Product Description
The MAC 72 Series valve is a three-way, balanced P.O.P. (Pilot-Operated Lift) valve, piloted by our Bullet Valve technology. The Bullet Valve utilizes “lift” solenoid valve technology. MAC’s “lift” configuration maintains a balanced design—a hallmark of MAC valves—because shifting force remains high and response times are consistent regardless of inlet pressure fluctuations.
| Item | Parameter |
|---|---|
| Country of Origin | USA |
| Function | 3/2 NO‑NC |
| Port Size | M 7 |
| Max Flow | 0.4 Cv |
| Fluid | Compressed air or inert gas |
| Pressure Range | Vacuum to 120 PSI (External Pilot); 40 to 120 PSI (Internal Pilot) |
| Pilot Pressure | 40 to 120 PSI |
| Lubrication | Not required |
| Filtration | 40 µ |
| Temperature Range | 0 to 120 ℉ |
| Flow @6 bar, ΔP=1 bar | 0.4 Cv |
| Coil | Class A continuous duty, #26 AWG x 18 leads |
| Voltage Tolerance | -15 ~ +10% of nominal voltage |
| Voltage | 24 VDC |
| Power Consumption | 2.5 W |
| Mounting | Manifold base mount |
| Pilot Supply | Internal |
| Cable Length | 72 inch |
| Manual Override | Embedded non‑locking type |
| MOV | Non‑grounded |
Performance Features
Cv (Max): 0.4
Port Sizes: #10–21, M5, M7
Configurations: In-line – Discrete Base; Non-insertion – Circuit Board; Non-insertion
Balanced Lift Valve
Tapered valve seat for long service life
High flow capacity
Adhesive-type lift valve with low friction
Wiping action eliminates sticking
Highly repeatable response
Translated with (free version)
Product Applications
Automotive, Carpets and Textiles, Cement and Concrete, Dust Collection, Electronics, Filling, Food, Glass, HVAC, Material Handling (Conveyors), Packaging, Plastics, Power Generation, Primary Metals (Aluminum), Printing, Tires and Rubber, Recycling, Transportation, Wood Processing
