As a leading manufacturer based in Hengshui, Hebei, China, Anping County Boli Hardware Wiremesh Products Factory (established 1998) proudly presents our PVDF Coated Perforated Aluminum Ceiling Panel – a premium solution designed specifically for outdoor applications. With over two decades of expertise in metal fabrication and an annual export value of US$5 – US$10 million, we deliver panels that combine exceptional weather resistance with aesthetic versatility. Our PVDF coating technology ensures long-lasting protection against UV radiation, moisture, and temperature extremes, making these panels ideal for open-air ceilings, walkways, and building facades.
Each panel is precision-engineered from high-grade aluminum alloy (3003 or 5052 series) and undergoes a multi-layer PVDF coating process. The perforated design not only enhances visual appeal but also provides acoustic control and ventilation. Whether you need a standard size or a custom dimension, our factory is equipped to meet your specific requirements. With shipping ports in Tianjin, Qingdao, and Shanghai, we ensure timely delivery to markets across North America, South America, Europe, Asia, Africa, Oceania, and the Middle East.
Key Features and Technical Specifications
- Superior Weather Resistance: PVDF coating provides excellent UV stability, moisture resistance, and corrosion protection – ideal for outdoor environments with temperature ranges from -40°C to +120°C.
- Lightweight yet Strong: Aluminum alloy panels weigh only 2-5 kg/m², reducing structural load while maintaining high rigidity and impact resistance.
- Customizable Perforations: Choose from round, square, or custom hole patterns (2-10 mm diameter) with open area ratios from 10% to 60% to suit functional and aesthetic needs.
- Acoustic Performance: Perforations can be combined with optional acoustic backing (e.g., non-woven fabric or sound-absorbing foam) to achieve noise reduction coefficients (NRC) up to 0.8.
- Easy Installation: Panels are designed for concealed or exposed grid systems, with snap-in or screw-fixed options. Pre-cut holes and edge bending available upon request.
- Fire Safety: Optional fire-resistant backing material meets Class A (ASTM E84) standards – contact us for certification details.
Technical Parameters (Typical Values)
| Parameter | Value | Remarks |
|---|---|---|
| Material Grade | Aluminum 3003 / 5052 | H14/H18 temper |
| Panel Thickness | 0.5 mm – 1.2 mm | Customizable within ±0.05 mm |
| PVDF Coating Thickness | 25 – 35 microns | Two-coat or three-coat systems |
| Perforation Open Area | 10% – 60% | Depends on hole pattern |
| Standard Panel Size | 600×600 mm, 1200×2400 mm | Custom sizes up to 1500×3000 mm |
| Color Options | All RAL colors + custom | Gloss level 20-80° |
| Fire Rating (Optional) | Class A (ASTM E84) or equivalent | Available upon request with backing |
Benefits for Your Project
- Long Service Life: PVDF coating resists chalking, fading, and peeling for 20+ years in outdoor conditions, reducing maintenance costs.
- Design Flexibility: Choose from a variety of perforation patterns, colors, and edge treatments to match architectural aesthetics.
- Temperature Adaptability: Aluminum’s thermal expansion is predictable, and PVDF coating remains stable in extreme heat or cold.
- Eco-Friendly: Aluminum is 100% recyclable, and our manufacturing process minimizes waste – supporting green building certifications like LEED.
- Competitive Pricing: As a direct manufacturer with 26 years of experience, we offer factory-direct prices without compromising quality.
Trust & Reliability
Since 1998, Anping County Boli Hardware Wiremesh Products Factory has been a trusted partner for global clients. Our annual export value of US$5–10 million reflects our commitment to consistent quality and on-time delivery. We ship from major Chinese ports (Tianjin, Qingdao, Shanghai) to over 15 regions including North America, Europe, Southeast Asia, Africa, and Oceania. Our products are used in commercial buildings, transportation hubs, and outdoor recreational spaces. We invite you to request samples or a customized quotation – our engineering team is ready to support your project from concept to installation.
Frequently Asked Questions
Q1: What is the minimum order quantity (MOQ) for these panels?
A: Our MOQ is typically 100 square meters for standard sizes and colors. Custom orders may have different MOQs – please contact us for details.
Q2: Can the panel be installed in coastal areas with high salt spray?
A: Yes, the PVDF coating provides excellent corrosion resistance. For severe marine environments, we recommend a thicker coating (35 microns) and anodized aluminum substrate – available upon request.
Q3: Are there any certifications for fire safety or environmental standards?
A: Our panels can be produced with optional fire-resistant backing that meets ASTM E84 Class A. Environmental compliance (e.g., RoHS, REACH) is available upon request. Please specify your requirements during inquiry.
Q4: What hole patterns are available? Can I provide a custom pattern?
A: We offer round, square, slotted, and custom patterns. You can send your design (CAD or PDF) and we will produce a matching perforation tool. Custom patterns may require additional setup fees.
Q5: How long does the PVDF coating last? Does it fade over time?
A: PVDF coating is known for its 20+ year color retention in outdoor exposure. Fading is minimal – less than 5% change in ΔE after 10 years under normal conditions. We provide a 10-year warranty against peeling and chalking.
Q6: What is the lead time for production and shipping?
A: Standard orders take 15–20 working days after confirmation. Custom sizes or patterns may require 20–30 days. Shipping time depends on destination – typically 20–35 days by sea.
Q7: Do you offer installation guidance or accessories?
A: Yes, we provide installation manuals and recommend compatible suspension systems (T-grid or concealed). We can also supply edge trims, clips, and screws as accessories – please inquire.
Q8: Can I get a sample before placing a bulk order?
A: Absolutely. We offer free samples (up to 300×300 mm) with freight collect. For larger samples, contact our sales team for a quote. Samples are typically shipped within 3–5 days.
