Satin Weave Carbon Fiber Cloth 5 Harness 0.25mm Thickness 3K
Product Spotlights
High-quality 5-harness satin weave carbon fiber cloth, 0.25mm thickness, 3K fibers. Offers excellent drapability, smooth surface finish, and high tensile strength. Ideal for aerospace, automotive, and sports equipment. Factory-direct from a manufacturer with 25+ years of experience and global export capability.
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Carbon Fiber
Weave Type:
Satin Weave 5 Harness
Thickness:
0.25mm
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Carbon Fiber Cloth for Concrete Structure Strengthening Wrapping SystemNegotiableMOQ: 1 Square Meter -
Pre-preg Carbon Fiber Cloth Resin Content 40% Curing Temperature 120°CNegotiableMOQ: 1 Square Meter
-
High Modulus Carbon Fiber Cloth 400GPa Modulus >98% Carbon Content for AerospaceNegotiableMOQ: 1 Square Meter
-
Carbon Fiber Cloth With Mill Test Report 1 Year WarrantyNegotiableMOQ: 1 Square Meter
-
ISO Standard Compliant Carbon Fiber Cloth Technical Training AvailableNegotiableMOQ: 1 Square Meter
Material
Carbon Fiber
Weave Type
Satin Weave 5 Harness
Thickness
0.25mm
Fiber Count
3K
Color
Black (Standard)
Width
Customizable (e.g., 1m, 1.27m)
Application
Aerospace, Automotive, Sports Equipment, Marine
Features
High Strength, Lightweight, Durable
Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer established in 1998 with an annual export value of US$5–10 million. As a specialized producer of advanced composite materials, we proudly present our Satin Weave Carbon Fiber Cloth 5 Harness 0.25mm Thickness 3K. This premium fabric is engineered for high-performance applications, combining exceptional strength, lightweight properties, and superior aesthetic quality. With our decades of experience and global shipping from major ports like Tianjin, Qingdao, and Shanghai, we deliver consistent quality to markets across North America, Europe, Asia, and beyond.
Product Overview
Our 5-harness satin weave carbon fiber cloth is crafted from 3K (3,000 filaments per tow) high-grade carbon fiber, featuring a thickness of 0.25mm. The satin weave pattern offers a smooth, lustrous surface and excellent drapability, making it ideal for complex shapes and cosmetic finishes. Whether you need structural reinforcement, weight reduction, or a sleek surface for visible parts, this fabric delivers reliable performance.
Key Features & Benefits
- Lightweight yet Strong: With a density of approximately 1.8 g/cm³, carbon fiber provides high tensile strength (up to 3,500 MPa) and modulus, outperforming steel at a fraction of the weight.
- Excellent Drapability: The 5-harness satin weave conforms easily to curved surfaces and complex molds, reducing layup time and waste.
- Smooth Surface Finish: The satin pattern minimizes fiber distortion, resulting in a uniform, glossy appearance suitable for exposed components.
- Consistent Quality: Controlled manufacturing processes ensure uniform thickness of 0.25mm ±0.02mm, with stable fiber orientation.
- Versatile Applications: Ideal for aerospace parts, automotive body panels, bicycle frames, drone components, sporting goods, and marine structures.
- Customizable Options: Available in various widths, roll lengths, and with optional pre-impregnated (prepreg) treatment upon request.
Technical Specifications
| Property | Value |
| Weave Pattern | 5-Harness Satin (5H) |
| Fiber Type | 3K Carbon Fiber (3000 filaments per tow) |
| Thickness | 0.25mm ±0.02mm |
| Areal Weight | Approx. 200 g/m² (standard; customizable) |
| Width | 1m, 1.27m, or custom widths |
| Roll Length | 50m, 100m, or custom lengths |
| Tensile Strength | ≥ 3,500 MPa (typical) |
| Tensile Modulus | ≥ 230 GPa (typical) |
Why Choose Our Carbon Fiber Cloth?
- Reliable Supply Chain: As a factory-direct manufacturer, we control every step from raw material sourcing to final packaging, ensuring stable quality and competitive pricing.
- Global Shipping Experience: With shipment ports in Tianjin, Qingdao, Shanghai, and Foshan, we efficiently serve clients in over 20 countries, including North America, Europe, and Southeast Asia.
- Customization Capability: We offer tailored width, length, and packaging options to meet your specific production requirements.
- Decades of Expertise: Since 1998, our team has been dedicated to wire mesh and composite materials, building a reputation for precision and reliability.
- Support for Diverse Applications: From automotive aftermarket parts to aerospace prototyping, our fabric is trusted by engineers and designers worldwide.
Frequently Asked Questions (FAQ)
-
What is the difference between 5-harness satin and plain weave?
5-harness satin weave has fewer interlacings, resulting in a smoother surface and better drapability for complex shapes, while plain weave offers more stability but less flexibility. -
Is this carbon fiber cloth suitable for wet layup or vacuum infusion?
Yes, it works well with both wet layup and vacuum bagging processes. The weave allows good resin wet-out. For best results, we recommend using a low-viscosity epoxy resin. -
Can I use this fabric for visible cosmetic parts?
Absolutely. The satin weave produces a uniform, glossy surface that is often used for visible carbon fiber components like automotive interior trim, hoods, and bicycle frames. -
What is the typical shelf life of this product?
When stored in a cool, dry place away from direct sunlight, the dry fabric has an indefinite shelf life. For prepreg versions, please inquire about specific storage requirements. -
Do you offer samples before bulk order?
Yes, we provide small sample pieces (e.g., 30cm x 30cm) for testing. Please contact us with your requirements. -
What is the minimum order quantity (MOQ)?
Our standard MOQ is 100 square meters, but we can discuss smaller quantities for sample orders or new customers. -
How do you package the carbon fiber cloth for shipping?
We roll the fabric onto cardboard tubes, wrap it in protective plastic and kraft paper, then pack into sturdy cartons or wooden cases to prevent damage during transit. -
Can you provide a certificate of analysis or test reports?
Yes, we can supply a material test report (tensile, weight, thickness) upon request. Please note that we do not claim third-party certifications unless specified.
Trust Anping County Boli Hardware Wiremesh Products Factory – With over 25 years of manufacturing experience, annual export revenue exceeding US$5 million, and a global customer base spanning 6 continents, we are your reliable partner for high-quality carbon fiber materials. Our factory-direct pricing, flexible customization, and dedicated customer service ensure you get the best value. Contact us today to discuss your project requirements or request a quote!
