Slope Stability Netting Double Twist Wire 3.0mm – engineered for long-term erosion control and structural reinforcement. Manufactured by Anping County Boli Hardware Wiremesh Products Factory (established 1998), our double twist wire mesh is produced from high-quality galvanized steel with a diameter of 3.0 mm, ensuring superior durability and resistance to harsh environmental conditions. Each roll is accompanied by a Mill Test Report confirming mechanical properties, and we offer full technical support for custom orders to meet your specific project requirements. Trust our two decades of manufacturing expertise to deliver reliable slope stabilization solutions.
Our double twist wire netting is widely used for slope protection, rockfall containment, and landscaping. The hexagonal mesh structure provides excellent flexibility and load distribution, adapting to ground movements without breaking. The 3.0 mm wire gauge offers a balanced combination of strength and workability, making it suitable for both permanent and temporary applications. We understand that every project site is unique, so we provide customization options including mesh size, roll width, coating type, and edge treatment. Our in-house engineering team assists with load calculations, anchoring recommendations, and installation guidance.
Key Features & Technical Specifications
- Superior Strength: 3.0 mm wire diameter ensures high tensile strength (350-550 N/mm²) to withstand heavy loads and soil pressure.
- Double Twist Design: Each intersection is twisted twice, preventing unraveling even under stress. This structure provides greater flexibility compared to welded mesh, allowing the netting to conform to irregular terrain.
- Corrosion Resistance: Available in hot-dip galvanized or electro-galvanized finish. Hot-dip galvanizing offers a thick zinc coating for aggressive environments (e.g., coastal or acidic soils).
- Mill Test Report: Certifies wire diameter, tensile strength, elongation, and zinc coating weight. Transparent quality assurance for your procurement.
- Customizable Dimensions: Mesh openings can be tailored (e.g., 60x80mm, 80x100mm, 100x120mm). Roll width up to 3m, length up to 30m per roll, or as specified.
- Easy Installation: Lightweight yet robust, can be installed manually with minimal tools. Suitable for steep slopes and difficult access areas.
| Parameter | Specification |
|---|---|
| Wire Diameter | 3.0 mm (±0.05 mm) |
| Mesh Type | Hexagonal Double Twist |
| Standard Mesh Opening | 80 x 100 mm (customizable) |
| Tensile Strength | 350 – 550 N/mm² |
| Zinc Coating (Hot-dip) | ≥ 250 g/m² |
| Roll Width | 1m – 3m (customizable) |
| Roll Length | 10m – 30m (customizable) |
Benefits to Your Project: Using our slope stability netting reduces the risk of landslides and soil erosion, protecting infrastructure and property. The double twist structure allows water drainage while retaining soil, vegetative growth can be supported through the openings, enhancing ecological restoration. The 3.0 mm wire offers a cost-effective solution compared to thicker alternatives, without compromising safety. We provide technical support from concept to completion, including site assessment, mesh selection, and anchoring system design. With our Mill Test Report, you can verify compliance with project specifications, saving time during inspections.
As a manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory has exported to more than 20 countries and regions, including North America, Europe, Southeast Asia, and Africa. Our annual export value exceeds US$5 million, reflecting our capacity to handle large-scale orders. We ship from major ports (Tianjin, Qingdao, Shanghai, Foshan) with flexible logistical arrangements. Our dedicated quality control team ensures every batch meets the agreed standards. We welcome custom orders – whether you need specific dimensions, special packaging, or additional certifications, we can accommodate your requirements. Contact us today for a quotation or technical consultation. Let our robust slope stability netting secure your slopes for years to come.
Frequently Asked Questions
Q1: What is the difference between double twist wire mesh and welded wire mesh?
A: Double twist mesh is more flexible and can adapt to uneven surfaces without breaking. It is ideal for slope stabilization because it allows movement of soil and rock while maintaining integrity. Welded mesh is rigid and better suited for flat surfaces or animal enclosures.
Q2: Can the 3.0mm netting be used for high-risk rockfall areas?
A: Yes, the 3.0 mm diameter provides sufficient strength for most rockfall applications. For extremely high energy impacts, a thicker wire or additional reinforcement layers may be recommended. Our technical team can help you design an appropriate system.
Q3: Do you provide sample rolls before bulk order?
A: Yes, we can produce small samples (e.g., 1m x 1m) for testing. The sample cost is usually refundable upon bulk order. Please contact us with your requirements.
Q4: How long is the lead time for custom orders?
A: Standard production takes 10-15 working days. Custom orders (e.g., non-standard mesh openings or special coatings) may require 15-20 working days, depending on quantity and complexity. We will confirm the schedule after order confirmation.
Q5: Is the Mill Test Report included with every shipment?
A: Yes, each shipment includes a Mill Test Report showing the actual wire diameter, tensile strength, and zinc coating results. Additional test reports (e.g., third-party inspection) can be arranged at extra cost.
Q6: What packaging do you use for export?
A: The netting is compressed in bales or wound on rolls, then wrapped with waterproof plastic and steel strapping. We can also bundle with wooden pallets or crates for fragile environments. Export packaging is designed to withstand sea freight and handling.
Q7: Can you help with installation design for slopes?
A: Absolutely. We have an engineering team that provides technical support for anchoring layout, tension calculations, and drainage considerations. We can share typical installation drawings and recommend accessories such as tie wires, staples, and anchor pins.
Q8: What is the minimum order quantity?
A: For standard sizes, MOQ is 500 square meters. For custom sizes, MOQ may be higher. We are flexible and can discuss trial orders for new customers.
