Help CenterActive Slope Retaining Net 300J Energy Absorption Capacity With 2.5mm Steel Wire Rope
Product Spotlights
Related Products
-
Slope Retaining Net Zinc-Aluminum Alloy Coated 6mm Wire Tensile Strength 65kN ISO StandardNegotiableMOQ: 1 Square Meter -
Slope Retaining Net for Mining Pit Slope Protection Anti-Fall Rock Mesh 304 Stainless SteelNegotiableMOQ: 1 Square Meter
-
Slope Retaining Net Applied to Road Cut Slope Stabilization With 4m x 5m Panel DimensionsNegotiableMOQ: 1 Square Meter
-
Slope Retaining Net 1 Year Warranty Mill Test Report Included With Installation ManualNegotiableMOQ: 1 Square Meter
-
Slope Retaining Net Standard Compliant With ASTM A975 Delivered With Quality Inspection CertificateNegotiableMOQ: 1 Square Meter
As a leading manufacturer from Anping County Boli Hardware Wiremesh Products Factory (established in 1998), we are proud to introduce our Active Slope Retaining Net with 300J Energy Absorption Capacity, constructed with 2.5mm steel wire rope. This product is engineered to provide reliable protection against rockfalls, landslides, and debris flows on slopes, highways, and mining sites. With over two decades of wire mesh manufacturing expertise and an annual export value of US$5–10 million, we deliver a solution that combines high energy absorption, durability, and cost-effectiveness.
Our active slope retaining net is designed to dynamically absorb impact energy up to 300 joules, effectively reducing the risk of catastrophic slope failures. The 2.5mm steel wire rope core ensures exceptional tensile strength and corrosion resistance, making it suitable for long-term outdoor installation in diverse climates. Each net is hot-dip galvanized to withstand harsh environmental conditions, providing years of maintenance-free service.
Below is a detailed overview of the key technical specifications and features:
| Energy Absorption Capacity | 300J (per panel) |
| Wire Rope Diameter | 2.5mm |
| Material | High-tensile steel wire rope (≥1770 N/mm²) |
| Mesh Type | Interlocking diamond pattern |
| Surface Treatment | Hot-dip galvanized (average zinc coating > 85 µm) |
| Panel Dimensions | Customizable (standard: 3m × 3m, 4m × 4m) |
| Connection Components | Steel wire rope clips, shackles, and anchor bolts (included) |
| Sustainability | 100% recyclable steel material |
Key Features and Benefits
- High Energy Absorption: The 300J capacity effectively dissipates kinetic energy from falling rocks and debris, minimizing damage to infrastructure and ensuring safety.
- Durable Steel Wire Rope: The 2.5mm diameter rope provides excellent flexibility and strength, allowing the net to conform to irregular slope surfaces while maintaining structural integrity.
- Corrosion Resistant: Hot-dip galvanizing offers superior protection against rust and UV degradation, extending service life in coastal, humid, or high-rainfall areas.
- Easy Installation: Lightweight design and pre-assembled panels reduce labor time and costs. No specialized tools required for standard installation.
- Customizable Dimensions: Available in various sizes to fit specific project requirements. Custom mesh patterns and rope diameters are also available upon request.
- Low Maintenance: Once installed, the net requires minimal inspection and upkeep, reducing long-term operational expenses.
- Environmentally Friendly: The steel wire rope is fully recyclable, aligning with sustainable construction practices.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
Since 1998, we have been dedicated to manufacturing high-quality wire mesh products for global markets. Our factory is located in Hengshui, Hebei, China, the renowned wire mesh industrial base. We export to major regions including North America, South America, Europe, Southeast Asia, Africa, and Oceania, with an annual export turnover of US$5–10 million. Our active slope retaining nets are rigorously tested for performance and durability, meeting the demands of civil engineering and geotechnical projects worldwide.
We offer flexible shipping options via major ports such as Tianjin, Qingdao, Shanghai, and Foshan. Our team provides technical support, installation guidance, and after-sales service to ensure your project runs smoothly. We also welcome OEM/ODM orders for customized solutions.
Contact us today to discuss your slope protection requirements. Our experienced engineers will help you select the right configuration for your site conditions. With our competitive pricing, fast delivery, and proven track record, we are your trusted partner in safety and reliability.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum energy absorption of this net?
A: The standard net is rated for 300J energy absorption capacity per panel. Higher energy ratings (e.g., 500J, 1000J) can be customized with thicker wire rope or different mesh configurations. -
Q: Can the net be used on steep slopes?
A: Yes, the flexible steel wire rope mesh adapts to slope angles up to 90 degrees. Proper anchoring with bolts and cables is recommended for extreme slopes. -
Q: What is the lifespan of the net in outdoor conditions?
A: With hot-dip galvanizing, the net typically lasts 15–20 years in temperate climates. In coastal or highly corrosive environments, additional protective coatings (e.g., PVC) are available. -
Q: Is the net easy to install?
A: Yes, the net is pre-assembled into panels with connection points. Installation involves unrolling, securing with anchors, and tensioning. A simple installation guide is provided with each order. -
Q: Do you provide samples for testing?
A: Yes, we offer free samples (shipping cost borne by buyer) for quality evaluation. Custom samples can be produced within 7–10 working days. -
Q: Can I get custom dimensions or different wire rope diameters?
A: Absolutely. We can produce nets with rope diameters from 2.0mm to 4.0mm, and panel sizes from 1m×1m to 10m×10m. Please provide your specific requirements. -
Q: What is the minimum order quantity?
A: Our typical MOQ is 100 square meters for standard sizes. For custom orders, MOQ may vary depending on complexity. Contact our sales team for details. -
Q: How is the net packaged for export?
A: Each net is compressed, rolled, and wrapped in waterproof polyethylene film, then packed in wooden pallets or crates for safe ocean or air freight.
All specifications are subject to our standard manufacturing tolerances. For project-specific load calculations, please consult our engineering department.
