As a trusted manufacturer from Anping County Boli Hardware Wiremesh Products Factory (established in 1998), we proudly present our 20 Micron Stainless Steel Wire Mesh Water Purifier Filter Element with a standard 3/4" NPT thread connection. This filter element is engineered for high-efficiency sediment removal, offering a reusable and durable solution for residential, commercial, and industrial water filtration systems. Crafted from premium stainless steel wire mesh, it provides excellent corrosion resistance and long service life, ensuring consistent water quality.
Our filter element is designed to trap particles as small as 20 microns, effectively removing sand, rust, silt, and other suspended solids from water. The 3/4" NPT threaded end makes it easy to install in standard filter housings or inline systems. Unlike disposable cartridges, this element is fully reusable — simply rinse it with water or brush it clean, reducing replacement costs and environmental waste.
Key Features & Technical Specifications:
- Material: 304 or 316L stainless steel wire mesh (optional) — acid & alkali resistant, high strength.
- Filtration Precision: 20 microns (other micron ratings available upon request).
- Connection: 3/4" NPT male thread (customizable to other thread types).
- Reusability: Washable, backwashable, or brush clean — average lifespan 2-5 years under normal use.
- Operating Temperature: Up to 100°C (212°F) for standard models; higher temperature options available.
- Flow Rate: Depends on housing; typically 10-20 GPM for standard 10-inch element.
- Dimensions: Standard lengths: 10", 20", 30", 40" (custom sizes available).
- Application: Whole house water filtration, pre-filtration for RO systems, irrigation, industrial process water.
| Parameter | Value |
|---|---|
| Micron Rating | 20 µm |
| Mesh Count | Approx. 100-200 mesh (depends on weave) |
| Thread Type | 3/4" NPT |
| Material Grade | SS304 / SS316L |
| Max Pressure | 10 bar (145 psi) |
Advantages Over Disposable Filters: This stainless steel mesh filter element eliminates the need for frequent cartridge replacements. It is environmentally friendly, cost-effective, and maintains consistent filtration performance even after repeated cleaning. The robust construction ensures it withstands high water pressure and temperature fluctuations without deformation.
Trust & Reliability: With over 25 years of manufacturing experience, Anping County Boli Hardware Wiremesh Products Factory has been exporting to global markets including North America, Europe, Southeast Asia, and Oceania, with annual export values between US$5 million and US$10 million. We are committed to strict quality control, offering customizable options such as different mesh sizes, thread types, and dimensions. Our products are used in diverse applications from residential water purifiers to large-scale industrial filtration systems.
We invite you to experience the performance and durability of our 20 micron stainless steel mesh filter element. Contact us for sample testing, bulk orders, or custom specifications. Let us be your reliable partner in clean water solutions.
Frequently Asked Questions (FAQ)
-
Q: Can this filter element be used in a standard 10-inch housing?
A: Yes, it is available in standard 10-inch length with 3/4" NPT thread, compatible with most common filter housings. -
Q: How do I clean the filter element?
A: Simply remove it from the housing, rinse with clean water under pressure, or use a soft brush to remove debris. For stubborn deposits, soak in vinegar solution. -
Q: What is the micron rating equivalent to?
A: 20 microns captures particles visible to the naked eye (about 0.02 mm), such as fine sand, rust particles, and sediment. -
Q: Is the mesh material food-grade?
A: Yes, we use stainless steel that meets food contact safety standards. It is non-toxic and suitable for drinking water. -
Q: Can I get a different thread size?
A: Yes, we offer customization for other thread types (e.g., BSP, NPT in different sizes) and lengths. Please inquire. -
Q: What is the expected lifespan?
A: Under normal usage (city water, moderate sediment), it can last 3-5 years with proper cleaning. Harsh water conditions may reduce lifespan. -
Q: Do you provide samples?
A: Yes, samples are available for evaluation. Contact our sales team for details. -
Q: Is this filter element suitable for hot water?
A: Standard models handle up to 100°C. For higher temperatures, we can provide high-temperature resistant versions.
