As a dedicated manufacturer from Anping County Boli Hardware Wiremesh Products Factory (established in 1998), we present our premium 304 Stainless Steel Welded Mesh Panel with a wire diameter of 1.2mm and an opening of 50mm x 50mm. Each panel comes with a Mill Test Report to guarantee material traceability and quality assurance. This product is engineered to deliver exceptional corrosion resistance, structural integrity, and long service life in demanding industrial environments.
Our welded mesh panels are manufactured using advanced welding technology and high-grade 304 stainless steel wire, ensuring consistent opening dimensions and strong weld joints. The 50mm x 50mm square openings provide an ideal balance between strength and visibility, making the panels suitable for a wide range of applications including security fencing, animal enclosures, partition walls, machine guards, and concrete reinforcement. With a wire diameter of 1.2mm, the mesh offers robust rigidity while remaining manageable for handling and installation.
Below is a summary of the technical specifications for this product:
| Parameter | Specification |
|---|---|
| Material | 304 Stainless Steel (AISI 304) |
| Wire Diameter | 1.2 mm (±0.02 mm) |
| Opening Size | 50 mm x 50 mm (center to center) |
| Mesh Panel Size | 2.0 m x 3.0 m (custom sizes available on request) |
| Surface Finish | Mill finish (no coating) |
| Tensile Strength | ≥ 600 MPa (typical) |
| Corrosion Resistance | Excellent in atmospheric, freshwater, and mild chemical environments |
| Mill Test Report | Provided with each shipment, certifying chemical composition and mechanical properties |
Key product features and benefits:
- High-grade 304 stainless steel: Contains 18% chromium and 8% nickel, offering superior resistance to rust and oxidation compared to galvanized or mild steel mesh. Suitable for both indoor and outdoor use.
- Precision welded construction: Each intersection is fusion-welded under controlled parameters, ensuring uniform strength and preventing loose joints. The mesh remains flat and stable during handling.
- 1.2mm wire diameter: Provides a good balance of stiffness and flexibility. The mesh is rigid enough to maintain shape yet can be cut or bent for custom installations.
- 50mm x 50mm opening: Large enough to allow airflow and visibility, small enough to contain small animals or debris. Ideal for security fencing, window guards, and partition screens.
- Mill Test Report included: Every batch is accompanied by a detailed report documenting the chemical composition (e.g., C, Si, Mn, P, S, Cr, Ni) and mechanical properties (yield strength, tensile strength, elongation). This provides full traceability and quality assurance for buyers.
- Customizable panel sizes: We can cut and fabricate panels to your specific dimensions, reducing waste and installation time. Available in rolls or flat panels.
- Low maintenance: The 304 stainless steel surface requires no painting or coating, saving labor and material costs over the product lifetime.
Our 304 Stainless Steel Welded Mesh Panel is widely used in:
- Security fencing for industrial sites, warehouses, and residential areas
- Animal cages, aviaries, and zoo enclosures
- Machine guards and safety barriers
- Concrete reinforcement in slabs and walls
- Shelving, racks, and storage partitions
- Filter screens and ventilation grilles
- Architectural decorative mesh (with optional surface treatment)
Backed by Anping County Boli Hardware Wiremesh Products Factory, a manufacturer with over 26 years of experience (since 1998), we have built a reputation for consistent quality and reliable delivery. Our annual export value of US$5 million to US$10 million demonstrates the trust placed in us by customers across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and other regions. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring efficient logistics to global destinations.
Each panel is carefully inspected before packaging to ensure it meets your specifications. We have a strict quality control system that includes dimensional checks, weld integrity tests, and material verification. The Mill Test Report is your guarantee that the mesh conforms to the required 304 stainless steel standards.
Frequently Asked Questions (FAQ):
1. What is the difference between 304 and 316 stainless steel welded mesh?
304 stainless steel contains 18% chromium and 8% nickel, offering good corrosion resistance for most environments. 316 stainless steel includes molybdenum (2-3%) for enhanced resistance to chlorides and acidic conditions. For general industrial, fencing, and architectural use, 304 is a cost-effective choice. If your application involves seawater or strong chemicals, we recommend 316 (available upon request).
2. Is the mesh supplied in flat panels or rolls?
We can supply both flat panels and rolls. Standard flat panels are 2.0m x 3.0m, but we can customize size. Rolls are typically 1.0m to 2.0m wide and up to 30m long, depending on wire diameter. Please specify your preference when ordering.
3. Can the mesh be cut or bent on-site?
Yes, the 1.2mm wire diameter allows cutting with standard bolt cutters or angle grinders. Bending can be done with a press brake or by hand for small adjustments. However, for large quantities, we recommend ordering custom sizes to avoid waste.
4. Does the Mill Test Report include chemical composition and mechanical properties?
Yes, the Mill Test Report (MTR) includes the exact chemical composition (C, Mn, P, S, Si, Cr, Ni, etc.) and mechanical properties (tensile strength, yield strength, elongation) for the specific lot of wire used. This ensures full traceability to the steel mill.
5. What is the typical lead time for an order?
For standard sizes and quantities (e.g., 100-500 panels), lead time is approximately 15-20 working days after order confirmation. Custom sizes or larger quantities may require 25-30 days. We will confirm the exact schedule upon receiving your inquiry.
6. Are there any surface treatment options available (e.g., PVC coating, galvanized)?
This product is supplied in mill finish (uncoated). However, we can provide PVC-coated 304 stainless steel mesh or galvanized after welding as an option. Please contact us to discuss your requirements.
7. How is the mesh packed for export?
Standard export packing: flat panels are bundled with steel straps and wrapped in waterproof paper or plastic film. Rolls are wrapped with protective material. All packages are marked with product details and handling instructions. We can also pack according to your specific requirements.
8. Can I request a sample before placing a bulk order?
Yes, we offer samples (e.g., a small cut piece of 300mm x 300mm) for quality evaluation. The sample cost is usually free, but the buyer is responsible for shipping charges. Please contact our sales team to arrange.
With our 26 years of manufacturing expertise, strict quality control, and commitment to customer satisfaction, Anping Boli is your reliable partner for stainless steel welded mesh. Contact us today for a quotation or technical consultation.
