Welcome to Anping County Boli Hardware Wiremesh Products Factory, a trusted manufacturer established in 1998 with over 20 years of export experience (annual export value US$5–10 million). Our Horizontal Solar Hot Water Storage Tank (0.6MPa, 50mm Insulation) is designed for high efficiency and durability, making it the ideal choice for solar thermal systems in residential, commercial, and industrial applications. With a robust pressure rating and thick insulation, this tank ensures reliable hot water storage while minimizing heat loss, even in cold climates. We ship from major ports like Tianjin, Qingdao, Shanghai, and Foshan to markets worldwide including North America, Europe, Southeast Asia, and Africa.
Product Features & Technical Specifications
- High Working Pressure: Rated at 0.6 MPa (approx. 87 psi), suitable for closed-loop solar systems and mains pressure applications.
- Thick Polyurethane Insulation: 50 mm high-density foam insulation reduces heat loss by up to 80%, keeping water hot for longer periods.
- Corrosion Protection: Inner tank lined with enamel or stainless steel (optional anti-corrosion coating) to extend service life.
- Horizontal Design: Space-saving configuration ideal for limited roof spaces or ground-mounted installations.
- Wide Application: Compatible with solar collectors, heat pumps, electric backup heaters, and gas boilers.
- Customizable Options: Volume from 100L to 500L, multiple inlet/outlet positions, and color choices available.
- Easy Installation: Pre-assembled brackets and connection ports (female thread or flange) for quick integration.
| Parameter | Value |
|---|---|
| Working Pressure | 0.6 MPa (6 bar) |
| Insulation Thickness | 50 mm |
| Insulation Material | High-density polyurethane foam |
| Inner Tank Material | Enameled steel / Stainless steel (optional) |
| Outer Shell | Powder-coated steel (white or custom color) |
| Connection Ports | 3/4" or 1" female thread / flange (customizable) |
| Volume Options | 100L, 150L, 200L, 300L, 500L (custom sizes available) |
| Max Working Temperature | 95°C (203°F) |
Advantages & Customer Benefits
- Energy Savings: Thick 50mm insulation reduces standby heat loss, lowering your energy bills and improving system efficiency.
- Long Service Life: Enamel inner lining protects against corrosion, withstanding high-temperature water and thermal cycling.
- Versatile Application: Works seamlessly with solar thermal panels, heat pumps, auxiliary electric heaters, and boiler backup systems.
- Space Saving: Horizontal shape fits under roofs, in attics, or on ground mounts without occupying excessive vertical space.
- Low Maintenance: High-quality construction minimizes the need for repairs; sacrificial anode rod (optional) further protects the tank.
- Global Compatibility: Designed to meet international standards for pressure vessels; export-friendly design with multiple port options.
Why Choose Us?
With a factory established in 1998 and an annual export value of US$5–10 million, Anping County Boli Hardware Wiremesh Products Factory has supplied reliable storage tanks to customers in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our horizontal solar hot water storage tanks are manufactured using advanced production lines and stringent quality control. We offer flexible customization (volume, connection type, color) to fit your project needs. Our dedicated logistics team ensures smooth delivery from Tianjin, Qingdao, Shanghai, or Foshan ports. Contact us today for a competitive quote and technical support. We look forward to building a long-term partnership with you!
Frequently Asked Questions
1. What is the maximum working pressure of this tank?
It is rated at 0.6 MPa (6 bar), suitable for most residential solar water heating systems with closed loops.
2. Can I use this tank with a heat pump or gas boiler?
Yes, the horizontal tank is compatible with solar collectors, heat pumps, electric backup heaters, and gas boilers, thanks to multiple connection ports.
3. What sizes are available?
Standard volumes range from 100L to 500L. Custom sizes can be manufactured upon request.
4. Is the tank insulated? How effective is the insulation?
Yes, it features 50mm thick high-density polyurethane foam insulation, which reduces heat loss significantly, keeping water hot for up to 24 hours under normal conditions.
5. How do I connect the tank to my solar system?
The tank is equipped with 3/4" or 1" female thread connections (also flanged options available). Detailed installation instructions are provided with the product.
6. What materials are used for the inner tank?
The standard inner tank is made of enameled steel for corrosion resistance. Stainless steel (304 or 316L) is available as an option for higher durability.
7. Do you provide certifications?
We adhere to international quality standards for pressure vessels. Specific certifications (e.g., CE, ISO) can be discussed based on your market requirements. Please contact us for details.
8. What is the warranty period?
Standard warranty is 2 years for manufacturing defects. Extended warranty options are available upon request.
