Hemaokang Steel (Shandong) Co., Ltd. is proud to introduce our premium Metal Cladding Panel for Cold Storage Warehouse with 60mm PIR Insulation Core. As a reliable manufacturer established in 2025 with an annual export value exceeding US$50 million, we understand the critical demands of temperature-controlled environments. Our panels are engineered to deliver superior thermal efficiency, structural integrity, and long-term durability, making them an ideal choice for cold storage warehouses, refrigerated facilities, and logistics centers. With a dedicated team of 51–100 skilled professionals and ISO9001 certification, we ensure every panel meets rigorous quality standards.
This panel features a 60mm thick PIR (Polyisocyanurate) insulation core, which offers exceptional thermal performance with a low thermal conductivity of ≤0.022 W/m·K. The metal facings (available in galvanized steel, aluminum, or pre-painted steel) provide robust protection against moisture, impact, and corrosion. The panels are designed for quick and easy installation, reducing labor costs and downtime. Whether you are building a new cold storage facility or upgrading an existing one, our cladding panels deliver consistent performance in temperatures ranging from -50°C to +100°C.
Key Features & Technical Specifications
- Superior Insulation: PIR core provides excellent thermal resistance, minimizing energy loss and reducing operational costs.
- Structural Strength: Metal facings add rigidity and load-bearing capacity, suitable for wall and roof applications.
- Fire Performance: PIR foam achieves Class B fire rating (Euroclass B-s2,d0) – additional certifications available upon request.
- Moisture Resistance: Closed-cell structure prevents water absorption, preventing mold and degradation.
- Customizable Dimensions: Available in widths up to 1200mm and lengths up to 12m, with thicknesses from 40mm to 200mm.
- Eco-Friendly: PIR is free of CFCs and HCFCs, contributing to green building standards.
| Parameter | Value |
|---|---|
| Core Material | PIR (Polyisocyanurate) Foam |
| Panel Thickness | 60mm (other options: 40–200mm) |
| Facing Material | 0.4–0.8mm Galvanized Steel / Aluminum / Pre-painted Steel |
| Thermal Conductivity (λ) | ≤0.022 W/m·K |
| Fire Rating | Class B (Euroclass B-s2,d0) – optional |
| Compressive Strength | ≥150 kPa |
| Surface Coating | PVDF, HDP, or PE (customizable) |
| Operating Temperature Range | -50°C to +100°C |
Our panels are designed to meet the demanding requirements of cold storage warehouses. The tongue-and-groove joint system ensures airtight connections, preventing thermal bridging and condensation. The panels are also compatible with various fastening systems, allowing for flexible installation on steel or concrete structures. Additionally, the metal surface can be finished in a wide range of RAL colors to match your facility’s aesthetic requirements.
Benefits for Your Business
- Energy Savings: The high thermal resistance of the PIR core reduces the load on refrigeration systems, lowering electricity bills by up to 30% compared to traditional insulation.
- Quick Installation: Pre-engineered panels come with all necessary accessories, cutting installation time by 40% compared to field-assembled systems.
- Durability: Metal facings resist corrosion and impact, ensuring a service life of 25+ years with minimal maintenance.
- Hygiene: Smooth, non-porous surfaces are easy to clean and inhibit bacterial growth, crucial for food storage applications.
- Global Compliance: Panels are manufactured in accordance with ISO9001 standards and can be tailored to meet local building codes (e.g., ASTM, EN).
Trust Hemaokang Steel (Shandong) Co., Ltd. as your partner for cold storage cladding solutions. With over US$50 million in annual export value and a strong presence in markets across North America, Europe, Asia, Africa, and Oceania, we have proven our ability to deliver quality products on time. Our factory in Liaocheng, Shandong, operates with advanced production lines capable of outputting 500,000 square meters of panels annually. We provide comprehensive technical support, from sample testing to on-site guidance. Choose our Metal Cladding Panel with 60mm PIR core and experience the difference in performance and reliability. Contact us today for a quote or sample request!
Frequently Asked Questions (FAQ)
-
Q: What is the typical lead time for 60mm PIR cladding panels?
A: Standard lead time is 15–20 working days after order confirmation, depending on quantity and customization. Express delivery is available for urgent orders. -
Q: Can I get samples before placing a bulk order?
A: Yes, we offer free samples (size 300x300mm) for quality evaluation. Shipping cost may apply, which can be deducted from your first order. -
Q: Are these panels suitable for outdoor use in cold climates?
A: Absolutely. The metal facings are treated with anti-corrosion coatings, and the PIR core has low water absorption, making them ideal for outdoor cold storage warehouses in harsh weather conditions. -
Q: What fire safety certifications do your panels have?
A: Our standard PIR panels achieve Class B (Euroclass B-s2,d0) fire rating. Higher fire ratings (e.g., Class A) are available upon request with special core formulations. -
Q: How do I install the panels to ensure airtightness?
A: The panels feature a tongue-and-groove design with an integrated seal. We provide detailed installation manuals and optional technical support from our engineers. -
Q: Can you customize the color or surface finish?
A: Yes, we offer a wide range of RAL colors and surface finishes including PVDF (high durability) and HDP (high density polyethylene). Please specify your requirements. -
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ for standard panels is 500 square meters. For custom sizes or colors, the MOQ may be higher. Contact our sales team for details. -
Q: Do you provide installation accessories like fasteners and sealants?
A: Yes, we can supply matching accessories including screws, washers, and sealant tapes. These are sold separately or as part of a complete package.
