Help CenterCold Rolled Tin Plate 0.20mm T3 Temper Electrolytic Tin Plate for Tin Plate Cans, 2.8g/m² Coating
Product Spotlights
Related Products
-
T2-T5 Cold Rolled Electrolytic Tin Plate, 508mm Width, ASTM A623 Standard for Tin Plate CansUS$ 599 - 620MOQ: 25 Tons -
0.15mm-0.5mm Electrolytic Tin Plate Coil, Cold Rolled Steel, 2.8/5.6g/m² Tin Coating for CansUS$ 599 - 620MOQ: 25 Tons
-
0.16mm Cold Rolled Electrolytic Tin Plate, 800mm Width, 1000mm Coil ID, for Tin Plate CansUS$ 599 - 620MOQ: 25 Tons
-
Cold Rolled Tin Plate Coil 0.20mm, T4 Temper, 2.8g/m², ISO 9001 Compliant for Can MakingUS$ 599 - 620MOQ: 25 Tons
-
Electrolytic Tin Plate Coil for Tin Plate Cans, Free Sample Available, 15-20 Days DeliveryUS$ 599 - 620MOQ: 25 Tons
As a trusted manufacturer based in Qingdao, Shandong, Shandong Sino Steel Co., Ltd. specializes in producing high-quality cold rolled tin plate with precise thickness and coating. Our 0.20mm T3 Temper Electrolytic Tin Plate with 2.8g/m² tin coating is specifically designed for the production of tin plate cans, ensuring excellent corrosion resistance, formability, and solderability. With over 6 years of experience and a dedicated team of 101-200 employees, we deliver consistent quality that meets international standards.
This product is engineered for the demanding packaging industry, where dimensional accuracy and surface finish are critical. The 0.20mm thickness offers the perfect balance between strength and material economy, while the T3 temper provides adequate hardness for can body forming without cracking. The 2.8g/m² electrolytic tin coating ensures superior protection against rust and maintains food safety compliance.
Key Features & Technical Specifications
- Precise Thickness Tolerance: ±0.005mm ensures consistent wall thickness for high-speed can manufacturing.
- Uniform Tin Coating: 2.8g/m² electrolytic coating provides excellent corrosion resistance and solderability, meeting FDA/EU food contact requirements.
- T3 Temper: Optimal hardness range (HR30T 56-63) for easy forming and flanging without work hardening.
- Surface Options: Available in bright (stone finish) or matte finish, and can be supplied with oiled or dry surface as per customer request.
- Customizable Dimensions: Width from 600mm to 1050mm, coil inner diameter 508mm or 610mm, and coil weight up to 10 tons.
- High Purity Tin: Tin purity ≥99.85% ensures no contamination of packaged goods.
- Excellent Flatness: Edge wave and center buckle are strictly controlled for trouble-free printing and lacquering.
- Traceability: Each coil is laser-marked with heat number, coating weight, and lot number for full traceability.
| Parameter | Value | Remarks |
|---|---|---|
| Thickness | 0.20mm | Tolerance ±0.005mm |
| Temper | T3 | HR30T 56-63 |
| Tin Coating Weight | 2.8g/m² (each side) | Uniform distribution |
| Coating Type | Electrolytic (ETP) | Passivation optional |
| Width Range | 600 – 1050 mm | Customizable |
| Coil Inner Diameter | 508 mm / 610 mm | Other sizes available on request |
| Surface Finish | Bright / Matte | As per customer preference |
Advantages for Your Business
- Cost Efficiency: The 0.20mm thickness reduces material consumption by up to 15% compared to thicker gauges, without compromising structural integrity.
- High-Speed Forming: T3 temper ensures excellent ductility for deep drawing and ironing processes, minimizing downtime.
- Food Safety Compliance: Our tin plate meets global food contact regulations (FDA, EU 1935/2004). The 2.8g/m² coating provides adequate barrier against external contaminants.
- Consistent Coating Adhesion: Electrolytic process guarantees uniform tin distribution, preventing flaking during printing and lacquering.
- Reliable Supply Chain: With an annual export value of US$2.5–5 million, we maintain stable inventory and fast delivery from Qingdao, Tianjin, or Shanghai ports.
- Technical Support: Our experienced quality team provides pre-shipment testing reports (coating weight, temper, hardness) and offers after-sales technical assistance.
Shandong Sino Steel Co., Ltd. operates a modern factory spanning 10,000–30,000 square meters, equipped with state-of-the-art slitting, cutting, and inspection lines. We hold ISO9000 and ISO19011:2000 certifications, ensuring our production processes are controlled and audited regularly. Our products are exported to North America, South America, Eastern Europe, Southeast Asia, Africa, the Middle East, East Asia, Western Europe, Northern Europe, Southern Europe, and South Asia, serving packaging companies, can manufacturers, and metal converters.
We understand that consistent quality and on-time delivery are critical for your production planning. That's why we implement strict quality control at every stage: from raw material inspection of cold rolled coils to final tin coating analysis. Each batch is tested for coating weight, thickness, temper, and surface cleanliness. We also offer customization of width, inner diameter, and surface treatment to meet your specific can-making requirements.
Our 0.20mm T3 Temper Electrolytic Tin Plate is the ideal choice for manufacturers of tinplate cans, food containers, aerosol cans, and decorative tins. With over 100 employees dedicated to your success, we strive to build long-term partnerships. Contact us today to request a free sample, a quotation, or a technical data sheet. Let Shandong Sino Steel be your reliable partner for high-quality tin plate products.
Frequently Asked Questions
- What is the difference between T3 and other tempers? T3 temper offers a balanced hardness for moderate forming; it is commonly used for general-purpose can bodies. T2 is softer for deep drawing, while T4 is harder for ends and closures. For 0.20mm thickness, T3 is the standard choice for most can applications.
- Can this tin plate be used for food contact? Yes, the 2.8g/m² electrolytic tin coating meets international food safety standards. The tin purity is ≥99.85%, and the plate is free from harmful substances. We can provide a declaration of compliance upon request.
- What is the typical lead time for this product? For standard sizes (width 900mm, coil ID 508mm), lead time is 15-20 days after order confirmation. Custom sizes may require 25-30 days. We can expedite urgent orders based on inventory availability.
- Do you offer printed or lacquered tin plate? We supply plain electrolytic tin plate. For printed or lacquered sheets, we can recommend partnering with specialized coating facilities. We can also provide cut sheets in specific sizes.
- How is the tin coating weight measured? We use X-ray fluorescence (XRF) and chemical titration methods to verify the coating weight. Each coil is tested at multiple points to ensure uniformity within ±0.1g/m².
- What packing options are available? Standard packing includes steel pallets with side protection, wrapped in waterproof paper and plastic film, and secured with steel straps. For sea freight, we add wooden crates or fumigation-free pallets as required.
- Can you supply small trial quantities? Yes, we can provide trial coils of 1-2 tons for testing. Minimum order quantity for regular production is 20 tons per size. We encourage first-time buyers to request a sample before bulk order.
- What certifications does your company hold? We are certified under ISO9001:2015 (quality management) and ISO19011:2000 (auditing guidelines). Our products are manufactured in accordance with JIS G3303 and ASTM A623 standards. Additional certifications can be arranged per customer request.
