Help CenterZinc Chloride Crystallization Evaporator Mill Test Report Provided Standard Compliant Design
Product Spotlights
Related Products
-
2-Year Warranty Zinc Chloride Crystallization Evaporator With Free Installation GuidanceUS$ 6490 - 879000MOQ: 1 Combo -
Zinc Chloride Crystallization Evaporator With Double Effect Falling Film Design 2000L/DayUS$ 6490 - 879000MOQ: 1 Combo
-
304 Stainless Steel Zinc Chloride Crystallization Evaporator With PLC Control 220V 50HzUS$ 6490 - 879000MOQ: 1 Combo
-
Zinc Chloride Crystallization Evaporator for Chemical Wastewater Treatment Zero Liquid DischargeUS$ 6490 - 879000MOQ: 1 Combo
-
Lithium Hydroxide Evaporation System With Vacuum Operation, 316L SS, 5kW Heating, PLC AutomaticUS$ 6150 - 880200MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 and headquartered in Qingdao, Shandong, China, is a professional manufacturer specialized in environmental and chemical processing equipment. With a factory area of 10,000-30,000 square meters and an annual export value exceeding US$10 million, we are proud to introduce our Zinc Chloride Crystallization Evaporator — a high-efficiency solution designed to recover zinc chloride crystals from industrial waste solutions. This evaporator features a standard compliant design and is delivered with a mill test report to ensure transparency and quality. By combining advanced crystallization technology with robust construction, our equipment helps clients reduce waste, lower operating costs, and achieve sustainable production goals.
The Zinc Chloride Crystallization Evaporator is engineered to handle challenging zinc chloride solutions with high chloride content and corrosion risks. It utilizes forced circulation or MVR (Mechanical Vapor Recompression) technology to achieve efficient evaporation and crystallization. The system is fully customizable to match your specific capacity, concentration, and energy requirements. Below are the key technical specifications and benefits:
| Parameter | Specification |
|---|---|
| Material of Construction | Stainless Steel 316L / 904L (depending on chloride concentration) |
| Evaporation Capacity | 500 – 5000 kg/h (customizable) |
| Operating Temperature | 50 – 120°C (adjustable) |
| Crystallization Method | Forced Circulation / MVR (Mechanical Vapor Recompression) |
| Control System | PLC + HMI touch screen, remote monitoring available |
| Heat Source | Steam / Electricity / Waste heat (optional) |
| Final Crystal Purity | ≥98% (depending on feed composition) |
| Power Consumption | 0.5 – 1.5 kWh per kg of water evaporated (MVR technology) |
Key Features & Benefits:
- Corrosion-Resistant Design: All wetted parts are made of high-grade stainless steel or special alloys to withstand the aggressive nature of concentrated zinc chloride solutions, ensuring long service life.
- Energy-Efficient MVR Option: The Mechanical Vapor Recompression system recycles vapor heat, reducing energy consumption by up to 60% compared to traditional evaporators.
- Standard Compliant Construction: The design follows international standards (ASME, PED, Chinese GB, etc.) and is backed by a mill test report for each component, providing full traceability.
- Flexible Crystallization Control: Adjustable temperature and circulation rate allow precise control of crystal size and purity, meeting downstream requirements.
- Automated Operation: PLC-based control system with real-time monitoring minimizes manual intervention and ensures consistent output.
- Compact Footprint: Modular design reduces floor space requirements and simplifies installation.
- Low Maintenance: Few moving parts and easy-access design reduce downtime and maintenance costs.
Our Zinc Chloride Crystallization Evaporator is widely used in industries such as metal finishing, battery recycling, chemical synthesis, and wastewater treatment. Whether you need to recover high-purity zinc chloride crystals for reuse or concentrate waste streams for disposal, this evaporator delivers reliable performance.
Trust & Assurance: Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been serving global clients since 2015, with a factory covering 10,000-30,000 sqm and a team of 201-300 skilled employees. Our annual export value exceeds US$10 million, and we hold multiple certifications including ISO9001, ISO14000, HACCP, SA8000, OHSAS18001, and others. Every evaporator is tested before shipment, and a mill test report is provided to verify material and dimensional compliance. With our main markets spanning North America, Europe, Asia, Africa, and Oceania, we have the experience and capacity to support your project. Contact us today to discuss your specific requirements and receive a customized proposal.
Frequently Asked Questions (FAQ)
1. What is the typical lead time for this evaporator?
Lead time depends on capacity and customization. Standard units require 45-60 days after order confirmation. Custom designs may take 60-90 days.
2. Can the evaporator handle feed solutions with high impurity levels?
Yes, the design includes pre-concentration and filtration options. We can customize the system to handle impurities such as iron, calcium, or magnesium based on your feed analysis.
3. Is the mill test report included for every component?
Yes, a mill test report (MTR) is provided for all pressure-bearing parts and critical materials, ensuring full traceability and compliance with international standards.
4. What is the minimum order quantity (MOQ)?
Generally, MOQ is 1 set. For small-scale pilot units, we can offer a lab-scale version upon request.
5. Do you provide installation and commissioning services?
We offer on-site installation supervision and commissioning support by our experienced engineers. Remote assistance is also available.
6. How does the MVR system work and what is the energy saving?
MVR compresses the vapor generated during evaporation, raising its temperature and pressure, then reuses it as the heating medium. This reduces steam consumption by 50-70% compared to single-effect evaporation.
7. Can the evaporator be integrated into an existing production line?
Yes, our design is modular and can be adapted to fit your existing layout, piping, and control systems. We provide detailed engineering support for integration.
8. What certifications does your company hold?
Our company is certified with ISO9001, ISO14000, HACCP, SA8000, OHSAS18001, and others. Specific product certifications can be arranged if required.
