Help CenterPolyester Screen Printing Mesh Roll 200 Mesh 38 Micron Thread 35% Open Area 1.5m x 100m
Product Spotlights
Related Products
-
Standard Compliant Polyester Screen Printing Mesh With 1-Year Warranty – 150 Mesh RollNegotiableMOQ: 1 Square Meter -
Polyester Screen Printing Mesh for Textile Garment Printing – 120 Mesh Plain Weave RollNegotiableMOQ: 1 Square Meter
-
Polyester Screen Printing Mesh 120 Mesh Plain Weave 34 Micron Thread Diameter 1.0m Width RollNegotiableMOQ: 1 Square Meter
-
High Tension Polyester Screen Printing Mesh 150 Mesh Twill Weave 40 Micron 1.2m WidthNegotiableMOQ: 1 Square Meter
-
Consistent Quality Polyester Mesh for Screen Printing – Mill Test Report Available, 120 Mesh 1.2mNegotiableMOQ: 1 Square Meter
Anping County Boli Hardware Wiremesh Products Factory has been a trusted manufacturer of industrial meshes since 1998. Our Polyester Screen Printing Mesh Roll 200 Mesh 38 Micron Thread 35% Open Area 1.5m x 100m is engineered to deliver consistent print quality and long service life for demanding screen printing applications. With an annual export value of US$5–10 million and serving markets across North America, South America, Europe, Asia, and beyond, we bring decades of expertise to every roll we produce.
This polyester mesh offers a precise balance of tension, ink flow, and durability. The 200 mesh count (38 micron thread diameter) combined with a 35% open area ensures excellent ink passage for fine detail printing while maintaining strong dimensional stability. The roll dimension of 1.5m x 100m provides ample material for large production runs or multiple setups.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Mesh Count | 200 mesh (76 threads per cm) |
| Thread Diameter | 38 micron |
| Open Area | 35% |
| Mesh Thickness | Approx. 76 micron |
| Roll Width | 1.5 m (59 inches) |
| Roll Length | 100 m (328 feet) |
| Material | High-tenacity polyester monofilament |
| Color Options | White, yellow, or custom color upon request |
Product Features & Benefits
- Consistent Tension Retention: The polyester monofilament threads are woven with precision to ensure uniform tension across the entire mesh, reducing registration errors and improving print accuracy.
- Optimal Ink Flow: With 35% open area and 38 micron threads, this mesh allows smooth ink passage for both solvent-based and water-based inks, ideal for high-definition graphics and fine text.
- High Durability: Polyester resists stretching, chemicals, and humidity better than nylon or silk, extending the life of the screen and reducing downtime.
- Easy Cleaning & Reclaiming: The smooth surface of polyester mesh facilitates quick cleaning and screen reclaiming, saving time and solvent costs.
- Versatile Application: Suitable for printing on textiles, paper, plastic, glass, metal, and ceramic substrates, especially for electronic circuits, PCB, and decals.
- Customizable Dimensions: We can supply the mesh in different widths and lengths according to your specific requirements. Custom colors and open area variations are also available.
Why Choose Our Polyester Screen Printing Mesh?
Our manufacturing process utilizes advanced looms and strict quality control to ensure every roll meets the same high standards. The 200 mesh count is a popular choice for multi-color halftone printing, textile graphics, and fine line work. The 1.5m width allows efficient use for large format screens, while the 100m length reduces roll changes during continuous production.
Trusted by Global Clients: Since 1998, Anping County Boli Hardware Wiremesh Products Factory has exported to over 30 countries. Our annual export value of US$5–10 million reflects the confidence our customers place in our products. We ship from major ports (Tianjin, Qingdao, Shanghai, Foshan) to ensure fast delivery worldwide.
Customization Options: If you require a different mesh count, thread diameter, or roll size, please contact us. We can adapt the product to match your specific printing needs. Our team is ready to provide technical support and sample rolls for testing.
Ready to Order? Invest in a mesh that delivers consistent results and reduces waste. Contact us today for a competitive quote or to discuss your project requirements. With our factory-direct pricing and decades of experience, you can rely on us as your long-term partner in screen printing supplies.
Frequently Asked Questions
-
What is the difference between 200 mesh and 180 mesh?
200 mesh has finer threads (38 micron) and higher thread count, resulting in sharper detail but slightly lower ink deposit. 180 mesh is coarser and allows thicker ink layers. Choose based on your desired print resolution and ink type. -
Can this mesh be used with UV inks?
Yes, polyester mesh is compatible with UV inks. However, ensure proper tension and exposure to avoid ink bleeding. We recommend testing a sample before full production. -
What is the recommended tension for this mesh?
Typical tension for 200 mesh polyester is 20–25 N/cm. Final tension depends on frame size and printing technique. Our mesh is woven to hold consistent tension during stretching. -
Is the mesh pre-shrunk?
We apply a heat-setting process during manufacturing to minimize shrinkage. However, slight dimensional changes may occur after stretching and curing. We advise pre-stretching the mesh before mounting if tight tolerances are required. -
How do I clean the mesh after printing?
Use a mild solvent like screen wash or emulsion remover. Polyester mesh is resistant to most chemicals, but avoid harsh acids or strong alkalis. Gently scrub with a soft brush and rinse with water. -
Can I get a sample before ordering bulk?
Absolutely. We offer small sample rolls (e.g., 1m x 1m) for testing. Please contact our sales team with your requirements. -
What is the minimum order quantity?
For standard 200 mesh 1.5m x 100m rolls, the minimum order is 1 roll. Custom sizes may have different MOQ. Contact us for details. -
How long does shipping take?
We ship from Tianjin, Qingdao, Shanghai, or Foshan ports. Standard sea freight takes 15–30 days depending on destination. Express delivery options are available upon request.
