Help CenterStainless Steel Welded Mesh 2.5mm Wire Thickness, 4x4 Mesh Count, 2m Width, 3m Length, Standard Compliant
Product Spotlights
Related Products
-
Welded Stainless Steel Wire Mesh 2.5mm Diameter, 304 Material, 50mm x 50mm Square Hole, Industrial GradeNegotiableMOQ: 200 Square Meters -
316 Stainless Steel Welded Wire Mesh 2.5mm Wire Diameter, 100mm x 100mm Aperture, Heavy DutyNegotiableMOQ: 200 Square Meters
-
2.5mm Wire Diameter 304 Stainless Steel Welded Mesh, 2.4m x 1.2m Panel, 100mm x 100mm OpeningNegotiableMOQ: 200 Square Meters
-
304 Stainless Steel Welded Mesh 2.5mm Wire Diameter, 50mm x 50mm Opening, 2m x 3m PanelNegotiableMOQ: 200 Square Meters
-
Stainless Steel Welded Mesh 2.5mm Wire Diameter for Fencing and Security, 304 Grade, 50x50mm MeshNegotiableMOQ: 200 Square Meters
As a trusted manufacturer with over 20 years of expertise, Anping County Boli Hardware Wiremesh Products Factory proudly presents this Stainless Steel Welded Mesh featuring a robust 2.5mm wire thickness and a precise 4x4 mesh count. Each panel, measuring 2m in width by 3m in length, is engineered to deliver consistent performance in demanding environments. Our commitment to quality ensures that every roll meets strict dimensional tolerances and surface finish standards, making it an ideal choice for industrial, commercial, and agricultural applications.
This welded mesh is constructed from premium-grade stainless steel, offering exceptional corrosion resistance, tensile strength, and longevity. The 4x4 mesh pattern provides a balanced open area for optimal flow while maintaining structural integrity. Whether you need reliable fencing, secure partitioning, or efficient filtration media, this product delivers reliable results.
Key Features and Technical Specifications
- High-Strength Wire: 2.5mm diameter wire ensures excellent resistance to impact and deformation, suitable for heavy-duty use.
- Precise Mesh Count: 4x4 openings per inch (approx. 6.35mm aperture) provide consistent sizing for filtration and separation tasks.
- Standard Dimensions: 2m width x 3m length panels are convenient for installation and can be cut to custom sizes upon request.
- Corrosion Resistance: Stainless steel material withstands moisture, chemicals, and UV exposure, making it perfect for outdoor and marine environments.
- Clean Welds: Each intersection is fusion-welded for uniform strength, eliminating loose joints and ensuring long-term durability.
- Easy Maintenance: Smooth surface resists dirt buildup and can be cleaned with standard methods.
| Parameter | Value |
|---|---|
| Wire Diameter | 2.5 mm (±0.05 mm) |
| Mesh Count | 4 wires per inch (both directions) |
| Aperture Size | Approx. 6.35 mm x 6.35 mm |
| Panel Width | 2 m (customizable) |
| Panel Length | 3 m (customizable) |
| Material Grade | 304 / 316 stainless steel (optional) |
| Surface Finish | Mill finish, bright annealed, or PVC coated (available upon request) |
This stainless steel welded mesh is widely used in applications such as animal enclosures, security fencing, window screens, machinery guards, shelves, and liquid/solid separation. Its uniform openings and strong welds make it a reliable choice for architects, contractors, and OEMs who demand consistency. The 2m x 3m size reduces the number of joints needed during installation, saving time and labor costs.
Compared to woven wire mesh, welded construction offers superior rigidity and flatness, ensuring the panel retains its shape even under tension. The 2.5mm wire thickness provides a robust barrier that can withstand moderate impacts, while the 4x4 mesh count allows sufficient visibility and airflow. For applications requiring higher corrosion resistance, we offer 316 stainless steel grade with enhanced resistance to chlorides and acidic environments.
Trusted by Global Customers
Anping County Boli Hardware Wiremesh Products Factory has been a reliable manufacturer since 1998, with annual export value exceeding US$5 million. Our products are shipped to major ports including Tianjin, Qingdao, Shanghai, and Foshan, serving markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. We maintain strict quality control throughout production, from raw material selection to final inspection. Each panel is checked for dimensional accuracy, weld strength, and surface finish before packaging.
We understand that every project has unique requirements. That's why we offer customizable options including different wire diameters, mesh counts, panel sizes, and edge treatments. Our experienced team can provide technical support and samples to ensure the mesh meets your specific needs. With a strong track record of repeat orders from satisfied customers, we are confident in the quality and performance of our stainless steel welded mesh.
Contact us today to request a quote or discuss your application. We are ready to supply durable, standard-compliant welded mesh that delivers long-term value. Let us be your trusted partner in wire mesh solutions.
Frequently Asked Questions (FAQ)
-
Q: What is the exact opening size of the 4x4 mesh?
A: The 4x4 mesh count means 4 wires per inch in each direction, resulting in an aperture of approximately 6.35 mm (0.25 inches). Actual opening may vary slightly due to wire diameter tolerances. -
Q: Can I get this mesh in a different size or shape?
A: Yes, we offer customization. You can request different widths, lengths, wire diameters, and mesh counts. Minimum order quantities may apply for custom sizes. -
Q: Is this product suitable for outdoor use?
A: Absolutely. The stainless steel material provides excellent resistance to rust and corrosion. For coastal or highly corrosive environments, we recommend grade 316 stainless steel. -
Q: How is the mesh packaged for export?
A: Panels are typically bundled with protective wrapping (plastic or paper) and packed in wooden crates or pallets to prevent damage during shipping. Custom packaging is available upon request. -
Q: What is the lead time for this product?
A: For standard sizes, lead time is approximately 15-20 working days after order confirmation. Custom orders may require additional time depending on specifications. -
Q: Do you provide samples before bulk order?
A: Yes, we can provide small samples (e.g., 300mm x 300mm) for quality evaluation. The sample cost is usually covered by the customer, but we may offer free samples for serious inquiries. -
Q: What edge types are available?
A: Standard edges are plain cut. We can also provide finished edges such as hemmed, rolled, or with welded border wire for added stability. Please specify your requirement. -
Q: Does this mesh comply with international standards?
A: Yes, our production follows industry standards for stainless steel welded mesh. Specific certifications (e.g., ASTM) can be provided upon request for relevant orders.
