorized Drive Roller – a high-performance solution designed for automated systems. With an annual export value of US$2.5 Million – US$5 Million and serving markets across North America, South America, Europe, Asia, and Africa, we understand the demands of global logistics. This 0.75kW, 100kg load capacity roller combines robust polyurethane construction with precision engineering to deliver reliable, low-maintenance operation in conveyor systems, sorting lines, and packaging machinery. Our commitment to quality is backed by certifications including ISO9001, ISO14000, and OHSAS18001, ensuring every roller meets rigorous international standards.
This motorized drive roller is engineered to optimize material handling efficiency. The integrated 220V motor eliminates the need for external chains or belts, reducing downtime and maintenance costs. The PU (polyurethane) outer surface provides excellent grip, noise reduction, and wear resistance, making it ideal for delicate or high-speed applications. Below is a detailed specification table:
| Parameter | Value |
| Voltage | 220V AC, 50/60Hz |
| Power | 0.75kW (1 HP) |
| Load Capacity | 100 kg per roller |
| Roller Diameter | Available in 60mm, 80mm, 100mm (customizable) |
| Roller Length | 300mm – 2000mm (customizable) |
| Surface Material | Polyurethane (PU) – Shore A 80-90 |
| Motor Type | Built-in asynchronous motor, IP54 protection |
| Speed Range | 0.1 – 2.0 m/s (adjustable via frequency inverter) |
Key Features & Benefits:
- Integrated Motor Design: Compact and space-saving, eliminates external drive components, reducing installation complexity and maintenance.
- High Load Capacity: Supports up to 100 kg per roller, suitable for medium-weight cartons, pallets, and parts.
- PU Surface: Provides excellent traction, quiet operation, and resistance to oils, chemicals, and abrasion – ideal for clean environments.
- Energy Efficient: 0.75kW motor with optimized gearbox reduces power consumption while maintaining consistent torque.
- Customizable Dimensions: Diameter and length can be tailored to your specific conveyor layout, with optional shaft extensions.
- Global Compatibility: 220V AC standard voltage, easily adaptable to local power supplies with frequency converters.
- Low Noise Operation: Engineered bearings and PU coating minimize vibration, ensuring a quieter workplace.
Application Scenarios: This motorized drive roller is widely used in automated assembly lines, warehouse sorting systems, airport baggage handling, food processing conveyors, and packaging machinery. Its robust construction and reliable performance make it a preferred choice for industries requiring continuous operation, such as logistics, e-commerce fulfillment, and automotive manufacturing.
At Henan San Kuang, we have over a decade of experience in manufacturing conveyor components. Our factory is equipped with advanced CNC machinery and testing facilities, allowing us to produce rollers with tight tolerances and consistent quality. We offer a full range of certifications including ISO9001, ISO14000, OHSAS18001, and others, reflecting our commitment to quality, environmental management, and occupational health. With our main export ports in Shanghai, Lianyungang, Qingdao, and Tianjin, we ensure timely delivery to global customers. Our team of 51-100 professionals provides technical support, from product selection to after-sales service. We invite you to experience the reliability of our PU Roller Motorized Drive Roller – a cost-effective solution that enhances your automated system's productivity.
FAQ:
-
Q: What is the typical lifespan of the PU roller surface?
A: Under normal operating conditions (non-abrasive loads, proper maintenance), the PU surface can last 3-5 years. The exact lifespan depends on load frequency, environment, and speed. -
Q: Can the roller be used in wet or food processing environments?
A: Yes, the PU material is resistant to moisture and many chemicals. However, for direct food contact, we recommend a food-grade polyurethane option available upon request. -
Q: Does the motor require a special drive or controller?
A: The motor is designed for direct connection to 220V AC. For speed control, an external frequency inverter (VFD) is required – we can provide compatible models. -
Q: What is the noise level of this roller?
A: Typically below 65 dB(A) at 1 meter distance, depending on speed and load. The PU coating and precision bearings contribute to quiet operation. -
Q: Can I get the roller with a different voltage (e.g., 380V)?
A: Yes, we offer custom voltage options. Please specify your requirements when ordering, and we will adjust the motor winding accordingly. -
Q: How is the roller connected to the conveyor frame?
A: The roller comes with standard shaft ends (flat or keyed) that fit into bearing brackets. Custom mounting options (flanges, threads) are available. -
Q: What is the minimum order quantity?
A: For standard sizes, MOQ is 10 pieces. Custom orders may require higher quantities – please contact our sales team for details. -
Q: Do you provide installation instructions or technical drawings?
A: Yes, we supply 2D and 3D CAD drawings, as well as installation manuals. Our engineers can also provide remote support.
